Mitutoyo-SERIES 148 – Fine Spindle Feed of 0.25mm/rev-Micrometer Heads

Miniature micrometer heads for ease of incorporating into machines. DIMENSIONS SPECIFICATIONS Metric Order No. Range Graduation Accuracy Stem dia. Stem Spindle end Spindle pitch 148-132 0 – 13mm   0.01mm   ±2µm   9.5mm Plain   Spherical (SR4)   0.25mm 148-133 w/ clamp nut 148-322 0 – 6.5mm Plain 148-323 w/ clamp nut

AUTHOR RATE
Mitutoyo-SERIES 148 – Fine Spindle Feed of 0.1mm/rev-Micrometer Heads

Highly accurate 0.1mm pitch thread is only one-fifth of that used for a standard-pitch head (0.5mm). External dimensions are compatible with standard 0.5mm pitch heads. DIMENSIONS SPECIFICATIONS Metric Order No. Range Graduation Accuracy Stem dia. Stem Spindle end Spindle pitch Special features 148-142     0 – 6.5mm     0.002mm   ±2µm   9.5mm Plain […]

AUTHOR RATE
Mitutoyo-SERIES 152 – Quick Spindle Feed of 1mm/rev-Micrometer Heads

Quick spindle feed of 1mm/rev. DIMENSIONS SPECIFICATIONS Metric Order No. Range Graduation Accuracy Stem dia. Stem Spindle end Spindle pitch 152-101 0 – 15mm   0.01mm ±2µm   12mm   Plain   Flat (carbide tip)   1mm 152-102 0 – 25mm 152-103 0 – 50mm ±4µm

AUTHOR RATE
Mitutoyo-SERIES 153 – Non-rotating Spindle Type – Micrometer Heads

The spindle translates without rotation. Torsion-free feed reduces workpiece deformation and wear. DIMENSIONS SPECIFICATIONS Metric Order No. Range Graduation Accuracy Stem dia. Stem Spindle end Spindle pitch Graduation features 153-101 0 – 15mm 0.01mm   ±3µm 9.5mm   Plain   Flat (carbide tip)   0.5mm Standard 153-201*   0 – 25mm   12mm 153-202* 0.001mm […]

AUTHOR RATE
Mitutoyo-SERIES 148 – Locking-screw Type – Micrometer Heads

Locking screw provides secure locking at any position of the spindle. Position of the locking screw is the same as the sleeve index line. DIMENSIONS SPECIFICATIONS Metric Order No. Range Graduation Accuracy Stem dia. Stem Spindle end Graduation features 148-220   0 – 6.5mm           0.01mm   ±5µm   6mm Plain […]

AUTHOR RATE
Mitutoyo-SERIES 151 – Medium-sized Standard Type with 8mm diameter spindle-Micrometer Heads

Larger spindle for heavy-duty applications (normally ø6.35mm). DIMENSIONS SPECIFICATIONS Metric Order No. Range Accuracy Stem dia. Stem Spindle end Special features 151-224           0 – 25mm           ±2µm             12mm Plain             Flat (carbide tip)   — […]

AUTHOR RATE
Mitutoyo-SERIES 150 – Medium-sized Standard Type-Micrometer Heads

Measuring range of 25mm. DIMENSIONS SPECIFICATIONS Metric Inch Order No. Range Accuracy Stem dia. Stem Spindle end Special features 150-208               0 – 1″               ±.0001″               .375″ Plain   Flat (carbide tip)     Standard 150-207 […]

AUTHOR RATE
Mitutoyo-SERIES 149 – Small Standard Type with Carbide-Tipped Spindle-Micrometer Heads

Carbide-tipped spindle provides high abrasion resistance. DIMENSIONS SPECIFICATIONS Metric Order No. Range Accuracy Stem dia. Stem Spindle end Graduation features 149-132           0 – 15mm           ±2µm           9.5mm Plain   Flat (carbide tip)     Standard 149-131 W/ clamp nut 149-183 Plain* […]

AUTHOR RATE
Mitutoyo-SERIES 148 – Small Thimble Diameter Standard Type-Micrometer Heads

Measuring range of 13mm. The thimble can be set to zero at any position by loosening the setscrew. Stainless steel throughout: 148-513, 518, 511 DIMENSIONS   SPECIFICATIONS Metric Order No. Range Accuracy Stem dia. Stem Spindle end Special features 148-503           0 – 13mm           ±2µm   […]

AUTHOR RATE
Mitutoyo-Optional Accessories for Surftest SJ-210/310

Attachment for interrupted surface measurement No.178-034 Best suited for measurement of the flat surface of a workpiece that has partial indentations and steps and that is hard to set the drive unit. Combination use with the magnet type specimen holder (Option: No.12AAA910) further improves the ease of operation. Attachment for measuring inside bores and holes […]

AUTHOR RATE
Mitutoyo-Optional Accessories for Surftest SJ-210/310

Detector Standard detectors Code No. Measuring force Stylus Remarks 178-296 0.75mN 2µmR /60˚ Dedicated to the standard/retractable drive unit 178–390 4 mN 5µmR /90˚ 178–387 0.75mN 2µmR /60˚ Dedicated to the transverse tracing drive unit 178–386 4 mN 5µmR /90˚ 178–391 4 mN 10µmR /90˚ Dedicated to the standard/ retractable drive unit *Tip radius /Tip angles Small hole detectors Code […]

AUTHOR RATE
Mitutoyo-SERIES 178 – On-site Surface Roughness Tester-Surftest SJ-310

SPECIFICATIONS *1: Calculation is available only when selecting the VDA, ANSI, or JIS 1982 standard. *2: Calculation is available only when selecting the ISO 1997 standard. *3: Calculation is available only when selecting the JIS 2001 standard. *4: Calculation is available only when selecting the ANSI standard. *5: Not available when selecting the JIS 1982 […]

AUTHOR RATE
Mitutoyo-SERIES 7 – Magnetic Stands

Mitutoyo’s Magnetic Stands accept all dial indicators and dial test indicators (with stem ø6 or ø8) and clamp to iron or steel surfaces with a strong magnetic force. 7014-10, 7031, 7032 and 7033B have a dovetail groove. DIMENSIONS SPECIFICATIONS Order No. Description Applicable holding stem dia. Magnetic force Remarks 7010-10 Magnetic stand ø6mm, ø8mm Approx. […]

AUTHOR RATE
Mitutoyo-Dial Snap Gage

Designed for quick GO/NG judgment of diameters of cylinders and shafts in machining processes. Wide (13.5 x 12mm/ 1.53 x 47”), flat carbide anvils. Anvil retracting stroke: 2mm/.080” Anvil positioning range: 25mm/ 1” Adjustment nut: adjusts the measuring range. Clamp: adjustment nut Flatness of measuring face: 1μm Stability of indication: 2μm or less (stability of […]

AUTHOR RATE
Mitutoyo-SERIES 209 – Internal Measurement Type-Dial Caliper gage

Dial caliper gages are inside diameter measurement tools, which have a broader range of applications including the measurement of hole diameter and internal measurement of special shapes (grooves). Internal measurement SPECIFICATIONS Metric Order No. Range Graduation Range of opening*1 Dial face Accuracy Measuring force 209-125 6 – 18mm 0.01mm 5.8 – 18.2mm 0-100-100 ±40µm 2.0N […]

AUTHOR RATE
Mitutoyo-SERIES 547, 7-Thickness Gages

Dial thickness gages can quickly measure the thickness of thin products such as paper and felt. Contact point and anvil are both made of ceramic: rust-free (547-401 is excluded.) Integrated molding of the bezel and crystal ensures protection against water and oil penetration via the front face. Standard Type High Accuracy Type Standard Type Lightweight […]

AUTHOR RATE
Mitutoyo-Optional Accessories for Dial Test Indicators-Styli, Stems and Holders

Styli (for Metric Models Only*) * Except for universal type dial test indicator (513-304G). Stylus length affects the scale factor of an indicator. The styli provided as standard give a scale factor of unity. ø0.5mm ball-point 190547 (L=14.7mm) 190549 (L=20.9mm) 190654 (L=22.3mm) 190656 (L=44.5mm) ø0.7mm ball-point 190548 (L=14.7mm) 190550 (L=20.9mm) 190653 (L=22.3mm) 190655 (L=44.5mm) ø1mm […]

AUTHOR RATE
Mitutoyo-SERIES 513-Pocket Type Dial Test Indicator

Jeweled bearings assure higher sensitivity and accuracy. Indicator can be mounted by clamping the stem or the body (except for 513-517WE and 513-517WT). Reversible measuring direction (Clutch type). Two holding bars are supplied. (Full sets only.) Fully adjustable bezel/dial face. Stylus is adjustable within 220°. Bezel is sealed with on O-ring to keep out water […]

AUTHOR RATE
Mitutoyo-SERIES 513 – Universal Type-Dial Test Indicator

Universal application to all directions. (Not only the direction of the measuring point, but also the direction of measurement itself can be adjusted 360 degrees without moving the indicator.) SPECIFICATIONS DIMENSIONS Set Configuration: Metric Set Configuration: Inch Optional Accessories ––––––: Swivel clamps (See page F-63.) ––––––: Holding bars (See page F-63.) ––––––: Stems (See page F-63.) 102824: Stylus, […]

AUTHOR RATE
Mitutoyo-SERIES 513 – Horizontal (20° Tilted Face), Vertical, and Parallel Types-Dial Test Indicator

Specially designed for easy viewing of dial. The dial face obliquely faces upward, allowing users to read the graduations from the user’s side. It is convenient when probing on the side of a large workpiece and the workbench is high. Using the universal holder allows easy hole centering. The dial face always faces upward when […]

