INSIZE VIDEOSCOPE (CODE ISV-E40)

Product Overview

The INSIZE ISV-E40 is a professional-grade mobile phone videoscope designed for high-precision visual inspection. This unit integrates with Android and iOS mobile devices to provide clear, real-time imaging for industrial maintenance and diagnostic tasks.

Key Features & Capabilities

Mobile Integration: Compatible with both Android and iOS mobile operating systems.
Flexible Inspection: Features a manual joystick for precise lens bending in any direction, with a bending range of 0–180°.
Adjustable Illumination: Equipped with an integrated LED light source featuring three levels of brightness control.
Durable Design: Constructed with a wear-resistant cable for demanding industrial environments.
Portable Power: Includes a built-in rechargeable battery providing up to 2 hours of continuous operation.

Technical Specifications

Parameter	Specification
Diameter of lens (ØD)	6±0.2 mm
Length of cable	1m
Resolution	960×720, 1280×720 (switchable)
Depth of field	20mm~∞
Angle of view (θ)	100°
Bending range (α)	0~180°
Illumination	LED with 3 levels control
Cable type	Wear resistant
Interface	USB, Type-C
Mobile phone system	Android, IOS
Power supply	Rechargeable battery (2 hours working)
Dimension (L×W×H)	195×57×105 mm
Weight	450g
