The INSIZE Digital Crimp Height Micrometer (Code 3566) is a precision measuring instrument designed to measure the height of crimp contacts. Available in multiple variants ranging from 0mm to 100mm, this micrometer features IP54 dust and waterproof protection, a digital readout with a 0.001mm/0.00005" resolution, and a ratchet stop mechanism for consistent measuring force.
- Application: Specifically engineered to measure the height of crimp contacts
- Resolution: 0.001mm / 0.00005"
- Protection Rating: IP54 dust and waterproof
- Button Functions: On/off, set, mm/inch, ABS/INC, data output
- Power Management: Automatic power off functionality
- Measurement Control: Ratchet stop for repeatable measuring pressure
- Data Transmission: Built-in data output capability (optional data output system available as an accessory)
