| D-31/D-41 Reversible Drills |
D-36 Reversible Angle Drills |
D-38/RY-311 Straight Drill |
 |
 |
 |
| D-4400 Air Tapping Drill |
SD 94-WS Air Tapping Wrench |
NS-50S Air Needle Scaler |
 |
 |
 |
| FC-510 Air Flux Chipper |
FC-502 Air Flux Chipper |
CH-104 Air Chipping/Riveting Hammer |
Technical Specifications
| Model No |
Free Speed (rpm) |
Drilling Cap |
Overall Length (mm) |
Air Inlet |
Air Consumption (cfm) |
Weight (kgs) |
| D-31 |
1,800 |
3/8″ |
165 |
1/4″ |
6 |
0.9 |
| D-41 | 800 |
1/2″ |
180 |
1/4″ |
6 |
1.13 |
| D-36 | 1,800 |
3/8″ |
216 |
1/4″ |
6 |
1.10 |
| D-38 | 2,600 |
3/8″ |
216 |
1/4″ |
6 |
0.90 |
| Model No | Free Speed (rpm) | Tapping Cap (mm) |
Overall Length (mm) | Air Consumption (cfm) | Weight (kgs) | Air Inlet (Inch) |
|
| Aluminium |
Steel |
||||||
| D-4400 |
700 |
12 |
8 |
205 |
6 |
1.62 |
1/4″ |
| SD-94 WS |
2500 |
10 |
6 |
225 |
4 |
1.36 |
1/4″ |
| Model No | No of Needle / Piston (mm) |
BPM |
Overall Length (mm) | Air Inlet |
Air Consumption (cfm) | Weight (kgs) |
| NS-505 |
2 x 29 Pcs |
3,000 |
250 |
1/4″ |
12 |
2.8 |
| FC-501 |
23.5 x 20 x 73 |
3,000 |
375 |
1/4″ |
12 |
2.6 |
| FC-502 |
23.5 x 20 x 73 |
3,000 |
250 |
1/4″ |
12 |
2.6 |
| Model No | Piston Dia (mm) |
Piston Stroke (mm) |
Speed (bpm) |
Overall Length (mm) | Average Air Consumption (cfm) | Weight (kgs) | Air Inlet |
| CH-104 |
28.5 |
102 |
1400 |
470 |
12 |
8.10 |
3/8″ |
