The INSIZE Mini Digital Depth Gages with Round Bar (Code 1140 series) are precision measuring instruments designed specifically for measuring the depth of small grooves and holes. Constructed from durable stainless steel, these compact depth gauges feature a digital readout unit with automatic power-off functionality and a responsive motion-activation system. Available in standard models with a data interface and wireless models with built-in wireless connectivity.
- Precision Measurement: Engineered for accurate depth measurement in restricted spaces such as small grooves and holes.
- Construction: Manufactured from high-grade stainless steel for durability and corrosion resistance.
- Display & Resolution: High-resolution digital display offering measurements down to 0.01mm / 0.0005".
- Function Buttons: Equipped with On/Off, Zero, mm/Inch, and Preset (+/-) controls.
- Power Management: Operates on a CR2032 battery. Features automatic power off and moves the digital unit to automatically turn on power.
- Data Output Options:
- Standard models feature a data interface (optional data output cable: code 7315-21; receiver code 7315-25 required).
- Wireless models feature built-in wireless connectivity (receiver code 7315-2/3/6/7/8/9 required).
- Ingress Protection: Non-waterproof construction.
With Data Interface (Code 1140)
Built-in Wireless (Code 1140WL)
(Receiver code 7315-2/3/6/7/8/9 is required)
