13 roughness parameters With probe position indicator Connected with printer via bluetooth (code ISR-C100-PRINTER) Can display roughness values, profile, and curve Memory of maximum 100 results Automatic power off Download PDF

Unit: μm, μin Automatic power off Download PDF

21 roughness parameters Connected with printer via bluetooth Display roughness values, profile and curve Memory of maximum 100 results Automatic power off   Download PDF

Roughness tester can be operated by mobile phone (only android system) or computer Data can be output to Excel by connecting with computer via bluetooth or USB cable Support bluetooth printer 22 roughness parameters Meet ISO, DIN, ANSI, JIS standards Display roughness values, profile and curve Memory of maximum 100 data and waveform Built-in lithium […]

Mobile and stationary measuring instrument Roughness and waviness measurements Traversing lengths up to 26 mm Over 50 R, W and P surface parameters Automatic choice of cut-off and traversing length in accordance with international standards Dynamic calibration function Cable and the Bluetooth connection between the drive unit and evaluation instrument (4 m) Magnetic probe holder […]

Bright, illuminated color display Automatic selection of filter and traversing length conforming to standards Integrated thermal graphics printer with high print quality Log printed by pressing a button Data transfer of results and profiles via USB interface to your PC Evaluation of most common parameters as well as characteristic curves, parameter lists (e.g. material ratio […]

First portable roughness measuring unit with the option of wireless (Bluetooth) connection between the evaluation unit and drive unit Easy to use, with high-resolution color display and menu-driven user guidance Integrated standard in the drive unit Large measuring range – 350 µm Automatic profile detection and corresponding selection of filter and traversing length conforming to […]

“sMAHRtSurf” – Simple, smart and mobile Compact roughness measuring instrument for mobile use Simple and intuitive to use: As easy to use as a smartphone Large, illuminated 4.3″ TFT touch display Adjustable display Start button also serves as the Home button for direct access to the start screen Data backup as TXT, X3P or PDF […]

Durable cast aluminum housing to provide years of accurate and reliable surface finish gaging Can be used to measure any one of four, selectable, parameters: Ra, Ry, Rmax, Rz Review any of the parameters after the measurement is complete Selectable traverse length 1, 3 or 5 cut-offs of 0.8 mm/0.030“ Operates in any position – […]

Attachment for interrupted surface measurement No.178-034 Best suited for measurement of the flat surface of a workpiece that has partial indentations and steps and that is hard to set the drive unit. Combination use with the magnet type specimen holder (Option: No.12AAA910) further improves the ease of operation. Attachment for measuring inside bores and holes […]

Detector Standard detectors Code No. Measuring force Stylus Remarks 178-296 0.75mN 2µmR /60˚ Dedicated to the standard/retractable drive unit 178–390 4 mN 5µmR /90˚ 178–387 0.75mN 2µmR /60˚ Dedicated to the transverse tracing drive unit 178–386 4 mN 5µmR /90˚ 178–391 4 mN 10µmR /90˚ Dedicated to the standard/ retractable drive unit *Tip radius /Tip angles Small hole detectors Code […]

SPECIFICATIONS *1: Calculation is available only when selecting the VDA, ANSI, or JIS 1982 standard. *2: Calculation is available only when selecting the ISO 1997 standard. *3: Calculation is available only when selecting the JIS 2001 standard. *4: Calculation is available only when selecting the ANSI standard. *5: Not available when selecting the JIS 1982 […]

*1: Calculation is available only when selecting the VDA, ANSI, or JIS 1982 standard. *2: Calculation is available only when selecting the ISO 1997 standard. *3: Calculation is available only when selecting the JIS 2001 standard. *4: Calculation is available only when selecting the ANSI standard. *5: Not available when selecting the JIS1982 standard *6: […]

To check the roughness of steel surfaces which have been blast cleaned before painting Meets ISO 8503/1 Rust-proof, made of pure Nickel   Code Machining method Roughness (Ra) Roughness (Rz) Quantity ISR-CS017 Shot blasting 3.2, 8, 13, 18µm 19.2, 48, 78, 108µm 4pcs ISR-CS018 Grit blasting 3.2, 10.5, 18, 25µm 19.2, 63, 108, 150µm 4pcs […]

To check the roughness of steel surfaces which have been blast cleaned before painting Meets ISO 8503/1 Rust-proof, made of pure Nickel   Code Machining method Roughness (Ra) Roughness (Rz) Quantity ISR-CS017 Shot blasting 3.2, 8, 13, 18µm 19.2, 48, 78, 108µm 4pcs ISR-CS018 Grit blasting 3.2, 10.5, 18, 25µm 19.2, 63, 108, 150µm 4pcs […]

To calibrate roughness testers Meets ISO 5436-1: 2000 Rust proof, made of pure Nickel Check the PDF

For checking, identifying and specifying the roughness by symbol Accuracy: +20% ~ -25%, Ra<0.1µm Accuracy: +12% ~ -17%, Ra>0.1µm Meets ISO 2632 (ISR-CS329 meets ISO 8503/1) Rust-proof, made of pure Nickel Check the PDF

For checking, identifying and specifying the roughness by symbol Accuracy: +20% ~ -25%, Ra<0.1µm Accuracy: +12% ~ -17%, Ra>0.1µm Meets ISO 2632 Rust-proof, made of pure Nickel Check the PDF

Automatic probe leveling Language: English, French, German, Italian, Spanish, Portuguese 12 roughness parameters Can set tolerance Measuring range up to 400µm, can measure grit and shot blasting Traverse length up to 16mm The probe can be set at 90°or 270°, for transverse measurement Memory of maximum 100 results Check the PDF

Automatic probe leveling Language: English, French, German, Italian, Spanish, Portuguese 12 roughness parameters Can set tolerance Measuring range up to 400µm, can measure grit and shot blasting Traverse length up to 16mm The probe can be set at 90°or 270°, for transverse measurement Memory of maximum 100 results Check the PDF

38 roughness parameters according to ISO-4287, JIS-B0601, ISO-12085, JIS-B0631 Automatic probe leveling Measuring range up to 1000µm, can measure grit and shot blasting Traverse length up to 25mm The probe can be set at 90° or 270°, for transverse measurement Color touch screen, display roughness values, profile and curves Can print roughness values, profile and […]

48 roughness parameters according to ISO-4287, JIS-B0601, ISO-12085, JIS-B0631 Automatic probe leveling Measuring range up to 1000µm, can measure grit and shot blasting Traverse length up to 50mm The probe can rotate from -90° to +90° Color touch screen, display roughness values, profile and curves Can print roughness values, profile and curves Memory of maximum […]
