SHORE DUROMETER CODE – ISH-S30A

Name: SHORE DUROMETER CODE – ISH-S30A
Brand: INSIZE
SKU: ISH-S30A

Code:

According to ISO868, ISO7619, ASTM D 2240 With peak value indicator Handhold use or work with test stand (code ISH-OS2) Check the PDF

DOWNLOAD CATALOG

f in

Click to Expand

SHORE DUROMETER CODE – ISH-S30A

Product Overview

The INSIZE ISH-S30A is a precision Shore A durometer designed for measuring the hardness of soft materials. This instrument is engineered for compliance with international standards and features a peak value indicator for accurate reading capture. It is suitable for both handheld operation and integration with the ISH-OS2 test stand.

Key Features & Capabilities

Standard Compliance: Conforms to ISO868, ISO7619, and ASTM D 2240 standards.
Peak Value Indicator: Equipped with a secondary needle to retain the maximum hardness value during testing.
Versatile Operation: Designed for manual handheld use or mounting on the ISH-OS2 test stand.
Indenter Design: Features a 35° blunt taper indenter with a 0.79mm tip diameter.
Operational Note: Use the ISH-S30A model when the measured hardness result is less than 20HD.

Technical Specifications

Parameter	Specification
Code	ISH-S30A
Unit	Shore A
Test Material	Soft plastic, soft rubber, etc.
Measuring Range	0–100HA
Resolution	1HA
Accuracy	±0.5HA
Indenter Protrusion	2.5mm
Bezel Diameter	57mm
Overall Height	121mm
Weight	184g
