• Used as shims to accurately set spacing
  • Made of hardened alloy steel
  • Length 5m
  • Width 13mm
4621 4621_01



Code Thickness (T) Accuracy
4621-02 0.02mm ±4µm
4621-03 0.03mm ±4µm
4621-04 0.04mm ±4µm
4621-04 0.05mm ±4µm
4621-06 0.06mm ±4µm
4621-07 0.07mm ±5µm
4621-08 0.08mm ±5µm
4621-09 0.09mm ±5µm
4621-10 0.10mm ±5µm
4621-12 0.12mm ±5µm
4621-15 0.15mm ±6µm
4621-18 0.18mm ±7µm
4621-20 0.20mm ±8µm
4621-25 0.25mm ±9µm
4621-30 0.30mm ±9µm
4621-35 0.35mm ±11µm
4621-40 0.40mm ±12µm
4621-45 0.45mm ±12µm
4621-50 0.50mm ±14µm
4621-55 0.55mm ±14µm
4621-60 0 60mm ±14µm
4621-65 0.65mm ±14µm
4621-70 0.70mm ±17µm
4621-75 0.75mm ±17µm
4621-80 0.80mm ±19µm
4621-85 0.85mm ±19µm
4621-90 0.90mm ±22µm
4621-95 0.95mm ±22µm
4621-100 1.00mm ±24µm

Check the PDF
