TILTING & SWIVELING VICE

Name: TILTING & SWIVELING VICE
Brand: Oscar
SKU: Height overall 800 & 800 S in mm

Code:

CODE NO. 800 (CI-BODY) CODE NO. BOOS (SG-IRON BODY) SIZE IN INCHES 2 3 4 5 6 8 Width of jaws in mm 50 75 100 125 150 200 Opening of jaws in mm 50 75 100 125 150 200 Depth of jaws i mm 28 35 38 50 50 60 Length overall in mm

DOWNLOAD CATALOG

f in

Click to Expand

TILTING & SWIVELING VICE

Product Overview

The Oscar Tilting & Swiveling Vice is engineered for precision machining operations requiring multi-axis workpiece positioning. Available in two robust body material variants—Cast Iron (CI-Body, Code No. 800) and SG-Iron Body (Code No. 800S)—this vice provides reliable clamping across six size variants ranging from 2 inches to 8 inches.

Key Features & Capabilities

Dual-Body Construction Options: Offered in high-grade Cast Iron (CI-Body) and SG-Iron Body for enhanced durability and strength under heavy machining loads.
Multi-Axis Adjustment: Designed for tilting and swiveling functionality to facilitate complex angular setups.
Size Range: Accommodates diverse workpiece scales with jaw sizes from 50 mm (2") up to 200 mm (8").

Technical Specifications

SIZE IN INCHES	2	3	4	5	6	8
Width of jaws in mm	50	75	100	125	150	200
Opening of jaws in mm	50	75	100	125	150	200
Depth of jaws in mm	28	35	38	50	50	60
Length overall in mm	220	275	340	460	485	635
Height overall 800 & 800 S in mm	110	135	150	180	195	230
Weight (Approx) 800 & 800 S in kgs.	3.5	8	16	30	40	75
