NOGA D AND T SCRAPERS BLADES

Code:

▪Scrapers are used mostly in the metalworking industries, to remove irregular surface defects and high spots on previously machined parts. The scrapers remove very little material, but create a smooth surface.
▪Noga supplies a great variety of scrapers mostly used for finishing interior and concave surfaces. Most of the scrapers are made having a triangular cross section, obtaining three cutting edges, but also special scrapers are available for deburring the internal ridges created by the break-through of holes drilled into pipes or bushings.
▪For effective working on various materials, Noga scrapers are made out of either alloy tool steel, high speed steel or solid tungsten carbide. The scrapers are made in many diameters, as to facilitate working in holes of various diameters, and different length for shallow or deep holes. Every tool consists of a scraper blade, gripped either directly in a convenient handle, or in a blade-holder which fits into an appropriate handle.
▪Noga Adjustable scraper (SC8000) is ideal for scraping, trimming and deburring almost all materials. Special slim-grip design for deburring in hard to reach location. Knurled locking collar to control blade extention.Includes 12mm anodized handle and T80 double ended triangular scraper. This handle can hold D55 carbide blade, D75 mini scraper blade and D66 internal scraper blade.
▪Noga Mini Scraper (NG3700) is ideal for tool and dies makers and includes NG-3 handle, D Holder and triangular mini scraper D50 blade. Blade D50 is secured to D holder with a set screw.
▪Noga new Scraper set (YT2000)/a combination of two scrapers and one new YT handle creates the world’s best scraper set. Most economical set. Ideal for machinists and tool/die makers. Includes a unique new YT handle that fits comfortably into every hand, Hollow ground H.S.S D75 triangular adjustable mini scraper and T80 double ended triangular adjustable scraper.
▪Noga Internal Scraper (NG3710) is ideal for cross-holes deburring and includes NG-3 handled holder and D66 internal blade. 66 blades are held in D Holder by a set screw.

Click to Expand

NOGA D AND T SCRAPERS BLADES

Product Overview

The Noga D and T Scraper Blades line comprises a comprehensive range of high-performance triangular and specialized scraper blades designed for deburring, trimming, and finishing applications. Available in various materials, sizes, and configurations, these blades are engineered for use with Noga tool handles and blade holders to accommodate shallow holes, deep holes, cross-holes, and hard-to-reach locations across diverse industrial materials.

Key Features & Capabilities

Diverse Blade Geometry & Construction: Includes mini triangular scraper blades, standard triangular scraper blades, double-ended medium triangular scraper blades, and specialized internal scraper blades for cross-holes deburring.
Material Variants: Manufactured from high-speed steel (H.S.S.), solid tungsten carbide, and CR115 tool steel to suit standard and heavy-duty applications.
Precision Compatibility: Designed to integrate securely with Noga handles (such as NG-3, SC, and YT series) and dedicated holders (D Holder and TN Holder).

Technical Specifications

Blade Model	Order No.	Blade Material	Hardness	Width x Length (mm)	Angle (Degrees)	Package Weight (g)	Package Quantity
D50	BD5010	H.S.S.	62–64 Rc	2.5 x 50	60	37	10
D50TiN	BD5012	H.S.S.	62–64 Rc	2.5 x 50	60	37	10
D55 Carbide	BD5501	Carbide	1400–1700 HV	2.5 x 50	60	9	1
D66	BD6610	H.S.S.	62–64 Rc	2.7 x 50	50	44	10
D75	BD7501	H.S.S.	62–64 Rc	2.5 x 75	60	8	1
D77	BD7701	H.S.S.	62–64 Rc	2.7 x 75	50	9	1
T40	BT4001	CR115	58–60 Rc	4.2 x 40	60	7	1
T60	BT6001	CR115	58–60 Rc	7.4 x 60	60	11	1
T80	BT8001	CR115	58–60 Rc	4.2 x 80	60	11	1
T120	BT1200	CR115	58–60 Rc	7.4 x 120	60	24	1

Additional Technical Notes

Material Hardness Standards:
H.S.S. Blades: Hardness 62–64 Rc
Carbide Blades (D55): 1400–1700 HV
CR115 Blades (T80, T120, and single-ended T series variants): 58–60 Rc
Holder Compatibility:
D Holder (EL05003): Holds D scraper blades using a 3 mm setscrew. Allen key included. Length: 131 mm.
TN Holder (EL0608): Holds T40 and T60 scraper blades. Features NF10 internal thread. Length: 113 mm.
