BAKER ELECTRONIC GAUGE: TWIN CHANNEL: 941 ANALOGUE

Electronic Gauge: Twin Channel: 941 Analogue Dual scale 3-0-3 and 10-0-10 galvanometer with enclosed tolerance pointers 5 Metric and 5 Inch ranges FEATURES OF ELECTRONIC GAUGE TWIN CHANNEL Twin channel gauge units with selectable probe combinations of +A, -A, +B, -B, +A +B, +A -B, -A +B, -A -B Inch and Metric measuring ranges RED,

DOWNLOAD CATALOG

f in

Click to Expand

BAKER ELECTRONIC GAUGE: TWIN CHANNEL: 941 ANALOGUE

Product Overview

The Baker Electronic Gauge: Twin Channel: 941 Analogue is an industrial twin-channel gauge unit designed for precision measurement tasks. It features a dual scale 3-0-3 and 10-0-10 galvanometer equipped with enclosed tolerance pointers, supporting both metric and inch measuring ranges.

Key Features & Capabilities

Dual scale 3-0-3 and 10-0-10 galvanometer with enclosed tolerance pointers
5 Metric and 5 Inch measuring ranges
Twin channel gauge units with selectable probe combinations: +A, -A, +B, -B, +A +B, +A -B, -A +B, -A -B
RED, GREEN, and YELLOW tolerance lamps for REJECT, ACCEPT, and REWORK indications
RS232 data output
Comprehensive outputs for further processing
Compatible with Half-bridge and LVDT type inductive measuring probes
Sturdy, ergonomic design suitable for shop floor environments
Splash-proof and sealed against dust
Add-on modules available for various applications (e.g., Light Grading Module, Relay Module)
Mains supply: 220 volts AC

Technical Specifications

Parameter	Specification
Metric Ranges	±10, ±30, ±100, ±300, ±1000 µm
Resolution (Metric)	0.5, 1, 5, 10, 50 µm
INCH Ranges	±0.0003, ±0.001, ±0.003, ±0.01, ±0.03 inch
Resolution (INCH)	0.00001, 0.00005, 0.0001, 0.0005, 0.001 inch
Power Supply	220 volts AC
