• Used as shims to accurately set spacing
  • Made of hardened alloy steel
  • Length 300mm
  • Width 13mm
  • 10pcs/set
4622 4622_01 4622_02



Code Thickness (T) Accuracy
4622-02 0.02mm ±3µm
4622-03 0.03mm ±3µm
4622-04 0.04mm ±3µm
4622-05 0.05mm ±3µm
4622-06 0.06mm ±3µm
4622-07 0.07mm ±4µm
4622-08 0.08mm ±4µm
4622-09 0.09mm ±4µm
4622-10 0.10mm ±4µm
4622-12 0.12mm ±5µm
4622-15 0.15mm ±5µm
4622-18 0.18mm ±6µm
4622-20 0.20mm ±6µm
4622-25 0.25mm ±6µm
4622-30 0.30mm ±7µm
4622-35 0.35mm ±7µm
4622-40 0.40mm ±8µm
4622-45 0.45mm ±8µm
4622-50 0.50mm ±9µm
4622-55 0.55mm ±9µm
4622-60 0 60mm ±9µm
4622-65 0.65mm ±9µm
4622-70 0.70mm ±12µm
4622-75 0.75mm ±12µm
4622-80 0.80mm ±13µm
4622-85 0.85mm ±13µm
4622-90 0.90mm ±14µm
4622-95 0.95mm ±14µm
4622-100 1.00mm ±16µm

Check the PDF
