INSIZE DIGITAL SURFACE PROFILE GAGE (CODE – 2844-10)

Code:

▪Measure peak-to-valley height of blast cleaned surface.
▪If the profile is too low, the adhesion of the coating to the surface will be reduced.
▪If the profile is too high, there is the danger that the profile peaks will remain uncoated, allowing rust spots to occur.
▪Meet ASTM D 4417-B
▪Zero set block is included, set zero before measurement
▪Button function: tolerance Go and No-Go display, data preset, measuring direction change, max./min./TIR measurement, inch/metric conversion, absolute/incremental measurement
▪CR2032 battery
▪Automatic power off (time is adjustable)
▪Data output
▪Stainless steel base
▪Optional accessory: data output cable
▪(code 7315-50M)

Click to Expand

INSIZE DIGITAL SURFACE PROFILE GAGE (CODE – 2844-10)

Product Overview

The INSIZE Digital Surface Profile Gage (Code 2844-10) is a precision instrument designed to measure the peak-to-valley height of blast-cleaned surfaces. It ensures optimal surface preparation for coating applications, preventing issues related to poor adhesion (if the profile is too low) or uncoated peaks leading to rust (if the profile is too high). This gage complies with ASTM D 4417-B standards.

Key Features & Capabilities

Measurement Functions: Includes tolerance Go/No-Go display, data preset, measuring direction change, max./min./TIR measurement, inch/metric conversion, and absolute/incremental measurement.
Calibration: Supplied with a zero set block for pre-measurement calibration.
Construction: Features a durable stainless steel base.
Power Management: Powered by a CR2032 battery with an adjustable automatic power-off function.
Data Connectivity: Equipped with data output capabilities.
Optional Accessories: Data output cable (Code 7315-50M).

Technical Specifications

Parameter	Specification
Code	2844-10
Range	0-12.7mm / 0-0.5"
Digital Indicator Stroke	12.7mm / 0.5"
Digital Indicator Resolution	0.001mm / 0.00005"
Accuracy	±0.005mm
Standard Compliance	ASTM D 4417-B
