- Designed for measuring wire thickness.
- Measurable wire dia.: 10mm or less
- Measuring faces: Carbide
- Equipped with Ratchet Stop for constant measuring force.
SPECIFICATIONS
Metric
| Order No. | Range | Graduation | Accuracy |
|---|---|---|---|
| 147-401 | 0 – 10mm | 0.01mm | ±3µm |
Inch
| Order No. | Range | Graduation | Accuracy |
|---|---|---|---|
| 147-402 | 0 – .4″ | .0001″ | ±.00015″ |
DIMENSIONS
Technical Data
Flatness: 0.6μm/.000024”
Parallelism: 1.3μm/.00005”
Standard accessories: Spanner (200168), 1 pc
Spanner (202863), 1pc
