UNIQUE HYDRAULIC PRESSURE VICE

Unique Hydraulic Pressure Vice Rigid material vise body of ductile iron Clamping force 3500 KGF. Accuracy in squareness within 0.02/100mm Hydraulic cylinder of alloy steel hardened, ground & lapped Jaws made of alloy steel properly hardened Fixed jaws is provided with vertical & horizontal ‘v’ grooves to hold the round job firmly Supplied with stopper

Download PDF

Unique Hydraulic Pressure Vice

Rigid material vise body of ductile iron
Clamping force 3500 KGF.
Accuracy in squareness within 0.02/100mm
Hydraulic cylinder of alloy steel hardened, ground & lapped
Jaws made of alloy steel properly hardened
Fixed jaws is provided with vertical & horizontal ‘v’ grooves to hold the round job firmly
Supplied with stopper for fast production

	Size in inches	6	6
A	Width of jaws in mm	150	150
B	Opening of laws in mm	300	200
C	Depth of jaws in mm	60	60
D	Length overall in mm	585	475
E	Height overall U 3310	155	155
F	Width Overall U 3310 S	250	250
	Height Overall U 3310 S	195	195
	Width Overall U 3310 S	320	320
	Tenon slot Size in mm	20	20
	Weight (Approx) in kgs U 3110	46	42
	Weight (Approx) in kgs U 3110	60	55
