• High contrast analog display
  • Locking screw above
  • Lapped guideway
  • Slide and beam made of hardened stainless steel
  • Immediate measurements due to the Reference System
  • Raised guideways for the protection of the scale
  • Excellent resistance against dust, coolants and lubricants
  • Dirt wipers are integrated in the slide
  • USB
  • Opto RS232C
  • Digimatic
  • IP 67
  • Battery
  • Instruction manual
  • Case
  • Battery life approx. 3 years

Height of digits

  • 8.5 mm



Order no. Measuring range mm Measuring range inches Resolution mm/inch Error limit (mm) Error limit inches Standard Depth Rod
4103080
10 – 160
0.4 – 6.3″
0.01 / .0005″
0.03 mm
.001″
Factory standard
none



Functions

  • ON/OFF
  • AUTO-ON / OFF
  • mm/inch
  • LOCK function (key lock)
  • RESET (set display to zero)
  • PRESET (for entering a numerical value)
  • DATA (Data transmission via connection cable)