AUTHOR RATE
Mitutoyo-SERIES 513 – Lever-Type Dial Indicators-Dial Test Indicators

Designed to probe surfaces that cannot be reached with a normal dial gauge. Useful both for alignment and for measurement purposes. Mitutoyo’s proprietary new design permits smooth pointer operation. Strong frame provides excellent rigidity and durability. Non-magnetic pointer and contact point permit reliable operation even in magnetic environments. Clear and concise wide dial face allows […]

AUTHOR RATE
Mitutoyo-SERIES 1-Back Plunger Type Dial Indicator

Back plunger type dial gauges are suitable for mounting onto leveling machine tool tables or inspection jigs, and for use in situations where standard dial gauges are difficult to read. Model 1960T and 1961T, which uses Mitutoyo’s proprietary shock-proofing mechanism, has excellent durability and shock resistance. DIMENSIONS Order No. A B C E F G […]

AUTHOR RATE
Mitutoyo-SERIES 2-Back Plunger Type Dial Indicator

Back plunger type dial gauges are suitable for mounting onto leveling machine tool tables or inspection jigs, and for use in small spaces where the graduations of standard dial gauges are difficult to see. Models 2960T, 2961T, 2990T-10 and 2991T-10, which use Mitutoyo’s proprietary shock-proofing mechanism, have excellent durability and shock resistance. Model 2990T-10 provides […]

AUTHOR RATE
Mitutoyo-SERIES 2 – Special Dial Indicators

Peak hold type dial gauge A mechanism holds the pointer and the spindle at the position of maximum depression and hence displays the maximum value. * Clearance of peak hold: push the nut in the direction of the arrow indicated in the dimensional drawing below. DIMENSIONS SPECIFICATIONS Metric Order No. Graduation Range (range/rev) Accuracy Repeat- […]

AUTHOR RATE
Mitutoyo-SERIES 2 – Special Dial Indicators-Dial Indicators

Adjustable hand dial gauge The hand position can be adjusted independently of the position of the spindle by rotating the top knob. DIMENSIONS * Contact points, other than dedicated types, cannot be installed. * The shoulder on a contact point (standard accessory) acts as a stop to prevent spindle overrun that may otherwise damage the […]

AUTHOR RATE
Mitutoyo-SERIES 3, 4 – Long StrokeType, Large Diameter-Dial Indicators

Dial indicators with a large-diameter dial face for easy reading. Models with longer measuring ranges are also available. All types are supplied with limit markers and a bezel clamp as standard. Both the stem and the spindle are made of high-strength quench-hardened stainless steel suitable for heavy-duty use. The bezel clamp and lifting lever (optional)*1 […]

AUTHOR RATE
Mitutoyo-SERIES 1 – Compact One Revolution Type for Error-free Reading-Dial Indicators

Mitutoyo’s unique shock-proof mechanism is incorporated, providing improved resistance to shock due to sudden spindle retraction caused by impact. This series has been developed to eliminate the possibility of reading errors due to miscounting multiple revolutions. The dead zone in red indicates “accuracy not guaranteed” . One revolution type Back plunger dial gages are also […]

AUTHOR RATE
Mitutoyo-SERIES 1 – Compact Type, Small Diameter-Dial Indicators

Compact dial indicators with bezel diameters of ø40mm for restricted-space applications in gaging jigs. SPECIFICATIONS Metric * Completed products inspection is performed in the vertical position (contact point downward) and the stated accuracy is guaranteed. Inch * Completed products inspection is performed in the vertical position (contact point downward) and the stated accuracy is guaranteed. […]

AUTHOR RATE
Mitutoyo-SERIES 1 – Compact Type, Small Diameter-Dial Indicators

Compact dial indicators with bezel diameters of ø31 or ø36mm for restricted-space applications in gaging jigs. DIMENSIONS Order No. A B C D E F G H I 1911T-10 15.5 42 31 12.9 19.2 15 11.5 30 5.9 1913T-10 15.5 39.5 31 12.9 19.2 15 9 30 5.9 1003T 18 40.3 36 13 15 9.5 […]

AUTHOR RATE
Mitutoyo-SERIES 2 – Long Stroke Type-Dial Indicators

Long stroke dial indicators with a ø57mm outer frame. All the models are equipped with limit markers and a bezel clamp as standard. An O-ring is employed to ensure air-tightness between the outer frame and the crystal case to prevent water or oil penetration. Both the stem and the spindle are made of high-strength quench-hardened […]

AUTHOR RATE
Mitutoyo-SERIES 2 – Standard One Revolution Type for Error-free Reading, Lightweight Type-Dial Indicators

Excellent water- and drip-proof characteristics (IP43). Smooth movement thanks to the improved design of bush and stem. Application of a hard coating on the surface of the crystal makes the gage scratch- and oil-resistant. Lightweight type (70g). DIMENSIONS * When installing an optional back (refer to page F-55 for details) please separately prepare 4 fixing […]

AUTHOR RATE
Mitutoyo-SERIES 2 – Standard One Revolution Type for Error-free Reading, Waterproof Type-Dial Indicators

Mitutoyo’s unique shock-proof mechanism is incorporated, providing improved resistance to shock due to sudden spindle retraction caused by impact. This series has been developed to eliminate the possibility of reading errors due to miscounting multiple revolutions. The dead zone in red indicates “accuracy not guaranteed”. One revolution type Back plunger dial gages are also available. […]

AUTHOR RATE
Mitutoyo-SERIES 2 – Standard One Revolution Type for Error-free Reading-Dial Indicators

Mitutoyo’s unique shock-proof mechanism is incorporated, providing improved resistance to shock due to sudden spindle retraction caused by impact. This series has been developed to eliminate the possibility of reading errors due to miscounting multiple revolutions. The dead zone in red indicates “accuracy not guaranteed”. DIMENSIONS Note 1: Dimensions of the inch (ANSI/AGD Type) dial […]

AUTHOR RATE
Mitutoyo-SERIES 2 – Waterproof Type, 0.01mm & 0.001mm Graduation-Dial Indicators

Waterproof type dial gages having a bezel with an outside diameter of 57mm. All types come with limit markers and a bezel clamp as standard. The bezel clamp can be attached to either the right or left side. These parts can be easily installed and removed without tools. The stem and spindle are made of […]

AUTHOR RATE
Mitutoyo-SERIES 2 – Standard Type, 0.001mm & 0.005mm Graduation-Dial Indicators

Standard 0.001mm and 0.005mm graduation dial indicators having a bezel with an outside diameter of ø57mm. All types come with limit markers and a bezel clamp. The outer clamp and lifting lever (optional) can be attached to either the right or left side. These parts can be easily installed and removed without tools. Secure adhesion […]

AUTHOR RATE
Mitutoyo-SERIES 2 – Standard Type, 0.01mm Graduation-Dial Indicators

Standard 0.01mm graduation dial gages having a bezel with an outside diameter of 57mm. All types come with limit markers and a bezel clamp as standard. The bezel clamp and lifting lever (optional) can be attached to either the right or left side. These parts can be easily installed and removed without tools. Secure adhesion […]

AUTHOR RATE
Mitutoyo-SERIES 543 – with Back-light LCD Screen-ABSOLUTE Digimatic Indicator ID-F

GO/±NG judgment function: If a judgment result shows an out of tolerance condition, the display backlighting changes from green to red. An analog bar indicator has been integrated to make upper/lower limit and turnover point reading more comfortable. With Mitutoyo’s ABSOLUTE Linear Encoder technology, once the measurement reference point has been set it will not […]

AUTHOR RATE
Mitutoyo-SERIES 543 – High Accuracy and High Functionality Type-Digimatic Indicator ID-H

This new-generation digital indicator offers the excellent accuracy and functionality expected from the top class of indicator. Take advantage of its high accuracy backed up by 0.5μm/.00002” resolution, remote control functionality via a handheld controller (or an RS-232C interface) and easy runout measurements with the well-established analog bar display. Functionality meets the needs of diverse […]

AUTHOR RATE
Mitutoyo-SERIES 575 – Slim and Economical Design-ABSOLUTE Digimatic Indicator ID-U

General purpose indicator with the measuring range of 25.4mm/ 1”. Cost-effective and user-friendly type which is equipped with the basic functions necessary. The ABS (absolute) sensor restores the last origin position automatically when the indicator is turned on, and realizes high reliability by eliminating over-speed errors.  Regarding origin setting, refer to “Origin Setting of Digimatic Indicators” on page F-18. […]

AUTHOR RATE
Mitutoyo-SERIES 543 – Signal Output Function Type-ABSOLUTE Digimatic Indicator ID-C

Enables a tolerance judgment to be output to external equipment for a measurement result against user-defined limits. Solid-state switching provides high reliability by avoiding metallic switch contacts. Output is enabled by directly connecting to external devices (sequencers, etc., for which a logical invert is available if required). The measurement and judgment results are displayed on the LCD. The […]

AUTHOR RATE
Mitutoyo-SERIES 543 – Calculation Type-ABSOLUTE Digimatic Indicator ID-C

Calculation function operates on spindle displacement. Entering the appropriate formula factors for a fixture dedicated to the application enables direct measurement readout, thereby eliminating any need for the conversion tables previously needed for those applications where fixtures are typically used. Peak-Value Run-out/MAX/MIN Hold enables GO/±NG judgement for peak value. Simple operation of many functions with five buttons and […]

AUTHOR RATE
Mitutoyo-SERIES 543 – Bore Gage Type-ABSOLUTE Digimatic Indicator ID-C

