BLADES



N80 – BN8010
double edge cutting blades-BN8010
N80 Blade.

  • Working dimensions 0-12mm.
  • Included angle 55deg.
  • Pack weight 35gr.
  • Pack quantity 10 pieces.
  • Made of H.S.S.. Hardness 62-64Rc.


N80M42 – BN8043
double edge cutting blades-BN8043
N80M42 Blade.

  • Working dimensions 0-12mm.
  • Included angle 55deg.
  • Pack weight 33gr.
  • Pack quantity 10 pieces.
  • Made of H.S.S. M42. Hardness 65-67Rc.


N70K – BN7001
double edge cutting blades-BN7001
N70K Blade.

  • Working dimensions 1.2-8mm.
  • Included angle 55deg.
  • Pack weight 5gr.
  • Pack quantity 1 piece.
  • Made of H.S.S. Hardness 62-64Rc.


N80K – BN8110
double edge cutting blades-BN8110
N70K Blade.

  • Working dimensions 2.4-11mm.
  • Included angle 55deg.
  • Pack weight 30gr.
  • Pack quantity 10 pieces.
  • Made of H.S.S. Hardness 62-64Rc.




N80KM42 – BN8143
double edge cutting blades-BN8143
N80KM42 Blade.

  • Working dimensions 2.4-11mm.
  • Included angle 55deg.
  • Pack weight 29gr.
  • Pack quantity 10 pieces.
  • Made of H.S.S. M42 Hardness 65-67Rc


N90K – BN9009
double edge cutting blades-BN9009
N90K Blade.

  • Working dimensions 3-15mm.
  • Included angle 55deg.
  • Pack weight 9gr.
  • Pack quantity 1 piece.
  • Made of H.S.S. Hardness 62-64Rc.


L3 – BL3001
double edge cutting blades-BL3001
L3 Blade.

  • Working dimensions 1-8mm.
  • Included angle 50deg.
  • Pack weight 6gr.
  • Pack quantity 1 piece.
  • Made of H.S.S.. Hardness 62-64Rc.


L4 – BL4001
double edge cutting blades-BL4001
L4 Blade.

  • Working dimensions 0.5-2.5mm.
  • Included angle 50deg.
  • Pack weight 6gr.
  • Pack quantity 1 piece.
  • Made of H.S.S.. Hardness 62-64Rc.


O-Ring – BO1001
double edge cutting blades-BO1001
O-Ring Blade.

  • Working dimensions 1-3mm.
  • Included angle 40deg.
  • Pack weight 9gr.
  • Pack quantity 1 piece.
  • Made of H.S.S.. Hardness 62-64Rc


TC – BC1001
double edge cutting blades-BC1001
TC Thread Cleaner Blade.

  • Working dimensions max. 3mm.
  • Included angle 90deg.
  • Pack weight 8gr.
  • Pack quantity 1 piece.
  • Made of H.S.S.. Hardness 62-64Rc.


Check the PDF



HOLDERS



K Holder – EL04003
EL04003
Holds all K blades with M3 screw. Length: 135mm


L Holder – EL07013
EL07013
Holds L blades. Blades are held in a 3mm square hole and tightened with 4mm setscrew. Length: 131mm

Check the PDF



TOOLS



DOUBLE BURR – DB1000
DB1000
DB1000_01
Simultaneously removes burrs from both sides of sheet metal. DB Handle with safety guard to protect your hand. Unique round cutting blades can be rotated and reversed for long life. For corners, use one blade only. Range: 0-12mm.

Includes:

  • N80 (BN8010)


NOGA O-RING BURR – NG1100
NG1100
NG1100_01
Removes burrs from internal O-ring grooves. Range 0-3(groove width).
Includes:

  • NG-1 Handle (NG1000)
  • O-Ring (BO1001)


NOGA V CUT – NG3200
NG3200
NG3200_01
For deburring sheet metal 1-8mm.
Includes:

  • NG-3 Handle (NG3000)
  • L Holder (EL07013)


KEYWAY-BURR – NG3300
NG3300
NG3300_01
Effectively removes burrs from internal and external keyways. Range 2.4-11mm.
Includes:

  • NG-3 Handle (NG3000)
  • K Holder (EL04003)
  • N80K (BN8110)
