| Indenter | Ball 2.5 mm diameter | Ball 5 mm diameter | Ball 10 mm diameter |
| Application | For closely wound bobbins of synthetic, finished fibers and filaments | For loosely wound bobbins of synthetic fibers and closely wound natural fibers, yarns and threads | For very loosely wound bobbins of thick yarns, such as carpet yarns |
| Convertible Probe | Curved end (< 400 mm diameter) / Flat end (> 400 mm diameter) |
| Measurement Range | 10 ~ 90H (display range 0 ~ 100H) |
| Resolution | 0.1H |
| Accuracy | ±1H |
| Testing Parameters | Depth of Indentation: 0 ~ 2.5 mm<br>Test pressure: ~12.5 N<br>Measuring spring force: 0.55 ~ 8.065 N |
| Operating Conditions | Temperature: 0 ~ 40°C, Humidity: < 80% RH |
| Dimensions & Weight | 177 x 65 x 45 mm, approx. 285 g |
| Power Source | 2 x 1.5V AAA batteries |
| Standard Accessories | Main unit, pins, screwdriver, manual, case |
| Optional Accessories | Data logging (PC interface with USB & software), Bluetooth |
