MILLIMESS 2001 INDUCTIVE DIGITAL COMPARATOR

High contrast LCD Analog display with 4 mm pointer ensures better visual recognition, ideal when checking concentricity or flatness as well as searching for the reversal point when measuring bores Operating and display unit (bezel) can be rotated through 280° Mounting shank and measuring spindle are both made of hardened stainless steel Measuring spindle is
  • High contrast LCD
  • Analog display with 4 mm pointer ensures better visual recognition, ideal when checking concentricity or flatness as well as searching for the reversal point when measuring bores
  • Operating and display unit (bezel) can be rotated through 280°
  • Mounting shank and measuring spindle are both made of hardened stainless steel
  • Measuring spindle is mounted in a high precision ball guide for minimal hysteresis
  • Linearized inductive absolute measuring system
  • Measuring force spring is interchangeable
  • Lower stop is adjustable
 Comparator
 Comparator  Comparator  Comparator  Comparator  Comparator Comparator

Technical data

Order no. Product type Measuring range mm Measuring range inch Measuring range 1 _beginning_ mm Measuring range 1 _end mm Measuring range 1 _beginning_inch Measuring range 1 _end inch Resolution Resolution Standard Minimum measuring force Maximum measuring force Height of digits Range of analog display mm Range of analog display inches IP protection category
4346100
2001
± 0.9
± .035″
-0.4 mm
0.4 mm
-0.015 inch
0.015 inch
0.001 mm / 0.001 mm / 0 mm
0 inch / 0 inch / 0 inch
Factory standard
0.7 N
0.9 N
6.5 mm
± 0,030 / ± 0,015 / ± 0,006
± .0015″ / ± .0006″ / ± .0003”
IP 54
4346910
2001
± 0.9
± .035″
-0.4 mm
0.4 mm
-0.015 inch
0.015 inch
0.001 mm / 0.001 mm / 0 mm
0 inch / 0 inch / 0 inch
Factory standard
0.7 N
0.9 N
6.5 mm
± 0,030 / ± 0,015 / ± 0,006
± .0015″ / ± .0006″ / ± .0003”
IP 54
4346911
2001
± 0.9
± .035″
-0.4 mm
0.4 mm
-0.015 inch
0.015 inch
0.001 mm / 0.001 mm / 0 mm
0 inch / 0 inch / 0 inch
Factory standard
0.7 N
0.9 N
6.5 mm
± 0,030 / ± 0,015 / ± 0,006
± .0015″ / ± .0006″ / ± .0003”
IP 54

Functions

  • ON/OFF
  • RESET (set display to zero)
  • 0 (set the analog display to zero)
  • PRESET (for entering a numerical value)
  • mm/inch
  • Reversal of counting direction
  • RANGE (switch the measuring range and resolution)
  • ABS (reference to the electrical zero point)
  • MAX/MIN memory for searching the reversal point
  • TIR (MAX-MIN) for testing flatness and concentricity
  • TOL (enter tolerance limit values)
  • Factor (adjustable)
  • Remote controlled via interface (optoRS232/USB)