Dedicated to inside measurement with minimum-value Hold and tolerance judgement functions. Measurement data memory function (9 measurement results can be stored) Simple operation of many functions with five buttons and status icons. Wide LCD and new analog bar graph are now standard on all models. Sampling is performed fifty times per second for accurate detection of maximum and […]

AUTHOR RATE
Mitutoyo-SERIES 543 – Peak-Value Hold Type-ABSOLUTE Digimatic Indicator ID-C

Run-out/MAX/MIN Hold function enables GO/±NG judgement for peak or difference values. Simple operation of many functions with five buttons and status icons. Wide LCD and new analog bar graph are now standard on all models. Sampling is performed fifty times per second for accurate detection of maximum and minimum values. SPECIFICATIONS Metric Order No.(w/lug, flat-back) Range Resolution Accuracy*1 Hysteresis*1 […]

AUTHOR RATE
Mitutoyo-SERIES 543 – with Dust/ Water Protection Conforming to IP66-ABSOLUTE Digimatic Indicator ID-N/B

Our unique ABS sensor restores the last origin position automatically when the indicator is turned on. The chance of overspeed errors has been eliminated thanks to the ABS sensor. Rated to IP66: can be used satisfactorily even in adverse environments where the indicator is subject to splashing by cutting fluid or coolant. Slim body design […]

AUTHOR RATE
Mitutoyo-SERIES 543 — Standard Type-ABLOLUTE Digimatic Indicator ID-CX

The ABS (absolute) sensor restores the last origin position automatically when the indicator is turned on. Note: Regarding origin setting, refer to “Origin Setting of Digimatic Indicators” on page F-18. Thanks to Mitutoyo’s ABSOLUTE Linear Encoder, reliability has been increased due to elimination of over-speed errors. Tolerance-judging measurement is available by setting upper and lower […]

AUTHOR RATE
Mitutoyo-SERIES 543-ABSOLUTE Solar-Powered Digimatic Indicator ID-SS

Solar powered An environmentally friendly measuring instrument that does not require batteries, eliminating the hassle and cost of battery replacement. Can operate under minimum light conditions of 40 lux—lower than the level in a warehouse. Built-in recharger The large-capacity built-in reservoir capacitor allows you to use the indicator for long periods of time under light conditions below the […]

AUTHOR RATE
Mitutoyo-SERIES 960-Precision Levels

High-precision longitudinal and transverse vials make it possible to check or level surfaces. SPECIFICATIONS Order No. Sensitivity Dimensions (W x D x H) 960-603 0.02mm/m 200 x 44 x 38.2mm 960-703 0.02mm/m 200 x 44 x 200mm Technical Data Accuracy of graduations: ±0.7 DIV (960-603), ±0.3 DIV (960-703)

AUTHOR RATE
Mitutoyo-SERIES 187-Digital Universal Protractor

Data output function makes it easy to gather statistical data. Can be attached to height gages using a gage holder (950750, metric) Setting preset value. Removable blade. SPECIFICATIONS Order No. Blade length Remarks (standard accessory) 187-501 150mm Height gage holder (950750) 187-502 300mm Height gage holder (950750) 187-551 6” Height gage holder (950749) 187-552 12” Height gage […]

AUTHOR RATE
Mitutoyo-SERIES 188-Thread Pitch Gages

Thread pitch is stamped on each gage. Metric, Unified, and Whitworth screw pitch gages.   SPECIFICATIONS Metric Screw Pitch Gages Order No. Range Composition of leaves 188-130 0.35 – 6mm 22 leaves: 0.35, 0.4, 0.45, 0.5, 0.6, 0.7, 0.75, 0.8, 1, 1.25, 1.5, 1.75, 2, 2.5, 3, 3.5, 4, 4.5, 5, 5.5, 6mm and 60° angle […]

AUTHOR RATE
Mitutoyo-SERIES 186-Radius Gages

Radius size is stamped on each gage leaf. Each leaf comprises an internal and an external radius gage of the same size. With locking clamp. SPECIFICATIONS Metric Order No. Range Composition of leaves Remarks 186-110 0.4 – 6mm 18 leaves: 0.4, 0.8, 1, 1.2, 1.5, 1.6mm, 1.75 – 3mm by 0.25mm, 3.5 – 6mm by 0.5mm […]

AUTHOR RATE
Mitutoyo-SERIES 184-Thickness Gages

Metric thickness gages are available with tapered leaves. Each leaf is marked with its Each leaf is detachable if SPECIFICATIONS Metric Order No. Range Composition of leaves Remarks 184-313S 0.05 – 1mm 28 leaves: 0.05 – 0.15mm by 0.01mm, 0.2 – 1mm by 0.05mm — 184-303S 28 leaves: 0.05 – 0.15mm by 0.01mm, 0.2 – […]

AUTHOR RATE
Mitutoyo-SERIES 182-Steel Rules

Clear graduations on satin-chrome finish. Stainless tempered. SPECIFICATIONS Metric Wide Rigid Rules Order No. Graduations Range Width 182-111   1mm, 0.5mm (on both faces) 150mm 19mm 182-131 300mm 25mm 182-151 450mm 30mm 182-171 600mm 30mm Metric Fully-Flexible Rules Order No. Graduations Range Width 182-211   1mm, 0.5mm (on both faces) 150mm 12mm 182-231 300mm 12mm […]

AUTHOR RATE
Mitutoyo-SERIES 516-Accessories for Rectangular Gauge Blocks over 100mm

Specially designed for standard size gauge blocks over 125mm which have two coupling holes on the body: coupling of two long gauge blocks and attachment of jaws is possible. These accessories can also be used for CERA blocks. SPECIFICATIONS Set Order No. Individual Item Order No. Item Description Quantity Supplied         516-605 […]

AUTHOR RATE
Mitutoyo-SERIES 547-ABSOLUTE Digimatic Depth Gage

Easy-to-read dial effectively prevents misreading. Allows integration into statistical process control and measurement systems for models with measurement data output connector. Refer to page A-3. SPECIFICATIONS Metric Order No. Range Graduation Stroke Accuracy*4 Measuring force Base Contact point*1 Extension rod*2 Indicator*3 W T flatness 547-211   0 – 200mm 0.01mm   12.7mm ±20μm   1.5N […]

AUTHOR RATE
Mitutoyo-SERIES 7-Dial Depth Gage

Optimal for hole, narrow groove and step measurement. Metric Order No. Range Graduation Accuracy Stroke Measuring force   Contact point*1 Extension rod*2 Indicator*3 (dial indicator) W T Flatness Mounting position of a dial indicator 7210 0 – 10mm               0.01mm   ±15μm   10mm   1.4N 40mm     16mm […]

AUTHOR RATE
Mitutoyo-SERIES 527, 571 – Hook End Type-Depth Gage

The end of the main beam is hook-shaped to allow depth and thickness measurements of a projected portion or lip in a hole, in addition to standard depth measurement. Coolant proof models achieve IP67 protection level. Enables stable depth measurement with a resolution of 0.01mm. ABSOLUTE Digital Caliper (Refer to page D-8 for ABSOLUTE function.) Digital […]

AUTHOR RATE
Mitutoyo-SERIES 527-Vernier Depth Gage

Standard gage for depth measurement. Optional longer extension bases are available. (Except for models with measuring ranges of 600 and 1000mm) SPECIFICATIONS Metric Order No. Range Vernier reading Accuracy Base (W x T) Remarks 527-201 0 – 150mm     0.05mm ±0.05mm   100 x 6.5mm — 527-202 0 – 200mm — 527-203 0 – […]

AUTHOR RATE
Mitutoyo-SERIES 571-ABSOLUTE Digimatic Depth Gage

Coolant proof models achieve IP67 protection level. Enables stable depth measurement with a  resolution of 0.01mm. ABSOLUTE Digital Caliper (Refer to page D-8 for ABSOLUTE function.) Sliding operation of models with the measuring ranges 150mm (6″), 200mm (8″) and 300mm (12″) is smooth and comfortable. Battery: SR44 (1 pc), 938882. For initial operational checks (standard accessory) Optional […]

AUTHOR RATE
Mitutoyo-SERIES 128-Depth Micrometer

Measuring rod diameter: ø4mm Measuring rod lock is attached. *Measuring rod is attached on the rear side of the micrometer. Carbide-tipped measuring rod model is available. Ratchet stop provides constant measuring force. SPECIFICATIONS Metric Order No. Range Graduation Base 128-101   0 – 25mm   0.01mm 63.5 x 16mm 128-103*1 128-102 101.6 x 16mm 128-104*1 *1  with […]

AUTHOR RATE
Mitutoyo-SERIES 329, 129 – Interchangeable Rod Type-Depth Micrometer

This type uses interchangeable rods to enable wide-range measurement. Order Nos. 329-250-30, 329-251-30, 329-350-30, and 329-351-30 allow integration into statistical process control and measurement systems. Measuring rod diameter: ø4mm Measuring rod lock. Ratchet stop provides constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Base No. of rods Digimatic (LCD) 329-250-30 0 – 150mm 0.001mm 101.6 x 16mm 6 […]

AUTHOR RATE
Mitutoyo-SERIES 518 — High Precision ABSOLUTE Digital Height Gage-QM-Height

Best-in-class accuracy ±(2.4+2.1L/600)μm Newly developed high accuracy and high resolution ABSOLUTE linear encoder for position detection. Once origin is set, origin setting is not required each time you turn the power ON (except in the case of a large environmental temperature change). GO/±NG judgment is performed by setting upper and lower tolerances. If a judgment […]

AUTHOR RATE
Mitutoyo-SERIES 518 – High Performance 2D Measurement System-Linear Height

