INSIZE External Dial Caliper Gage (Series 2332)

Product Overview

The INSIZE Series 2332 External Dial Caliper Gages are precision measuring instruments designed for accurate external dimension measurements. Engineered for industrial and workshop environments, these gages feature a robust mechanical design with a clear dial indicator for reliable, high-precision readings.

Key Features

Carbide Measuring Tips: Equipped with high-durability carbide tips to ensure excellent wear resistance and maintain measurement accuracy over extended use.
Ergonomic Grip: Features a textured, ergonomic handle for a secure grip and stable handling during measurement procedures.
Spring-Loaded Mechanism: Smooth lever-operated mechanism ensures consistent measuring force for repeatable results.

Technical Specifications

Measuring Tip Dimensions

Tip Diameter: $\varnothing$3 mm
Tip Length: 6 mm

Model Specifications

Code	Range	Graduation	Accuracy	L (mm)
2332-20	0-20 mm	0.01 mm	±0.04 mm	60
2332-40	20-40 mm	0.01 mm	±0.04 mm	60
2332-60	40-60 mm	0.01 mm	±0.04 mm	55
2332-80	60-80 mm	0.01 mm	±0.04 mm	55
2332-100	80-100 mm	0.01 mm	±0.04 mm	55
