INSIZE AC DIGITAL CLAMP METER 9243-CA600

Name: INSIZE AC DIGITAL CLAMP METER 9243-CA600
Brand: INSIZE
SKU: 600V

Code:

Description: Auto/manual ranging Maximum mode Data hold Display backlight Work light Low battery display Auto power off Safety rating: CAT Ill 600V Specification: Function Range Resolution Accuracy DC Voltage 200mV/2V/20V/200V 0.1mV/1mV/10mV/0.1V ±(0.8%+2) 600V 1V ±(1.0%+2) AC Voltage 2V/20V/200V 1mV/10mV/0.1V ±(1.0%+5) 600V 1V ±(1.2°/0+5) AC Current 2A(50.5A) 1mA ±(3.5%+20) 2A 1mA ±(3.0%+10) 20A 10mA ±(3.0%+10) 200A

f in

Click to Expand

INSIZE AC DIGITAL CLAMP METER 9243-CA600

Product Overview

The INSIZE AC Digital Clamp Meter (Model: 9243-CA600) is a professional-grade testing instrument designed for accurate electrical measurements. Engineered for safety and precision, it features auto/manual ranging, a bright display backlight, and an integrated work light for optimal visibility in industrial and commercial environments.

Key Features & Capabilities

Auto/Manual Ranging: Offers flexible measurement control for streamlined operation.
Maximum Mode: Captures and displays peak readings during testing.
Data Hold: Freezes the current reading on the display for easy recording.
Display Backlight & Work Light: Enhances visibility in low-light workspaces.
Power Management: Includes a low battery indicator and auto power-off function to preserve battery life.
Safety Rating: Certified to CAT III 600V safety standards.

Technical Specifications

Function	Range	Resolution	Accuracy
DC Voltage	200mV / 2V / 20V / 200V	0.1mV / 1mV / 10mV / 0.1V	±(0.8% + 2)
	600V	1V	±(1.0% + 2)
AC Voltage	2V / 20V / 200V	1mV / 10mV / 0.1V	±(1.0% + 5)
	600V	1V	±(1.2°/0 + 5)
AC Current	2A (50.5A)	1mA	±(3.5% + 20)
	2A	1mA	±(3.0% + 10)
	20A	10mA	±(3.0% + 10)
	200A	0.1A	±(2.5% + 10)
	600A	1A	±(1.5°/0 + 5)
Resistance	200Ω / 2kΩ / 20kΩ / 200kΩ / 2MΩ	0.1Ω / 10Ω / 100Ω / 0.1kΩ / 1kΩ	±(1.2% + 2)
	20MΩ	10kΩ	±(2.0% + 5)
Diode Test	Open circuit voltage 1.5V	—	—
Continuity Buzzer	<50Ω	—	—