Excellent accuracy of (1.1+0.6L/600)μm with 0.1μm/0.4μm resolution/repeatability. High-accuracy Height Gage incorporating a wide range of measurement functions. To achieve best-in-class accuracy, a highaccuracy reflective-type linear encoder and high-accuracy guide are used. Measurement can be implemented by icon based commands that also support easy one key operation. Perpendicularity (frontal) of 5μm and straightness of 4μm are guaranteed. The TFT LCD […]

AUTHOR RATE
Mitutoyo-SERIES 192 – With digital counter-Dial Height Gage

Easy and error-free reading with both up and down digital counters as well as a dial. Can be zero-set at any arbitrary position. Provided with a large adjustment wheel for easy height adjustment. Clamp can be operated easily and securely. Fits comfortably in the hand and moves easily on the surface plate. Carbide tipped scriber (No. 07GZA000) is […]

AUTHOR RATE
Mitutoyo-SERIES 514, 506 — Standard Height Gage with Adjustable Main Scale-Vernier Height Gage

Fits comfortably in the hand and moves easily on the surface The main scale slides and clamps within the column for quick and convenient zero-setting. Large locking knobs are used both for the slider and fine adjustment clamps to make clamping easy and secure. Operability of slider has been Improved. Large main- scale engraving for […]

AUTHOR RATE
Mitutoyo-SERIES 570 – with ABSOLUTE Linear Encoder-ABSOLUTE Digimatic Height Gage

ABS and INC measurement modes allow efficient operation. Rigid structure makes instrument suitable for use in severe work environments. The +/- measurement function widens the application range. Allows integration into statistical process control and measurement systems. Refer to page A-3. Battery: SR44 (1 pc), 938882. For initial operational checks (standard accessory) Battery life is 5,000 […]

AUTHOR RATE
Mitutoyo-SERIES 570 – with ABSOLUTE Linear Encoder-ABSOLUTE Digimatic Height Gage

Allows smooth elevation by the slider adjustment wheel, which is the same as the well-established double-column structure height gage. Large slider-clamp lever ensures positive and accurate clamping action. High durability and high accuracy are ensured by an improved column design (35x15mm). Character height of the LCD display is 10mm. Ergonomic and stylish base fits comfortably  […]

AUTHOR RATE
Mitutoyo-SERIES 192 – Standard Type with SPC Data Output-Digimatic Height Gage

Easy-to-use standard type. Double-column structure ensures high measuring accuracy. Ergonomic base fits comfortably in the hand. Character height of the LCD display has been increased (10mm to 11mm) and a highcontrast LCD display unit adopted, so that readability is improved. Allows integration into statistical process control and measurement systems. Refer to page A-3. Battery: SR44 (1 […]

AUTHOR RATE
Mitutoyo-SERIES 573-Absolute Snap Caliper

ABSOLUTE electromagnetic induction linear encoder system is introduced. Snap mechanism allows continuous and easy measurement without moving the slider by using the lever. The ABSOLUTE Digimatic snap caliper features a spring-loaded mechanism to allow quick and efficient GO/NO-GO inspection for mass production parts. Allows step measurement Displacement of snap part is 2 mm. Measuring force: 7N to […]

AUTHOR RATE
Mitutoyo-SERIES 573-Absolute Low Force Caliper

ABSOLUTE electromagnetic induction linear encoder system is introduced. Due to the low measuring force, these calipers are ideal for measuring elastic workpieces such as plastic parts and rubber parts that standard calipers cannot measure accurately. Allows fine feeding easily by using thumb roller. Displacement of main scale jaw is 0.3mm. Measuring force: 0.49N to 0.98N […]

AUTHOR RATE
Mitutoyo-SERIES 536-Hook Type Vernier Caliper

Can measure width of grooves and lands inside bores and recesses. SPECIFICATIONS Metric Order No. Range* Accuracy Remarks 536-171 0 – 200mm (10.1 – 200mm) ±0.03mm — 536-172 0 – 200mm (2.1 – 200mm) ±0.03mm with fine adjustment * ( ): Dimension in inside measurement DIMENSIONS Range D F L N P S t W […]

AUTHOR RATE
Mitutoyo-Mitutoyo-SERIES 573, 536 — ABSOLUTE Digimatic and vernier type-Neck Caliper-Tube Thickness Caliper

The beam-mounted jaw is a round bar that facilitates measurements of tube wall thickness. Digital models are IP67 Absolute type. No need to reset the origin after switching on. (Refer to page D-8 for a description of Absolute measurement.) Allows integration into statistical process control and measurement systems for models with measurement data output connector. Refer to page A-3. […]

AUTHOR RATE
Mitutoyo-SERIES 573, 536 — ABSOLUTE Digimatic and vernier type-Neck Caliper

Can measure wall thickness inside bores and recesses. Digital models are an IP67 Absolute type. No need to reset the origin after switching on. (Refer to page D-8 for a description of Absolute measurement.) Allows integration into statistical process control and measurement systems for modwith measurement data output connector. Refer to page A-3. SPECIFICATIONS Metric Digital model […]

AUTHOR RATE
Mitutoyo-SERIES 573, 536 — Knife-edge/Inside Groove/Point Jaw Type-ABSOLUTE Inside Caliper

Specially designed for inside measurements in hard-to-reach places. Digital models are IP67 Absolute type. No need to reset the origin after switching on. (Refer to page D-8 for a description of Absolute measurement.) Allows integration into statistical process control and measurement systems for models with measurement data output connector. Refer to page A-3. SPECIFICATIONS Metric Digital model […]

AUTHOR RATE
Mitutoyo-SERIES 573, 536 — ABSOLUTE Digimatic and vernier type-Blade Type Caliper

The thin blade-type jaws fit into very small grooves and make previously difficult outside measurements far easier to obtain. The outside measuring faces are carbide tipped. Allows step measurement. Digital models are IP67 Absolute type. No need to reset the origin after switching on. (Refer to page D-8 for a description of Absolute measurement.) Allows integration […]

AUTHOR RATE
Mitutoyo-SERIES 573, 536 — ABSOLUTE Digimatic and vernier type-Point Caliper

• Narrow-tip jaws fit into very small grooves and tracks, making many previously difficult outside measurements far easier to obtain. • Allows step measurement. • Digital models are IP67 Absolute type. No need to reset the origin after switching on. (Refer to page D-8 for a description of Absolute measurement.) • SPC output models allow integration into statistical process […]

AUTHOR RATE
Mitutoyo-SERIES 573 – Center-to-Center & Edge-to-Center Types-ABSOLUTE Back-Jaw Centerline Caliper

Specially designed to measure hole Centerto-Center and Edge-to-Center distances. Provided with jaws on the back of the slider, measurements can be read easily from above. A digital model is IP67 Absolute type. (Refer to page D-8 for Absolute function.) Direct reading of pitch measurements is available due to the offset value setting function. Allows integration into […]

AUTHOR RATE
Mitutoyo-SERIES 573, 536 — ABSOLUTE Digimatic and vernier type-Offset Centerline Caliper

Specially designed for hole Center-to-Center measurements on the same, or offset, planes. Digital models are IP67 Absolute type. No need to reset the origin after switching on. (Refer to page D-8 for a description of Absolute measurement.) Direct reading of pitch measurements is available due to the offset-value setting function. Allows integration into statistical process control […]

AUTHOR RATE
Mitutoyo-SERIES 534-Long Jaw Vernier Caliper

Long jaws for measuring hard-to-reach workpiece features. Inside and outside measurements can be read directly from the upper and lower vernier scales. SPECIFICATIONS Metric with inside measurement vernier scale Order No. Range* Accuracy Graduation Remarks 534-113 0 (10.1) – 300mm ±0.04mm   0.02mm   with fine adjustment 534-114 0 (20.1) – 500mm ±0.06mm 534-115 0 (20.1) – […]

AUTHOR RATE
Mitutoyo-SERIES 573, 536 – ABSOLUTE Digimatic and vernier type-Offset Caliper

The beam-mounted jaw can be adjusted to facilitate measurement of stepped sections and hard-to-get-at workpiece features. Digital models are IP67 Absolute type. No need to reset the origin after switching on. (Refer to page D-8 for a description of Absolute measurement.) Allows integration into statistical process control and measurement systems for models with measurement data output connector. Refer to […]

AUTHOR RATE
Mitutoyo-SERIES 534-Long Jaw Vernier Caliper

Long jaws for measuring hard-to-reach workpiece features. Inside and outside measurements can be read directly from the upper and lower vernier scales. SPECIFICATIONS Metric with inside measurement vernier scale Order No. Range* Accuracy Graduation Remarks 534-109 0 (10.1) – 300mm ±0.07mm 0.05mm without fine adjustment 534-110 0 (20.1) – 500mm ±0.13mm * ( ): Minimum dimension […]

AUTHOR RATE
Mitutoyo-SERIES 160 – with Nib Style Jaws and Fine Adjustment-Vernier Caliper

Inside and outside measurements can be read directly from the upper and lower vernier scales. The jaws have radiused measuring faces for accurate inside diameter (ID) measurement. With fine adjustment (except for 160-130/131/132/133/134). SPECIFICATIONS Metric with inside measurement vernier scale Order No. Range* Accuracy Graduations Remarks 160-130 0 (20.1) – 450mm ±0.10mm     0.05mm   […]

AUTHOR RATE
Mitutoyo-SERIES 552 – with Interchangeable Jaws-ABSOLUTE Coolant Proof Carbon Fiber Caliper

