- Ceramic tipped jaws for outside measurements, extremely wear-resistant, non–magnetic, non-conductive
- Resolutions: 0.01mm/0.0005*
- Buttons : zero, mm/inch, on/off
- After power off, move the digital unit to turn on power
- Battery CR2032
- Data Output
- Made of stainless steel
- Optional accesory: data output system
| Code | Range | Accuracy | Thumb Roller | L | a | b | c | d |
| 1193-150* | 0-150mm/0-6* | 0.03mm | with | 235 | 21 | 16.5 | 16 | 40 |
| 1193-200* | 0-200mm/0-8* | 0.03mm | with | 297 | 24 | 20 | 16 | 50 |
| 1193-300* | 0-300mm/0-12* | 0.03mm | with | 390 | 26 | 21.5 | 16 | 60 |
| 1193-150W* | 0-150mm/0-6* | 0.03mm | without | 235 | 21 | 16.5 | 16 | 40 |
| 1193-200W* | 0-200mm/0-8* | 0.03mm | without | 297 | 24 | 20 | 16 | 50 |
| 1193-300W* | 0-300mm/0-12* | 0.03mm | without | 390 | 26 | 21.5 | 16 | 60 |
*Supplied with manufaturer calibration certificate
