MICROMAR 40 Z THREAD MICROMETER

Name: MICROMAR 40 Z THREAD MICROMETER
Brand: Mahr
SKU: 4170030

Code:

Scales have a satin chrome finish Rugged steel frame, heat insulated Spindle is hardened throughout, ground and provided with a locking device Adjustable anvil Spindle and anvil both have a mounting bore to accommodate interchangeable anvils Flat end surface of the anvil shank rests on a hardened steel ball at the bottom of the mounting

f in

Click to Expand

MICROMAR 40 Z THREAD MICROMETER

Product Overview

The Mahr Micromar 40 Z is a precision thread micrometer designed for accurate measurement tasks. Built to DIN 863-3 standards, this instrument features a rugged, heat-insulated steel frame and a hardened, ground spindle. The design incorporates an adjustable anvil and a versatile mounting system for interchangeable anvils, ensuring high repeatability and durability in industrial measurement environments.

Key Features & Capabilities

Satin Chrome Finish: Scales are finished in satin chrome to reduce glare and improve readability.
Robust Construction: Features a rugged steel frame with heat insulation to minimize thermal expansion during use.
Precision Spindle: Hardened and ground spindle equipped with a reliable locking device.
Interchangeable Anvil System: Both the spindle and the anvil feature a mounting bore to accommodate interchangeable anvils.
Anvil Seating: The flat end surface of the anvil shank rests on a hardened steel ball at the bottom of the mounting bore for consistent positioning.

Technical Specifications

Order No.	Measuring Range (mm)	Graduation Value (mm)	Error Limit (µm)	Spindle Thread Pitch (mm)	Measuring Force (N)
4170030	0 – 25	0,01	4 µm	0.5 mm	5 – 10
4170031	25 – 50	0,01	4 µm	0.5 mm	5 – 10
4170032	50 – 75	0,01	5 µm	0.5 mm	5 – 10
4170033	75 – 100	0,01	5 µm	0.5 mm	5 – 10
4170034	100 – 125	0,01	6 µm	0.5 mm	5 – 10
4170035	125 – 150	0,01	6 µm	0.5 mm	5 – 10
4170036	150 – 175	0,01	7 µm	0.5 mm	5 – 10
4170037	175 – 200	0,01	7 µm	0.5 mm	5 – 10
