- High contrast analog display
- Stainless spindle is hardened throughout and ground
- Spindle and anvil are carbide tipped
- Rapid drive
- Ratchet is integrated in the thimble
- Lacquered steel frame, heat insulated
- Integrated wireless
- Battery life approx. 2 years (approx. 0.5 in wireless mode)
- IP 65
- instruction manual
- battery
- setting standard (measuring range of 25-50 mm)
- case
Heights of Digits
- 10 mm
 |
||||
 |
 |
 |
 |
 |
Technical Data
| Order no. | Measuring range mm | Measuring range inches | Resolution mm/inch | Error limit µm | Spindle diameter | Spindle thread pitch_mm | Measuring force (N) |
|---|---|---|---|---|---|---|---|
| 4157100 |
0 – 25
|
0 – 1″
|
0.001 / .00005″
|
2 µm
|
6.5 mm
|
0.5 mm
|
5 – 10
|
| 4157101 |
25 – 50
|
1 – 2″
|
0.001 / .00005″
|
2 µm
|
6.5 mm
|
0.5 mm
|
5 – 10
|
| 4157102 |
50 – 75
|
2 – 3″
|
0.001 / .00005″
|
3 µm
|
6.5 mm
|
0.5 mm
|
5 – 10
|
| 4157103 |
75 – 100
|
3 – 4″
|
0.001 / .00005″
|
3 µm
|
6.5 mm
|
0.5 mm
|
5 – 10
|
Functions
- RESET (set display to zero)
- ABS (display can be set to zero without losing reference to ORIGIN)
- mm/inch
- ORIGIN (for entering a numerical value)
- LOCK function (key lock)
- TOL (Tolerance and warning limits)
- DATA (data transmission)
- HOLD (storage of measured values)
