Product Overview

The INSIZE Digital Horizontal Scales (Code 7101) are precision non-waterproof measuring instruments constructed from durable stainless steel. Available in two distinct button configurations (Type A and Type B) across a wide range of measuring lengths, these scales feature an automatic power-off function and data output capabilities. Each unit is supplied with a mounting bracket designed for rear installation.

Key Features & Capabilities

• Non-Waterproof Construction: Built for standard workshop environments.
• High Resolution: 0.01mm / 0.0005" resolution for precision measurements.
• Control Buttons:
• Type A: on/off, zero, mm/inch
• Type B: on/off, zero, mm/inch, ABS, data preset
• Power Management: Automatic power off with automatic power-on triggered by moving the digital unit.
• Power Source: Powered by a CR2032 battery.
• Data Interface: Equipped with data output (optional data output cables: 7315-21, 7302-21, 7305-21 for Type A; 7315-22, 7302-22, 7305-22 for Type B).
• Material: Made of stainless steel.
• Mounting: Supplied with a bracket to be mounted on the back.

---

Technical Specifications

Type A Models (With data interface, cable codes 7315-21, 7302-21, 7305-21 optional)

---

Type B Models (With data interface, cable codes 7315-22, 7302-22, 7305-22 optional)
