The Mitutoyo Series 118 Sheet Metal Micrometer features a distinctive U-shaped frame designed specifically for measuring the thickness of sheet metal at a considerable distance from the edge. Equipped with carbide-tipped measuring faces and a ratchet stop for consistent measuring force, these analog micrometers are available in metric and inch ranges with various measuring face profiles (Flat-Flat, Spherical-Flat, and Spherical-Spherical).
- U-shaped frame ideal for measuring sheet metal at a distance from the edge
- Carbide-tipped measuring faces for enhanced durability and wear resistance
- Profile options of measuring faces: Flat-Flat (F-F), Spherical-Flat (S-F), and Spherical-Spherical (S-S)
- Equipped with a Ratchet Stop for a constant, repeatable measuring force
- Standard accessories include a setting standard (1 pc., except for 0 to 25 mm / 0 to 1 in measuring range models) and spanner (1 pc.)
- Models with a 300 mm (12 in) throat include a standard stand for convenient horizontal measurement orientation
- Note on anvil types: In spherical-flat anvil type micrometers, the measuring face on the anvil side is spherical
Metric Models
Inch Models
Dimensions (Analog Models Reference)
- Spindle diameter: ø6.35 mm
- Measuring face diameter: ø6.3 mm
- Anvil diameter: ø18 mm
- Model dimensions (L, a, b, c in mm):
- 118-101 / 118-102: L = 0, a = 34, b = 110, c = 2.5 (Minimum measuring length: 25 mm, Total length: 215 mm, Spindle travel: 66.9 mm)
- 118-114 / 118-118: a = 43, b = 160, c = 2.5
- 118-110: a = 25, b = 41, c = 165