IP66 Absolute Digital Caliper (Refer to page D-8 for a description of Absolute measurement.) The range of applications can be expanded by using interchangeable jaws (optional). Allows integration into statistical process control and measurement systems for models with measurement data output connector. Refer to page A-3. Provided with preset function for setting a desired starting point, which allows […]

AUTHOR RATE
Mitutoyo-SERIES 552 – with Long Jaws-ABSOLUTE Coolant Proof Carbon Fiber Caliper

IP66 Absolute Digital Caliper (Refer to page D-8 for a description of Absolute measurement.) Lightweight Digimatic Calipers that employ CFRP (Carbon Fiber Reinforced Plastics) in the beam and jaws. Allows integration into statistical process control and measurement systems for models with measurement data output connector. Refer to page A-3. SPECIFICATIONS Metric Order No. Range* Accuracy […]

AUTHOR RATE
Mitutoyo-SERIES 552 – with Standard jaws-ABSOLUTE Coolant Proof Carbon Fiber Caliper

IP66 Absolute Digital Caliper (Refer to page D-8 for Absolute function.) Lightweight Digimatic Calipers that employ CFRP (Carbon Fiber Reinforced Plastics) in the beam and jaws. Allows integration into statistical process control and measurement systems for models with measurement data output connector.Refer to page A-3. SPECIFICATIONS Metric Order No. Range* Accuracy 552-302-10 0 – 450mm […]

AUTHOR RATE
Mitutoyo-Series 505-Dial Caliper

Newly designed dial movement for ultra smooth sliding and high shock protection. Easy-to-read yellow dial. Large finger-rest aids ease-of-use. Jaw tips are relieved for easy measurement of thin parts. Allows step measurement. SPECIFICATIONS Metric Order No. Range Accuracy Graduation Remarks 505-730   0 – 150mm   ±0.03mm   0.02mm, 2mm/rev   505-734 Carbide-tipped jaws for outside […]

AUTHOR RATE
Mitutoyo-551 Series – with Nib Style and Standard Jaws-ABSOLUTE Digimatic Caliper

Offers a resolution of 0.01mm with corresponding accuracy. Incorporates an Absolute measurement system. No need to reset the origin after switching on. (Refer to page D-8 for a description of Absolute measurement.) Allows integration into statistical process control and measurement systems for models with measurement data output connector.Refer to page A-3. ID measurement value: displayed value […]

AUTHOR RATE
Mitutoyo-550 Series – with Nib Style Jaws-ABSOLUTE Digimatic Caliper

Offers a resolution of 0.01mm with corresponding accuracy. Incorporates an Absolute measurement system. No need to reset the origin after switching (Refer to page D-8 for a description of Absolute measurement.) Code 550-301-10, 550-331-10, 550-311-10 and 550-341-10: IP67 (These models are not a waterproof type. Therefore a rustproofing shall be applied after use.) Allows integration […]

AUTHOR RATE
Mitutoyo-532 Series – with fine adjustment-Vernier Caliper

Fine-adjustment aids slider positioning. Allows step measurement. SPECIFICATIONS Metric Order No. Range Depth bar Remarks 532-101 0 – 130mm   Blade   with fine adjustment 532-102 0 – 180mm 532-103 0 – 280mm Metric/Inch with metric/inch double scale Order No. Range Depth bar Inch graduation Remarks 532-119 0 – 130mm   Blade   .001″   […]

AUTHOR RATE
Mitutoyo-530 Series – Standard model-Vernier Caliper

Plain and basic design. Stepped graduation face prevents dust ingress between the main scale and slider. The small vernier face angle (14°) provides easy reading. Can measure outside and inside dimensions, depth, and steps. Carbide-tipped jaw calipers are optimal for rough finished parts, castings, grinding stones, etc. Decimal and fractional graduated scales (metric/inch and inch models only). […]

AUTHOR RATE
Mitutoyo-SERIES 500 – No battery or origin reset needed-ABSOLUTE Solar Caliper

Mitutoyo’s Absolute Solar Digimatic Caliper retains its origin point indefinitely. At 60 Lux and above the ABSOLUTE solar caliper is ready to start measurement. No more repeated zero setting caused by a shortage of light. An ABSOLUTE scale is incorporated so that zero setting is not required at each power ON. No danger of overspeed errors. Slider operation […]

AUTHOR RATE
Mitutoyo-500 Series – with Exclusive ABSOLUTE Encoder Technology-Long ABSOLUTE Digimatic Caliper

Long Digital caliper incorporating an ABSOLUTE scale and available with a measuring range from 450mm to 1000mm. Allows step measurement Allows integration into statistical process  control and measurement systems for models with measurement data output connector. Refer to page A-3. For the details of the Absolute scale and its function, refer to page D-8. SPECIFICATIONS Metric Order No. […]

AUTHOR RATE
Mitutoyo-500 Series – with exclusive ABSOLUTE Encoder Technology-ABSOLUTE Digimatic Caliper

ABSOLUTE electromagnetic induction linear encoder system is introduced (except for 0 – 300mm/0 – 12″ models). New ergonomic design with finger rest. The ZERO/ABS button allows the display to be Zero-Set at any slider position along the scale for comparison measurements. This button will also allow return to the absolute (ABS) mode and display of the true […]

AUTHOR RATE
Mitutoyo-SERIES 500 – with Dust/Water Protection Conforming to IP67 Level-ABSOLUTE Coolant Proof Caliper

ABS Coolant Proof Caliper with Dust/Water Protection conforming to IP67 Level. Can be used in workshop conditions exposed to coolant, water, dust or oil. 100% air-leak test ensures every caliper conforms to IP67. Font height is 9mm (increased by 22%) and visibility is improved (except for 0 – 300mm/0 – 12″ models). Battery cap does not require a screw […]

AUTHOR RATE
Mitutoyo-SERIES 500 – No battery or origin reset needed for IP67 digital caliper-Super Caliper

Top-of-the-line digital caliper. Solar type caliper with no battery and IP67 protection assures waterproof reliability. With no annoying origin restoration necessary, a measurement can be started any time and there is no restriction on operating speed. The impact resistance of the display unit has been increased for improved usability in workshop conditions. Waterproof function makes this Super Caliper suitable for […]

AUTHOR RATE
Mitutoyo-SERIES 511 – ABSOLUTE Digimatic Bore Gages-Bore Gages

These ABSOLUTE Digimatic bore gages are exclusively designed for inside diameter measurement. Up to four extension rods (250mm or 500mm) can be used for measuring at the bottom of a hole 2m deep. ABS (ABSOLUTE) type bore gages are not subject to overspeed error. The display and grip can be rotated up to 320 degrees and […]

AUTHOR RATE
Mitutoyo-SERIES 511 – for Blind Holes-Bore Gages

Capable of ID (inside diameter) measurement close to the bottom of a hole. Carbide contact point ensuring high durability and wear resistance. Grip is large and hollow to reduce effect of body heat on high-accuracy measurements. Alternative indicators may be used in place of those recommended*. * Some indicators and protection covers cannot be used with these […]

AUTHOR RATE
Mitutoyo-SERIES 511 – with Micrometer Head-Bore Gages

Micrometer head is attached to the anvil for accurate dimensional setting. Longer plunger stroke with no affect on accuracy. Carbide is used for the contact point ensuring high durability and wear resistance. This model reduces the influence of heat from  the operator’s hand by 50% by increasing the grip size and making the grip hollow-structured, thereby […]

AUTHOR RATE
Mitutoyo-SERIES 511 – Short Leg Type-Bore Gages

Compact and lightweight due to the short length below the grip. Longer plunger stroke with no affect on accuracy. Carbide contact point ensuring high durability and wear resistance. This model reduces the influence of heat from the operator’s hand by 50% by increasing the grip size and making the grip hollow-structured, thereby retaining high-accuracy measurement. Alternative indicators […]

AUTHOR RATE
Mitutoyo-SERIES 511-Bore Gages

Longer plunger stroke with no affect on accuracy. Carbide is used for the contact point ensuring high durability and wear resistance. This model reduces the  influence  of heat  from the operator’s hand by 50% by increasing the grip size and making the grip hollow-structured, thereby retaining high-accuracy measurement. Alternative indicators may be used in place […]

AUTHOR RATE
Mitutoyo-SERIES 511 – for Small Holes-Bore Gages

Alternative indicators may be used in place of those recommended*. Some indicators and protection covers cannot be used with these bore gages. Contact a Mitutoyo sales office if considering the use of dial or digimatic  indicators other than the recommended models. Setting Rings are available to aid in accurately setting a gage before making a measurement. (For details, […]

AUTHOR RATE
Mitutoyo-SERIES 141 – Interchangeable Rod Type-Inside Micrometers

Wide range of inside diameter measurements possible by combining one or more interchangeable rods. Each interchangeable rod is marked with its measuring range. For models supplied with more than one interchangeable rod, the full measuring range is achieved by combining spacing collars with the rods. Both micrometer head and rods are satinchrome finished throughout. The sleeve is rotated […]

AUTHOR RATE
Mitutoyo-SERIES 345, 145 – Caliper Type-Inside Micrometers

Carbide measuring faces. Equipped with a constant measuring-force device. Setting ring (nominal size below 300mm), CERA Inside Micro Checker (more than 50mm), and Gauge Block accessory set are provided as a reference gage for datum adjustment (refer to page C-47, C-26, and E-17 – E20 for details). SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Mass Digimatic (LCD) […]

AUTHOR RATE
Mitutoyo-SERIES 139, 339, 140 – Extension Pipe Type-Tubular Inside Micrometers

