INSIZE DIGITAL REFRACTOMETER ISQ-DRM31

Name: INSIZE DIGITAL REFRACTOMETER ISQ-DRM31
Brand: INSIZE
SKU: DRM31

Code:

Description: Quickly measure the concentration of coolant Two measurement modes: single measurement and automatic average multiple measurement Two units: brix and refractive index Refer to the refraction factor of coolant, for example: the refraction factor of grinding emulsion is 2.1, the reading value is 6%, so the actual concentration is (2.1×6%)=12.6% Automatic power off Specification:

f in

Click to Expand

INSIZE DIGITAL REFRACTOMETER ISQ-DRM31

Product Overview

The INSIZE ISQ-DRM31 is a digital refractometer designed for the rapid measurement of coolant concentrations. This precision instrument provides dual-mode measurement capabilities and supports both Brix and refractive index units, allowing for accurate concentration analysis through the application of specific coolant refraction factors.

Key Features & Capabilities

Dual Measurement Modes: Supports both single measurement and automatic average multiple measurement functions.
Dual Unit Support: Capable of displaying readings in Brix and refractive index.
Concentration Calculation: Enables determination of actual concentration by applying the coolant's specific refraction factor to the device reading (e.g., for a grinding emulsion with a refraction factor of 2.1, a 6% reading results in an actual concentration of 12.6%).
Power Management: Features an automatic power-off function to conserve battery life.
Standard Delivery: Includes the main unit, a dropper, and one AAA battery.

Technical Specifications

Parameter	Specification
Measuring Range	0-50% (1.3330-1.4200 RI)
Accuracy	±0.2% (±0.0003 RI)
Resolution	0.1% (0.0001 RI)
Power Supply	1x AAA battery
Dimensions	121 x 58 x 25 mm
Weight	90 g
