• High contrast analog display
  • Locking screw above
  • Lapped guideway
  • Measuring blade for inside measurements
  • Slide and beam made of hardened stainless steel
  • Step measuring function
  • Immediate measurements due to the Reference System
  • Raised guideway for the protection of the scale
  • Excellent resistance against dust, coolants and lubricants
  • Dirt wipers are integrated in the slide
  • USB
  • pto RS232C
  • Digimatic
  • IP 67
  • battery
  • instruction manual
  • case
  • Battery life approx. 3 years

Height of digits

  • 8.5 mm







Order no. Measuring range mm Measuring range inches Resolution mm/inch Error limit (mm) Error limit inches Standard Depth Rod
4103074
0 – 150
0 – 6″
0.01 / .0005″
0.03 mm
.001″
Factory standard
round



Functions

  • ON/OFF
  • AUTO-ON / OFF
  • mm/inch
  • LOCK function (key lock)
  • RESET (set display to zero)
  • DATA (data transmission via connection cable)
