| Measuring Range (XĆYĆZ) | $300\times200\times200\text{ mm}$ | $400\times300\times200\text{ mm}$ |
| Stage Size | $556\times406\text{ mm}$ | $561\times556\text{ mm}$ |
| Glass Stage Size | $350\times250\text{ mm}$ | $450\times350\text{ mm}$ |
| Resolution of X/Y/Z Axis | $0.5\text{ }\mu\text{m}$ | $0.5\text{ }\mu\text{m}$ |
| Accuracy of X/Y Axis | $\le(2.5+L/1000)\text{ }\mu\text{m}$ ($L$ is measuring length in mm) | $\le(3.5+L/200)\text{ }\mu\text{m}$ ($L$ is measuring length in mm) |
| Repeatability of X/Y Axis | $2\text{ }\mu\text{m}$ | $2\text{ }\mu\text{m}$ |
| Objective (Manual Zoom) | $0.7\text{X}\sim4.5\text{X}$ (Zoom) | $0.7\text{X}\sim4.5\text{X}$ (Zoom) |
| Working Distance | $92\text{ mm}$ | $92\text{ mm}$ |
| View Field (Diagonal Length) | $1.7\sim11.1\text{ mm}$ | $1.7\sim11.1\text{ mm}$ |
| Magnification | $33\text{X}\sim208.6\text{X}$ (on $24\text{"}$ monitor) | $33\text{X}\sim208.6\text{X}$ (on $24\text{"}$ monitor) |
| Camera | Giga-bit network camera | Giga-bit network camera |
| Illumination (Surface) | Coaxial light, programmable segmented ring light | Coaxial light, programmable segmented ring light |
| Illumination (Contour) | Adjustable LED light | Adjustable LED light |
| Max. Height of Workpiece | $200\text{ mm}$ | $200\text{ mm}$ |
| Max. Weight of Workpiece | $30\text{ kg}$ | $30\text{ kg}$ |
| Operation System | Windows 7/8/10 | Windows 7/8/10 |
| Drive Method | Automatic | Automatic |
| Power Supply | $220\text{V}$, $50/60\text{Hz}$ | $220\text{V}$, $50/60\text{Hz}$ |
| Dimension (LĆWĆH) | $1420\times915\times1830\text{ mm}$ | $1650\times1170\times1900\text{ mm}$ |
| Weight | $500\text{ kg}$ | $700\text{ kg}$ |
