• Sliding spindle
  • High contrast analog display
  • Stainless spindle is hardened throughout and ground
  • Spindle and anvil are carbide tipped
  • Rapid drive
  • Ratchet is integrated in the thimble
  • Lacquered steel frame, heat insulated
  • Digimatic
  • Opto RS232C
  • USB
  • IP 52
  • battery
  • instruction manual
  • case

Height of Digit

  • 8.5mm



Technical Data

Order no. Measuring range mm Measuring range inches Resolution mm/inch Error limit µm Spindle diameter Spindle thread pitch_mm Measuring force (N)
4151724
0 – 25
0 – 1″
0.001 / .00005″
4 µm
6.5 mm
0.635 mm
5 – 10

Functions

  • RESET (set display to zero)
  • ABS (display can be set to zero without losing reference to preset)
  • mm/inch
  • PRESET (for entering a numerical value)
  • DATA (data transmission via connection cable)
  • LOCK function (key lock)