Wide range of inside diameter measurements possible by combining extension pipes and anvils with the micrometer head. Carbide measuring faces are available. The sleeve is rotated to adjust the index line position when setting to a length An inside length standard is required for accurately setting the micrometer. Order No. 339-101/301/302/102/303/304 features: IP65 (water-proof) protection […]

AUTHOR RATE
Mitutoyo-SERIES 137, 337 – Extension Rod Type-Tubular Inside Micrometers

Wide range of inside measurements possible by combining extension rods and anvils with the micrometer head. Two types of measuring faces are available; with or without carbide tip. (No. 337- 101/301/302/102/303/304 only available with carbide ) The sleeve is rotated to adjust the index line position when setting to a length standard. An inside length […]

AUTHOR RATE
Mitutoyo-SERIES 133 – Single Rod Type-Tubular Inside Micrometers

Standard single rod type inside Carbide measuring The sleeve is rotated to adjust the index line position when setting to a length Setting ring (nominal size below 300mm), CERA Inside Micro Checker, and Gauge Block accessory set are provided as a reference gage for datum adjustment (refer to page C-47, C-26, and E-17 – E20 […]

AUTHOR RATE
Mitutoyo-SERIES 568 – ABSOLUTE Digimatic Snap-Open Bore Gages-ABSOLUTE Borematic

A snap-type digital display, inside-diameter measuring instrument allows quick and easy measurement with lever operation. Titanium-coated measuring pins provide excellent durability and impact resistance and allow the instrument to measure right to the bottom of a blind hole. Three-Point contact measuring head enables highly repeatable measurement data to be obtained. The ABSOLUTE linear encoder eliminates overspeed errors. GO/NO-GO […]

AUTHOR RATE
Mitutoyo-SERIES 368 – Three-point Internal Micrometers-Holtest (Type II)

Hardened tool-steel anvils (instead of titanium-coated carbide) for a more economically priced tool. Same accuracy as the titanium-coated Holtest models. For details of setting rings, refer to page C-47 Constant-force device allows repeatable measurement. Can measure deep holes using an Extension Rod (optional). Range (mm) L3 (mm) L5 (mm) 12 – 20 2.6 or below […]

AUTHOR RATE
Mitutoyo-SERIES 368 – Three-point/Two-point Internal Micrometers-Holtest

Titanium-coated measuring pins on the three- point type (over 6mm range models) provide excellent durability and impact resistance and allow the instrument to measure right to the bottom of a blind Three-point bore micrometer with measuring range 6mm or longer allows stable measurement through automatic Can measure deep holes using an Extension rod (optional) which […]

AUTHOR RATE
Mitutoyo-SERIES 468 – Three-point Internal Micrometers-Digimatic Holtest

v Three-point internal micrometer with large LCD readout. (Character height 7.4mm) Titanium-coated measuring pins provide excellent durability and impact resistance and allow the instrument to measure right to the bottom of a blind One SR44 battery is required and battery life is 1.2 years under normal use. ABSolute and INCremental measurement modes allow highly efficient […]

AUTHOR RATE
Mitutoyo-SERIES 148 – Small Standard Type-Micrometer Heads

Measuring range of 13mm. SPECIFICATIONS Metric Order No. Range Accuracy Stem dia. Stem Spindle end Graduation features 148-104           0 – 13mm           ±2µm           9.5mm Plain   Flat       Standard 148-103 W/ clamp nut 148-121 Plain* 148-120 W/ clamp nut* […]

AUTHOR RATE
Mitutoyo-SERIES 148 — Short Thimble with Choice of Diameter-Micrometer Heads

Short body design maintains measuring range for limited space applications. Available in three thimble diameters to provide ease-of-reading options. DIMENSIONS Technical Data Graduation: 0.01mm or .001” Spindle pitch: 0.5mm or .025”

AUTHOR RATE
Mitutoyo-SERIES 148 — Small/Ultra-small Type-Micrometer Heads

Miniature micrometer heads for ease of incorporating into machines.   SPECIFICATIONS Metric Order No. Range Accuracy Stem dia. Stem Spindle end Graduation 148-215 0 – 5mm ±5µm 3.5mm Plain W/ clamp nut Spherical (SR1.5) Standard 148-216 148-201 0 – 6.5mm 6mm Plain W/ clamp nut Flat 148-203 148-205 Plain W/ clamp nut Spherical (SR3) 148-207 […]

AUTHOR RATE
Mitutoyo-Series 164, 350-Digimatic Micrometer Heads

Equipped with digital display and output. Series 350 IP65 models: the Digimatic output port enables inclusion in a statistical process control or networked measurement system. (Refer to page A-3 for details). SPECIFICATIONS Metric Order No. Range Resolution Accuracy** Stem Stem dia Spindle end Graduation features 164-163 0 – 50mm 0.001mm ±3µm ±2µm Plain 18mm Flat (carbide […]

AUTHOR RATE
Mitutoyo-SERIES 156-Micrometer Stands

Designed to allow benchtop use of hand micrometers or other gages which have frames suitable for gripping by the clamp. SPECIFICATIONS Order No. Micrometer ranges Remarks 156-101-10 Up to 100mm (4″)* Adjustable angle type 156-105-10 0-25mm (0-1″), 25-50mm (1″-2″) Fixed angle type 156-102 125-300mm (5″-12″) Vertical type 156-103 300-1000mm (12″-40″) Vertical type * Items that cannot […]

AUTHOR RATE
Mitutoyo-SERIES 157-Optical Parallels

Designed to inspect parallelism and flatness of measuring faces of micrometers. For details, refer to “Quick Guide to Precision Measuring Instruments”. Each set consists of 4 sizes to aid in testing parallelism at various angular positions of the micrometer spindle.   SPECIFICATIONS Metric Order No. Range of micrometer to be checked Sizes of parallels included in set Diameter […]

AUTHOR RATE
Mitutoyo-SERIES 167-Setting Standards for Screw Thread Micrometers

Used for accurately setting screw thread micrometers at the start or end of the measuring range. Metric Order No. Length Accuracy Metric (unified) 8 = 60° 167-261 25mm ±4µm 167-262 50mm ±5µm 167-263 75mm ±6µm 167-264 100mm ±7µm 167-265 125mm ±8µm 167-266 150mm ±9µm 167-267 175mm ±10µm 167-268 200mm ±11µm 167-269 225mm ±12µm 167-270 250mm […]

AUTHOR RATE
Mitutoyo-SERIES 167-Setting Standards for Outside Micrometers

Used for adjusting the reference point of the outside micrometer. SPECIFICATIONS and DIMENSIONS Metric Order No. Length  (L) Tolerance   Diameter  (D) 167-101 25mm ±1.5µm 18   6.35mm 167-102 50mm ±2.0µm 40 167-103 75mm ±2.5µm Inch Order No. Length  (L) Tolerance   Diameter  (D) 167-141 1″ ±.00005″ 18   .25″ 167-142 2″ ±.0001″ 40 167-143 […]

AUTHOR RATE
Mitutoyo-SERIES 155-Telescoping Gage Set

A spring-loaded plunger expands within a bore (or groove) and is locked in place, allowing measurement of diameter (or width) with an outside micrometer after extraction. SPECIFICATIONS Metric Order No. Range 6-gage Set 155-905 8 – 150mm Gages included 155-127 8 – 12.7mm 155-128 12.7 – 19mm 155-129 19 – 32mm 155-130 32 – 54mm […]

AUTHOR RATE
Mitutoyo-SERIES 154-Small Hole Gage Set

Extra long for gaging deep and shallow holes, slots, and similar workpiece features. Two sprung leaves are fully expanded inside a feature so that its size can be measured with an outside micrometer after extraction. SPECIFICATIONS Metric Order No. Range 4-gage Set 154-902   3 – 13mm Gages included   154-101 3 – 5mm 154-102 5 […]

AUTHOR RATE
Mitutoyo-SERIES 700-Quick-Mini

Lightweight and palm-sized. Highly suitable for quick dimensional inspection of small, thin and delicate objects. Functions: origin setting and zero-setting. Application examples Measurement of small objects: pearls, jewels, shims for engine tappets  and screws. Measurement of thin objects: printing paper, polyethylene bags,  sheet materials, foods including noodles, lenses for glasses, media substrates, foils, thin plates and medical products including filter […]

AUTHOR RATE
Mitutoyo-SERIES 146-Groove Micrometers

Flanged spindle and anvil for measuring width and location of grooves inside bores and tubes. Two-directional ratchet stop. For ID and OD (except for 0 – 25mm) measurement, a master gage is required for adjusting the reference point. SPECIFICATIONS Metric Order No. Range Outside Range Inside Graduation Accuracy Flange Rotating spindle 146-121 0 – 25mm […]

AUTHOR RATE
Mitutoyo-SERIES 523-Snap Meters

Suited to the measurement of massproduced parts. Various types of indicator can be selected according to the measurement application. Measuring faces: Carbide SPECIFICATIONS Metric Order No. Range Anvil movement Measuring force* Mass 523-141 0 – 25mm   2mm   5 – 10N 710g 523-142 25 – 50mm 810g 523-143 50 – 75mm 920g 523-144 75 – […]

AUTHOR RATE
Mitutoyo-SERIES 523-Dial Snap Meters

Suited to the measurement of massproduced parts. Designed for measurement using a stand: realizes stable measurement. Greatly improved accuracy: indication error and graduation of 1μm. Water-proof to protection level IP54. Hard-coated crystal: enhanced oil and scratch resistance. Indicator scale is large and easy-to-read. Easily settable adjustable limit markers for GO/±NG testing. Equipped with an elevating workpiece […]

