MICROMAR 40 AW MICROMETER

Name: MICROMAR 40 AW MICROMETER
Brand: Mahr
SKU: 4134300

Code:

Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device Sliding spindle instruction manual case Technical Data Order no. Measuring range mm Graduation value mm Error limit µm Parallel error in µm Flatness in µm

f in

Click to Expand

MICROMAR 40 AW MICROMETER

Product Overview

The Mahr Micromar 40 AW Micrometer (Order No. 4134300) is a precision measuring instrument designed with a measuring range of 0 to 25 mm. Engineered with a hard lacquered steel frame and equipped with operating and display units featuring a satin chrome finish, this micrometer delivers reliable metrological performance for industrial measurement applications.

Key Features & Capabilities

Construction: Hard lacquered steel frame with satin chrome finish on operating and display units.
Anvil & Spindle: Hardened steel spindle and anvil, carbide tipped for enhanced durability and wear resistance.
Drive System: Rapid drive with integrated ratchet mechanism for consistent measuring force.
Precision Control: Includes a locking device and sliding spindle.
Thermal Protection: Fitted with heat insulators to minimize thermal expansion from hand warmth.
Inclusions: Supplied with an instruction manual and protective case.

Technical Specifications

Technical Parameter	Specification
Order No. / SKU	4134300
Model	Micromar 40 AW
Measuring Range	0 – 25 mm
Graduation Value	0.01 mm
Error Limit	8 µm
Parallel Error	5 µm
Flatness	2 µm
Spindle Thread Pitch	0.5 mm
Measuring Force	5 – 10 N
