INSIZE DIGITAL DEPTH GAGES WITHOUT MOUNTING HOLES FOR EXTENSION BASE (CODE – 1147)

Non waterproof Resolution: 0.01mm/0.0005" Buttons: on/off, zero, mm/inch Automatic power off, move the digital unit to turn on power Meet DIN862 Battery CR2032 Made of stainless steel Optional accessory: extension base (code 6141)

With data interface

Code Range Accuracy L (mm)
1147-150 0-150mm/0-6″ ±0.03mm 237
1147-200 0-200mm/0-8″ ±0.03mm 287
1147-300 0-300mm/0-12″ ±0.03mm 403
1147-500 0-500mm/0-20″ ±0.05mm 605
1147-700 0-700mm/0-28″ ±0.06mm 805

Built-in wireless (receiver code 7315-2/3/6/7/8/9 is required)

Code Range Accuracy L (mm)
1147-150WL 0-150mm/0-6″ ±0.03mm 237
1147-200WL 0-200mm/0-8″ ±0.03mm 287
1147-300WL 0-300mm/0-12″ ±0.03mm 403
1147-500WL 0-500mm/0-20″ ±0.05mm 605
1147-700WL 0-700mm/0-28″ ±0.06mm 805

Digital depth gauge-1147_1

  • Non waterproof
  • Resolution: 0.01mm/0.0005″
  • Buttons: on/off, zero, mm/inch
  • Automatic power off, move the digital unit to turn on power
  • Meet DIN862
  • Battery CR2032
  • Made of stainless steel
  • Optional accessory: extension base (code 6141)