AUTHOR RATE
Mitutoyo-SERIES 510-Indicating Micrometers

Suited to the measurement of low-volume manufactured parts. Easy to use when operating one-handed due to retractable anvil. In the 25mm measuring range, the model lineup offers a choice of left or right positioning of the anvil-retraction button. Greatly improved accuracy: indication error and graduation of 1μm. Water-proof to protection level IP54. Hard-coated crystal: enhanced oil and […]

AUTHOR RATE
Mitutoyo-SERIES 113-Limit Micrometers

Dual-spindle design enables use as a GO/±NG gage by setting upper and lower limits. Measuring faces: Carbide SPECIFICATIONS Metric Order No. Range Graduation Accuracy Flatness Parallelism 113-102 0 – 25mm 0.01mm ±3µm 0.6µm 3µm 113-103 25 – 50mm Technical Data Standard accessories: Reference bar, 1 pc (except for measuring range 0-25mm (0-1″) models) Spanner (200877), 1 […]

AUTHOR RATE
Mitutoyo-Series 317, 117 — Interchangeable Anvil Type-”Uni-Mike”

Measures tubing thickness, shoulderedge distance, rivet head height, etc., with interchangeable anvils (flat anvil, rod anvil, V-anvil). IP65 water/dust protection (series 317). Equipped with Ratchet Stop for constant  measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Digimatic  (LCD) 317-251-30 0 – 25mm 0.001mm ±4µm 317-252-30 25 – 50mm * Excluding quantizing error Inch/Metric Order No. […]

AUTHOR RATE
Mitutoyo-Series 342,112,142-Crimp Height Micrometers

Measures the height of crimp contacts. Equipped with Ratchet Stop for constant measuring force. IP65 water/dust protection (digital model). Model 342-451 is the Quickmike type, which provides a speedy spindle feed of 10mm per thimble rotation, which enables widely differently sized features to be measured quickly. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Digimatic  (LCD) 342-271-30 0 […]

AUTHOR RATE
Mitutoyo-Series 147-Wire Micrometers

Designed for measuring wire thickness. Measurable wire dia.: 10mm or less Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Graduation Accuracy 147-401 0 – 10mm 0.01mm ±3µm Inch Order No. Range Graduation Accuracy 147-402 0 – .4″ .0001″ ±.00015″ DIMENSIONS Technical Data Flatness: 0.6μm/.000024” Parallelism: 1.3μm/.00005” Standard […]

AUTHOR RATE
Mitutoyo-SERIES 147-Hub Micrometers

Measures hub thickness and shoulders inside a bore. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Graduation Accuracy 147-301 0 – 25mm   0.01mm   ±2µm 147-302 25 – 50mm 147-303 50 – 75mm 147-304 75 – 100mm ±3µm Inch Order No. Range Graduation Accuracy 147-351 0 – […]

AUTHOR RATE
Mitutoyo-SERIES 147-Can Seam Micrometers

 Measures the width, height, and depth of can seams. SPECIFICATIONS Metric Order No. Range Graduation Accuracy Remarks 147-103   0 – 13mm   0.01mm   ±3µm for steel cans 147-105 for aluminum cans 147-202 for spray cans Inch Order No. Range Graduation Accuracy Remarks 147-104   0 – .5″   .001″   ±.00015″ for steel […]

AUTHOR RATE
Mitutoyo-SERIES 422, 122 – Non-Rotating Spindle Type-Blade Micrometers

The anvil and spindle are blade-shaped for measuring the groove diameter of shafts, keyways, and other hard-to-reach features. Carbide-tipped measuring faces are also available Non-rotating spindle type. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Remark Digimatic  (LCD) 422-230-30 0 – 25mm       0.001mm   ±3µm   […]

AUTHOR RATE
Mitutoyo-SERIES 314, 114-3 Flutes and 5 Flutes-V-Anvil Micrometers

Measures the outside diameter of cutting tools (such as taps, reamers, end mills) which have three or five flutes. Measures pitch diameter: refer to “Quick Guide to Precision Measuring Instruments” on page B-73. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric For 3-flute cutting tools Order No. Range Resolution Accuracy* […]

AUTHOR RATE
Mitutoyo-SERIES 342, 142, 112-Point Micrometers

Pointed spindle and anvil for measuring the web thickness of drills, small grooves, keyways, and other hard-to-reach features. The measuring points (carbide tipped) have approximately 0.3mm radius. series 342: IP65 Digimatic micrometers Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Point Digimatic (LCD) (With carbide tip) 342-251-30 0 […]

AUTHOR RATE
Mitutoyo-SERIES 331, 111, 131-Spline Micrometers

The anvil and spindle are of small diameter for measuring splined shafts, slots, and keyways. IP65 water/dust protection (series 331). Measuring faces: Carbide. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Remarks Digimatic  (LCD) 331-251-30 0 – 25mm       0.001mm   ±2µm   Type A 331-252-30 25 […]

AUTHOR RATE
Mitutoyo-SERIES 395, 115, 295 — Spherical and Cylindrical Anvil Type-Tube Micrometers

Spindle face: Carbide series 395: IP65 spherical and cylindrical anvil type digital micrometers Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Remarks Digimatic  (LCD) 395-261-30   0 – 25mm   0.001mm   ±3µm Type A 395-262-30 Type B 395-263-30 Type C 395-264-30 Type D * Excluding quantizing error […]

AUTHOR RATE
Mitutoyo-SERIES 395, 115, 295 — Spherical Anvil and Spindle Type-Tube Micrometers

Measuring faces: Carbide (115-201: only the spindle is carbide tipped.) Series 395: IP65 spherical anvil and spindle type digital micrometer. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* 0D Digimatic  (LCD) 395-271-30 0 – 25mm   0.001mm   ±2µm 015 395-272-30 25 – 50mm 395-273-30 50 – 75mm 019 […]

AUTHOR RATE
Mitutoyo-SERIES 395, 115, 295-Tube Micrometers

Measuring faces: Carbide (115-101: only the spindle is carbide tipped.) series 395: IP65 digital spherical-flat anvil  type micrometer. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* 0D Digimatic  (LCD) 395-251-30 0 – 25mm   0.001mm   ±2µm 015 395-252-30 25 – 50mm 395-253-30 50 – 75mm 019 395-254-30 75 […]

AUTHOR RATE
Mitutoyo-SERIES 119-Sheet Metal Micrometer

Large diameter dial model enables easy and quick measurement of sheet metal thickness. Adjustable anvil. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Order No. Range Graduation Accuracy Throat depth 119-202 0 – 25mm 0.01mm ±4µm 50mm DIMENSIONS Technical Data Standard accessories: Spanner (200168), 1 pc

AUTHOR RATE
Mitutoyo-SERIES 389, 118-Sheet Metal Micrometers

Measures thickness of sheet metal. IP65 water/dust protection (series 389). Measuring faces: Carbide Profile of measuring faces: Flat-Flat, Spherical-Flat and Spherical-Spherical. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Throat depth Measuring surfaces Digimatic  (LCD) 389-251-30   0 – 25mm       0.001mm   ±4µm   150mm […]

AUTHOR RATE
Mitutoyo-SERIES 369, 227, 169 — Non-Rotating Spindle Type-Disk Micrometers

Measures “root tangent length” of spur gears and helical gears. Determination of the root tangent length: refer to “Quick Guide to Precision Measuring Instruments”. Non-rotating spindle type. Measurable range of gear pitch: 0.5 to 6 module (series 227: 0.4 to 3 module). Equipped with Ratchet Stop for constant measuring force. Supplied with a setting standard […]

AUTHOR RATE
Mitutoyo-SERIES 324, 124 — Interchangeable Ball Anvil / Spindle Tip Type-Gear Tooth Micrometers

Measures over-pin diameter of gears using precision steel (or carbide) ball anvils / spindle tips. Series 324: IP65 Digimatic gear tooth micrometers. Determination of the over-pin diameter: refer to “Quick Guide to Precision Measuring Instruments”. Interchangeable ball anvils / spindle tips for various gear modules (0.5-5.25) are optional. Equipped with Ratchet Stop for constant measuring […]

AUTHOR RATE
Mitutoyo-SERIES 323, 223, 123-Disk Micrometers

Measures “root tangent length” of spur gears and helical gears. Determination of the root tangent length: refer to “Quick Guide to Precision Measuring Instruments”. Equipped with Ratchet Stop for constant measuring force. Supplied with a setting standard (except for 0-25mm/0-1” measuring range).   SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Anvil dia. Measurable module Digimatic […]

AUTHOR RATE
Mitutoyo-SERIES 169 – Non-Rotating Spindle Type-Paper Thickness Micrometers

• For paper thickness measurement. • Non-rotating spindle. • Equipped with Ratchet Stop for constant measuring force. (8.02±0.8N) SPECIFICATIONS Order No. Range Graduation Accuracy Flatness Parallelism 169-101 0 – 25mm 0.01mm ±4µm 1µm 3µm   Order No. Range Graduation Accuracy Flatness Parallelism 169-103 0 – 1″ .001″ ±.0002″ .00004″ .00015″ DIMENSIONS Anvil dimensions Technical Data Standard […]

AUTHOR RATE
Mitutoyo-SERIES 313-3-Wire Units

• Enables measurement of the pitch diameter of screw threads with a standard micrometer. • Determination of the pitch diameter: refer to “Quick Guide to Precision Measuring Instruments”. SPECIFICATIONS 3-Wire Units set Order No. Set Wire dia. (mm) Support spindle dia. (mm) 313-101 18 0.170 – 3.200 06.35 Order No. (One pair) (Support spindle dia.) 06.35mm […]

