• Measure wall thickness of tubes
  • Graduation 0.01mm
  • Ratchet stop
  • Carbide measuring faces
  • Supplied with setting standards (except 0-25mm)
Code Range Type Accuracy L b
3560-25A 0-25mm/0-1″ A 4μm 32 24
3560-50A 25-50mm/1-2″ A 4μm 57 32
3560-75A 50-75mm/2-3″ A 5μm 82 44.5
3560-100A 75-100mm/3-4″ A 5μm 107 57
3560-25SA 0-25mm/0-1″ B 4μm 32 24
3560-50SA 25-50mm/1-2″ B 4μm 57 32
3560-75SA 50-75mm/2-3″ B 5μm 82 44.5
3560-100SA 75-100mm/3-4″ B 5μm 107 57
