• High contrast analog display
  • Stainless spindle is hardened throughout and ground
  • Spindle and anvil are carbide tipped
  • Rapid drive
  • Ratchet is integrated in the thimble
  • Lacquered steel frame, heat insulated
  • ntegrated wireless
  • Battery life approx. 2 years (approx. 0.5 in wireless mode)
  • IP 65
  • instruction mnual
  • battery
  • setting values
  • case

Height of Digits

  • 10 mm



Technical Data

Order no. Measuring range mm Measuring range inches Resolution mm/inch Spindle diameter Spindle thread pitch_mm Measuring force (N)
4157115
0 – 100
0 – 4″
0.001 / .00005″
6.5 mm
0.5 mm
5 – 10

Functions

  • RESET (set display to zero)
  • ABS (display can be set to zero without losing reference to ORIGIN)
  • mm/inch
  • ORIGIN (for entering a numerical value)
  • LOCK function (key lock)
  • TOL (Tolerance and warning limits)
  • DATA (data transmission)
  • HOLD (storage of measured values)
