Disc Micrometer Rotating Type
FEATURES:
- Spindle made from stainless steel for rust prevention
- Measuring faces: hardened steel
- An in-built ratchet in the thimble
- Zero setting once done cannot be easily tampered with
- Sharp laser marking for better visibility & durability
- Heat insulating grip plates cover the entire handling portion of the micrometer frame
- Robust design withstands toughest workshop conditions
 |
 |
| Measuring Range | Reading | Type | A mm | B mm | C mm | Measuring Range | Reading | Type |
|---|---|---|---|---|---|---|---|---|
| 0-25 | 0.01 | MMA25-D | 10 | 36 | 29 | 0-1″ | 0.001″ | INA1-D |
| 25-50 | 0.01 | MMA50-D | 7.1 | 61.5 | 31 | 1-2″ | 0.001″ | INA2-D |
| 50-75 | 0.01 | MMA75-D | 8 | 87 | 45.5 | 2-3″ | 0.001″ | INA3-D |
| 75-100 | 0.01 | MMA100-D | 5.9 | 110 | 57.5 | 3-4″ | 0.001″ | INA4-D |
Check the PDF
Disc Micrometer Non-Rotating Type
FEATURES:
- Non-rotating spindle (only axial moment of spindle)
- Spindle made from stainless steel for rust prevention
- Measuring faces: hardened steel
- An in-built ratchet in the thimble
- Zero setting once done cannot be easily tampered with Sharp laser marking for better visibility & durability
- Heat insulating grip plates cover the entire handling portion of the micrometer frame
- Robust design withstands toughest workshop conditions
 |
 |
| Measuring Range mm |
Reading mm |
Type | A mm |
B mm |
C mm |
Measuring Range Inch |
Reading Inch |
Type |
|---|---|---|---|---|---|---|---|---|
| 0-25 | 0.01 | MMA25-ND | 10 | 36 | 29 | 0-1″ | 0.001″ | INA1-ND |
| 25-50 | 0.01 | MMA50-ND | 7.1 | 61.5 | 31 | 1-2″ | 0.001″ | INA2-ND |
| 50-75 | 0.01 | MMA75-ND | 8 | 87 | 45.5 | 2-3″ | 0.001″ | INA3-ND |
| 75-100 | 0.01 | MMA100-ND | 5.9 | 110 | 57.5 | 3-4″ | 0.001″ | INA4-ND |
