The INSIZE ISR-S1000A is a high-precision surface roughness tester designed for comprehensive surface analysis. It features a color touch screen interface for the display of roughness values, profiles, and curves, with integrated printing capabilities. The unit supports automatic probe leveling and offers versatile measurement configurations, including transverse measurement capabilities.
- Parameter Support: Measures 38 roughness parameters compliant with ISO-4287, JIS-B0601, ISO-12085, and JIS-B0631 standards.
- Measurement Versatility: Measuring range up to 1000µm, suitable for grit and shot blasting applications.
- Probe Flexibility: Probe can be set at 90° or 270° for transverse measurements; probe can be inverted for specific orientations.
- Data Management: Memory capacity for up to 1000 measurement results.
- User Interface: Color touch screen with stylus pen; supports tolerance setting.
- Output: USB data output for external connectivity.
- Portability: Designed for handhold use with an adjustable height probe driver.
- Main unit: 1pc
- Probe driver: 1pc
- Standard probe (ISR-SB10A): 1pc
- Calibration block: 1pc
- AC/DC adapter: 1pc
- Measuring software (ISR-S-SOFTWARE): Controls the tester, displays values/profiles/curves, and provides data statistics.
- Test stand (ISR-S400-DK)
- Specialized Probes:
- Small roughness probe (ISR-SB10A-R2)
- Groove probe (ISR-SB20A)
- Deep groove probe (ISR-SB120A)
- Small hole probe (ISR-SB30A)
- Deep hole probe (ISR-SB80A)
- Small rod probe (ISR-SB40A)
- Cylinder/hole probe (ISR-SB110A)
- Transverse probe (ISR-SB50A)
- Internal angle probe (ISR-SB140A)
