INSIZE DIGITAL ANEMOMETER 9331-40

Name: INSIZE DIGITAL ANEMOMETER 9331-40
Brand: INSIZE
SKU: 9v battery

Code:

Description: Measure velocity, flow, temperature and relative humidity Velocity unit m/s, km/h,mil/h, ft/m, ft/s, knots Flow unit CMS (cubic meter per second), CMM (cubic meter per minute), CFM (cubic feet per minute) Temperature type: ambient, dew point, wet bulb Maximum and minimum modes Automatic power off Specification: Standard Delivery Main unit 1 pc USB cable

f in

Click to Expand

INSIZE DIGITAL ANEMOMETER 9331-40

Product Overview

The INSIZE Digital Anemometer (Model: 9331-40) is a comprehensive environmental testing instrument designed to measure air velocity, air flow, temperature, and relative humidity. Equipped with a large rotating vane sensor and a digital LCD display, this handheld unit supports multiple measurement units and features maximum/minimum modes, USB output connectivity, and automatic power off functionality.

Key Features & Capabilities

Multi-Parameter Measurement: Measures velocity, flow, temperature, and relative humidity.
Velocity Units: Supports m/s, km/h, mil/h, ft/m, ft/s, and knots.
Flow Units: Supports CMS (cubic meter per second), CMM (cubic meter per minute), and CFM (cubic feet per minute).
Temperature Types: Measures ambient, dew point, and wet bulb temperatures.
Operational Modes: Includes maximum and minimum data recording modes, data hold, and automatic power off.
Data Output: Features USB connectivity for data transfer (cable and software included).

Technical Specifications

Parameter	Specification
Velocity Measuring Range	0.8~30 m/s, 1.4~108 km/h, 0.9~67.2 mil/h, 1.3~98.5 ft/s, 78~5900 ft/m, 0.8~58.3 knots
Flow Measuring Range	0~9999 CMS, 0~9999 CMM, 0~99990 CFM
Temperature Measuring Range	-20~60°C / -4~140°F
Relative Humidity Measuring Range	0~100% RH
Velocity Accuracy	±(2%+0.5) for m/s, km/h, mil/h, ft/s, knots; ±(2%+50) for ft/m
Temperature Accuracy	±1.5°C / ±2.7°F
Relative Humidity Accuracy	±3% (20~80% RH), ±5% (<20% RH or >80% RH)
Velocity Resolution	0.01 m/s, 0.01 km/h, 0.01 mil/h, 0.01 ft/s, 1 ft/m, 0.01 knots
Flow Resolution	0.01 CMS, 0.1 CMM, 0.1 CFM
Temperature Resolution	0.1°C / 0.1°F
Relative Humidity Resolution	0.1% RH
Flowing Area Range	0~9.999 m² / 0~9.999 ft²
Sampling Time	0.4s
Maximum Working Altitude	2000m
Output	USB
Power Supply	9V battery
Dimensions	165 × 85 × 38 mm
Weight	200g