AUTHOR RATE
Mitutoyo-SERIES 116 – Interchangeable Anvil Type-Universal Micrometer

Non-rotating spindle type which accepts seven forms of optional interchangeable anvil / spindle tip (flat, spline, spherical, point, knife-edge, disk, and blade) for a wide range of applications. Equipped with Ratchet Stop for constant measuring force. Optional anvils / spindle tips for screw thread measurement (matching V and cone) are also available. SPECIFICATIONS Metric Order No. Range […]

AUTHOR RATE
Mitutoyo-SERIES 326, 126 – Interchangeable Anvil / Spindle Tip Type-Screw Thread Micrometers

Anvils and spindle tips are interchangeable in matching pairs to enable measurement of Metric/Unified or Whitworth threads. Direct reading of screw pitch diameter (no need for calculation) Equipped with Ratchet Stop for constant measuring force. Interchangeable anvils / spindle tips are optional. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Digimatic  (LCD) 326-251-30 0 – 25mm   […]

AUTHOR RATE
Mitutoyo-SERIES 125-Screw Thread Micrometers

Fixed anvil type to suit 60º threads Directly indicates screw pitch diameter (no need for calculation) Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Thread to be measured (Metric/nnified) Range Graduation 125-101 0.4 – 0.5mm/64  – 48TPI     0 – 25mm           0.01mm 125-102 0.6 – […]

AUTHOR RATE
Mitutoyo-SERIES 343, 143-Caliper Type Micrometers

Effective for measuring workpiece features where access is difficult. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Digimatic  (LCD) 343-250-30 0 – 25mm   0.001mm ±5µm 343-251-30 25 – 50mm ±6µm 343-252-30 50 – 75mm ±7µm 343-253-30 75 – 100mm ±8µm * Excluding quantizing error […]

AUTHOR RATE
Mitutoyo-SERIES 105 — with Anvil Extension Collars-Outside micrometers

Wide measuring range with anvil extension collars 50mm/2” spindle stroke Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Graduation Extension Collars Setting Standard (pcs) (every 100mm) 105-408 1000 – 1100mm           0.01mm           1 pc (50mm)       […]

AUTHOR RATE
Mitutoyo-SERIES 105 — with Anvil Extension Collars-Outside micrometers

Adjustable measuring range with extension collars. 50mm/2” spindle stroke Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Order No. Range Graduation Extension Collars Setting Standard 105-103 500 – 600mm     0.01mm     1 pc (50mm)     2 pcs. 105-104 600 – 700mm 105-105 700 – 800mm 105-106 800 – 900mm […]

AUTHOR RATE
Mitutoyo-SERIES 340, 104 — with Interchangeable Anvils-Outside Micrometers

Wide measuring range with interchangeable anvils. Measuring face of the spindle is carbide tipped (standard model). IP 65 water/dust protection (series 340). * Models with a measuring range up to 300mm. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No.   Range   Resolution   Interchangeable anvils Setting Standard   Micrometer head stroke Qty […]

AUTHOR RATE
Mitutoyo-SERIES 107-Indicator Type Micrometers

Designed to mount a dial indicator for direct GO/±NG judgment on mass-produced parts. Anvil retracting trigger for quick measurement. Various kinds of indicators*1 are selectable depending on the measurement type (accuracy required, measuring range, etc.). Measuring faces: Carbide Anvil stroke: 3mm SPECIFICATIONS Metric Order No. Range Accuracy 107-201 0 – 25mm   ±2µm 107-202 25 – 50mm 107-203 […]

AUTHOR RATE
Mitutoyo-SERIES 406-Digimatic straight line micrometer outside micrometer

Non-rotating spindle. Equipped with Ratchet Stop for constant measuring force. Metric Order No. Range Resolution Accuracy* Flatness Parallelism 406-250-30 0 – 25mm     0.001mm   ±3µm     0.3µm   3µm 406-251-30 25 – 50mm 406-252-30 50 – 75mm 406-253-30 75 – 100mm ±4µm 4µm   * Excluding quantizing error Inch/Metric Order No. Range […]

AUTHOR RATE
Mitutoyo-SERIES 193-Digit Outside Micrometers

Mechanical digit counter with 0.01mm or .001” resolution for quick and error-free reading. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric With ratchet stop Order No. Range Graduation Accuracy 193-101 0 – 25mm 0.01mm     ±2µm 193-111 0.001mm 193-102   25 – 50mm 0.01mm 193-112 0.001mm 193-103   50 – […]

AUTHOR RATE
Mitutoyo-SERIES 101-Outside Micrometers

Satin-chrome-finished frame, tapered (on the anvil side) for hard-to-reach places. Supplied with a setting standard (except for 0-1” models). Measuring faces: Carbide SPECIFICATIONS Inch With ratchet stop Order No. Range Graduation Accuracy 101-113 0 – 1″     .0001″   ±.0001″ 101-114 1″ – 2″ 101-119 2″ – 3″ 101-120 3″ – 4″ ±.00015″ Inch With friction […]

AUTHOR RATE
Mitutoyo-SERIES 103-Outside Micrometers

Baked-enamel-finished frame. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. Metric  With ratchet stop Order No. Range Graduation Accuracy 103-137 0 – 25mm 0.01mm     ±2µm 103-129 0.001mm 103-138 25 – 50mm 0.01mm 103-130 0.001mm 103-139-10 50 – 75mm                         […]

AUTHOR RATE
Mitutoyo-SERIES 102 — Outside Micrometers-Ratchet Thimble Micrometer

More accurate in one-handed operation: inexperienced operators measure significantly more accurately with the new micrometer. Ratchet function works both from the thimble and the speeder. Rotating the thimble/speeder when the workpiece is between the anvil and spindle causes the ratchet mechanism to operate and apply a constant measuring force to the workpiece. Clearly audible ratchet operation […]

AUTHOR RATE
Mitutoyo-SERIES 102-Outside Micrometers

Heat-insulated frame. Cut-away frame (behind anvil) for measuring in hard-to-reach places. A ratchet stop or a friction thimble for a constant measuring force. Measuring faces: Carbide       SPECIFICATIONS Metric Order No. Range Graduation Accuracy Flatness Parallelism Constant-force device 102-301   0 – 25mm 0.01mm ±2µm 0.6µm 2µm Ratchet stop 102-311 0.001mm ±1µm 0.3µm […]

AUTHOR RATE
Mitutoyo-SERIES 227-with Adjustable Measuring Force-ABSOLUTE Digimatic Micrometers

Digimatic micrometer dedicated to applications requiring a constant/low measuring force such as measuring wire, paper, and plastic/rubber parts. Ratchet mechanism in the thimble applies constant force to workpiece. Compact and easy to handle. Measuring force is adjustable (in steps) to suit various kinds of workpiece. High-accuracy measurement can be performed even by unskilled operators due to […]

AUTHOR RATE
Mitutoyo-SERIES 293-IP54 ABSOLUTE Digimatic Micrometers-Quickmike

The Quickmike provides a speedy spindle feed of 10mm per thimble rotation, which enables widely differently sized features to be measured quickly. Set the origin only once. The absolute linear scale maintains the origin throughout the life of battery, meaning no more zero setting (presetting) or overspeed error. Measuring faces: Carbide Supplied with a Ratchet […]

293-582
AUTHOR RATE
Mitutoyo-SERIES 293-Digimatic outside micrometers

Models equipped with a Digimatic output port can form part of a statistical process control or networked measurement system. (Refer to page A-3 for details.) Constant-force device: ratchet stop Interface Input Tools are available that enable the conversion of measurement data to keyboard signals that are then directly input to cells in off-the-shelf spreadsheet software such as […]

AUTHOR RATE
Mitutoyo-SERIES 293 — with Dust/Water Protection Conforming to IP65 Level -Coolant Proof Micrometers

World’s highest performing micrometer overall. Extended battery life of approximately 2.4 years. Ergonomic anti-slip frame cover and front panel for more comfortable hand-held measurements. Ratchet thimble provides better operability for one-handed operation. Oil-resistant material used for all plastic parts. Models equipped with a Digimatic output port can form part of a statistical process control or […]

293-140
AUTHOR RATE
Mitutoyo-SERIES 293 — IP65 Micrometer with 2mm/rev Spindle Feed-QuantuMike

Advanced pioneering technology has created the next generation of micrometer, the most revolutionary advance in micrometer technology since James Watt invented the instrument. Faster measurement is achieved by using a coarser thread which feeds the spindle by 2mm per revolution of the thimble. This increase in thread lead has been made possible thanks to new high precision threadcutting […]

293-100
AUTHOR RATE
Mitutoyo – SERIES 293 – High-Accuracy Digimatic Micrometer

Enabling 0.1μm resolution measurement, this micrometer is ideal for customers who need to make highly accurate measurements with a hand-held tool. The High-Accuracy Digimatic Micrometer utilizes Mitutoyo’s innovative 0.1μm resolution ABS (absolute) rotary sensor*1 and high-accuracy screw machining technology to reduce the instrumental error to ±0.5μm, delivering higher accuracy without sacrificing operability. *1. Patent pending […]

AUTHOR RATE
Mitutoyo SERIES 192 – Multi-function Type with SPC Data Output – Digimatic Height Gage

Double-column structure ensures high measuring accuracy. Ergonomic base fits comfortably in the hand. Bidirectional touch-trigger probe is available as an optional accessory. Character height of the LCD display has been increased (10mm to 11mm) and a high- contrast LCD display unit adopted, so that the readability is improved. Inclined handle improves slider ergonomics. Allows integration into statistical […]

Gokul Traders Copyright © 2010-18 Developed by Shades Of Web. All rights reserved.
