PIPE VICE OPEN TYPE

CODE NO. 828   SIZE IN NO. 1 2 3 4 Pipe Holding Capacity in mm 30 50 75 100 Approx.weight in kgs 4.5 8.5 13 17 Check the PDF

AUTHOR RATE
PIPE VICE

CODE NO. 827 PILLAR TYPE CODE NO.827R ROUND PILLAR CODE NO.831 SELF LOCKING   SIZE IN INCHES 1 2 21/2 3 31/2 4 41/2 6 Pipe Holding Capacity 38 50 64 75 89 100 115 153 Approx weight 827 in kgs. 2.2 3.7 — 5 — 5.5 — — Approx weight 827R in kgs 4.8 […]

AUTHOR RATE
BENCH VICE (ALL STEEL BODY)

CODE NO. 805(Plain Model) CODE NO.805 S(Swivel Model) SIZE IN INCHES 3 4 5 6 8 Width of Jaws 80 100 125 150 200 Opening of Jaws 85 105 130 155 205 Depth of Jaws 58 70 82 88 105 Approximate Weight 805 in kgs 4.5 6 9.5 11.5 17 Approximate Weight 805S in kgs […]

AUTHOR RATE
UNIGRIP MACHINE VICE

CODE NO. 810   SIZE IN INCHES 31/4 4 5 6 Width of Jaws 80 100 125 150 Depth of Jaws 25 25 40 40 Opening of Jaws 80 100 125 150 Approx. Weight in kgs 2.5 4 6.5 8 Check the PDF

AUTHOR RATE
DRILL VICE EXTRA HEAVY DUTY

CODE NO. 860   SIZE IN INCHES 3 4 6 Width of Jaws 80 100 150 Depth of Jaws 45 60 60 Opening of Jaws 75 115 155 Height overall in mm 75 90 95 Approx. Weight in kgs 4.5 8 16.5 Check the PDF

AUTHOR RATE
DRILL VICE SUPER DELUXE

CODE NO. 812   SIZE IN INCHES 4 6 8 Width of Jaws 100 150 200 Opening of Jaws 140 220 280 Depth of Jaws 40 55 60 Height overall in mm 80 110 130 Length overall in mm 360 460 590 Width overall in mm 200 255 320 Approx. Weight in kgs 11 25 […]

AUTHOR RATE
DRILL VICE (COMMERCIAL TYPE)

CODE NO. 825 (Cl Body) CODE NO. 825S (SG Iron Body) SIZE IN INCHES 2 3 4 5 6 Width of Jaws 50 75 100 125 1.5 Opening of Jaws 50 85 110 140 160 Depth of Jaws 20 25 35 40 40 Height overall in mm 40 45 55 62 65 Approx. Weight 825 […]

AUTHOR RATE
BENCH VICE (COMMERCIAL DUTY)

CODE NO. 841 Fitted With SG Iron Nut SIZE IN NUMBER 0 1 2 3 4 5 6 8 10 12 SIZE IN INCHES 21/2 3 31/2 4 41/2 5 6 8 10 12 Width of Jaws 65 80 90 100 115 125 150 200 250 300 Opening of Jaws 70 85 110 120 140 […]

AUTHOR RATE
BENCH .VICE DOUBLE RIB (HEAVY DUTY)

CODE NO. 840 (Plain Model) CODE NO. 840S (Swivel Model) Fitted With SG Iron Nut SIZE IN NUMBER 0 1 2 3 4 5 6 8 SIZE IN INCHES 21/2 3 31/2 4 41/2 5 6 8 Width of Jaws 65 80 90 100 115 125 150 200 Opening of Jaws 70 85 110 120 […]

AUTHOR RATE
3-WAY TILTING & SWIVLING VICE

CODE NO. 830   SIZE IN INCHES 4 6 Width of jaws in mm 100 150 Opening of jaws in mm 100 150 Opening of jaws in mm 38 52 Depth of jaws i mm 450 530 Length overall in mm 195 285 Height overall 830 in mm 30 62 Check the PDF

AUTHOR RATE
COMPOUND & SINGLE SLIDING TABLE

CODE NO.808(Compound Sliding Table) CODE NO.808S (Single Sliding Table) CODE NO.808 SIZE IN INCHES 6X6 8X8 12X8 12X12 12X20 16X16 Height in mm 115 120 145 145 165 180 Overall Length in mm 300 350 510 510 680 620 T. Slot size in mm 13 13 13 13 16 16 Travel Both ways in mm […]

AUTHOR RATE
ROTARY MILLING TABLES

CODE NO. 811 (Universal without Indexing) CODE NO. 811  ID (Universal with Indexing) CODE NO. 815 (Horizontal without Indexing) CODE NO. 815 ID (Horizontal with Indexing)   SIZE IN INCHES 6 8 10 12 15 18 20 Dia. of table in mm 150 200 250 300 375 450 500 Table slate in mm 14 14 […]

AUTHOR RATE
DIVIDING HEAD

CODE NO. 848 SIZE IN INCHES 41/2 51/2 61/2 Gear worm ratio 1:40 1:40 1:40 Centre height in mm 115 140 165 Spindle Bore in mm 20 32 38 Spindle Taper 9 9 9 Overall height vertical position in mm 210 260 310 Length of base in mm 175 240 270 Width of base in […]

AUTHOR RATE
UNIVERSAL MACHINE VICE

CODE NO. 801 (SG-IRON BODY) SIZE IN INCHES 4 6 Width of jaws in mm 100 150 Opening of jaws in mm 65 115 Depth of jaws i mm 25 40 Height overall 801 in mm 175 225 Weight (Approx) 801 in kgs. 10 25 Check the PDF

AUTHOR RATE
SHAPER MACHINE VICE

CODE NO. 802 SWIVEL BASE CODE NO. 802P PLAIN BASE SIZE IN INCHES 6 8 10 12 Width of jaws in mm 150 200 250 300 Opening of jaws in mm 200 250 300 360 Depth of jaws i mm 50 55 70 75 Length overall in mm 530 685 770 860 Height overall 802 […]

AUTHOR RATE
TILTING & SWIVELING VICE

CODE NO. 800 (CI-BODY) CODE NO. BOOS (SG-IRON BODY) SIZE IN INCHES 2 3 4 5 6 8 Width of jaws in mm 50 75 100 125 150 200 Opening of jaws in mm 50 75 100 125 150 200 Depth of jaws i mm 28 35 38 50 50 60 Length overall in mm […]

AUTHOR RATE
PRECISION MILLING MACHINE VICE

J & S Type (England) CODE NO. 850 (Swivel Model) CODE NO. 850P (Plain Model) SIZE IN INCHES 4 6 8 Width of jaws in mm 100 150 200 Opening of jaws in mm 100 150 200 Depth of jaws i mm 40 50 60 Length overall in mm 320 465 590 Height overall 850 […]

AUTHOR RATE
MILLING MACHINE VICE

COOE NO. 803 SWIVEL BASE CODE NO. 803S STEEL BODY SWIVEL BASE CODE NO. 803P PLAIN BASE CODE NO. 803PS STEEL BODY PLAIN BASE SIZE IN INCHES 2 3 4 5 6 8 10 12 Width of jaws in mm 50 75 100 125 150  200 250 300 Opening of jaws in mm 50 […]
