INSIZE PENCIL HARDNESS TESTER (CODE PHT-C751)

INSIZE PENCIL HARDNESS TESTER (CODE PHT-C751)

Product Overview

The INSIZE PHT-C751 is a precision instrument designed for testing the hardness of flat coating surfaces. This tester ensures consistent results by maintaining a fixed 45° angle between the pencil and the measured surface, conforming to international testing standards.

Key Features & Capabilities

• Standard Compliance: Conforms to ASTM D3363, ISO 15184, BS3900-E19, and ECCA-T4/1 standards.
• Adjustable Pressure: The unit allows for variable pressure settings (500g, 750g, and 1000g) using the included weights.
• Application: Specifically engineered for use on flat coating surfaces.

Technical Specifications

Standard Delivery

• Main unit (1 pc)
• Weights (2 pcs)
• Leveling rod (1 pc)
• Level (1 pc)
• Pencils (12 pcs: 4B, 3B, 2B, B, HB, F, H, 2H, 3H, 4H, 5H, 6H)
• Pencil sharpener (1 pc)

Optional Accessories

• Pencil set (12 pcs: 4B-6H): PHT-C751-P
• 400 grade abrasive paper: PHT-C751-S
