| Steel Grade | High Carbon Steel |
| Fulcrum Stud | Hardened & Ground – Smooth bearing Surface |
| Tips | Hardened & Tempered for wear resistance |
| Bow Spring | Flexibale yet strong |
| Finish | Matt / Powder Coated |
| Size Range | 3″ to 60″ |
Key Features
Available Sizes
| SIZE | MM | APPLICATION NOTE |
|---|---|---|
| 3″ | 75 | Small bores & intricate work, Woodworking, Leather Craft, Jewelry Making, DIY |
| 4″ | 100 | Lothe & bench work, Woodworking, Leather Craft, Jowelry Making, DIY |
| 6″ | 150 | Gonoral purpose-most versatile size |
| 8″ | 200 | Medium lathe & CNC work, Wood Working, Fabrication, Metal Woricing |
| 10″ | 250 | Tool room standard |
| 12″ | 300 | Large bore & turning applications, Woodworking, Fabrication |
| 18″ | 450 | Heavy fabrication & casting work, Fabrication |
| 20″ | 500 | Large diameter layout |
| 24″ | 600 | Structural & heavy engineering, ile Setting, MetalWorking |
| 30″ | 750 | Large industrial components |
| 36″ | 900 | Heavy industry & shipbuilding |
| 40″ | 1000 | Specialist heavy applications |
| 48″ | 1200 | Large castings & forgings |
| 60″ | 1500 | Heavy Duty, Special Work |
CONSTRUCTION & MATERIALS
Designed with outward-curving legs that reach into bores, slots, and recesses to capture internal dimensions. The measurement is transferred to a steel rule or outside micrometer to obtain the reading.
