HARDENED & GROUND “V” BLOCKS 2

  • Used for Grinding, Light Milling, Drilling & Inspection of Round & Sqare Jobs.
  • Accuracy for Flatness, Sqareness and Parallesim within 0.005mm.
  • it can be used on the base, ends & sides.
  • Hardness 60±2 Rc & supply in pefect matched pair.
  • Clamps has tapping holes at 45° & 90° for clamping the square & round jobs.
  • Stepped groove design permits clamping of small or large jobs.



Sr. No. Art No. Size (MM) Range (MM)
1 215.01 65 L X 70 W X 50 H Ø 5 – Ø 50 round
35 mm square
