| Application | For fine sand mould/core in manual or mechanical low and medium pressure molding | For fine and coarse sand mould/core in manual or mechanical low and medium pressure molding | For sand mold in high pressure molding |
| Indenter | Ball radius 2.50mm | Ball radius 12.70mm | Ball radius 1.20mm |
| Load | 237g | 980g | 1500g |
| Pressure Load | 90g | 50g | 180g |
| Measurement Unit | HA | HB | HC |
| Measurement Range | 10 ~ 90H (A/ B/ C), display range is 0 ~ 100H | 10 ~ 90H (A/ B/ C), display range is 0 ~ 100H | 10 ~ 90H (A/ B/ C), display range is 0 ~ 100H |
| Resolution | 0.1H | 0.1H | 0.1H |
| Accuracy | ±1H | ±1H | ±1H |
| Operating Conditions | Temp: 0~40°C, Humidity <80% RH | Temp: 0~40°C, Humidity <80% RH | Temp: 0~40°C, Humidity <80% RH |
| Dimensions & Weight | 176 x 65 x 27mm, approx. 170g | 176 x 65 x 27mm, approx. 170g | 176 x 65 x 27mm, approx. 170g |
| Power Source | 2 x 1.5V AA batteries | 2 x 1.5V AA batteries | 2 x 1.5V AA batteries |
| Standard Accessories | Main unit, manual, case | Main unit, manual, case | Main unit, manual, case |
| Optional Accessories | Data logging: PC interface (USB & software), Bluetooth | Data logging: PC interface (USB & software), Bluetooth | Data logging: PC interface (USB & software), Bluetooth |
