20°/ 60°/ 85° GLOSS METER (CODE

20°/ 60°/ 85° GLOSS METER (CODE – ISQ-DG8)

To test the gloss of coating, such as painting, varnish, printing ink, etc. To test the material surfaces, such as metal, granite, ceramic, plastic, paper, etc. According to ISO 2813, ASTM D2457, ASTM D523 Memory of 1000 measurement results for browsing and output Automatic power off

Download Catalog

Incidence angle	20°	60°	85°
Measuring range	0~2000GU	0~1000GU	0~160GU
Resolution	0.1GU (range<119.9GU)
Resolution	1GU (range<119.9GU)
Accuracy	±1.5GU (range<119.9GU)
Accuracy	±1.5% (range<119.9GU)
Repeatability	±0.2GU (range<119.9GU)
Repeatability	±0.2% (range<119.9GU)
Zero set error	0.2GU
Measuring area	10x9mm	16x9mm	39x5mm
Output	USB & bluetooth
Power supply	1×1.5V AA battery
Dimension	155x48x75 mm
Weight	400g

To test the gloss of coating, such as painting, varnish, printing ink, etc.
To test the material surfaces, such as metal, granite, ceramic, plastic, paper, etc.
According to ISO 2813, ASTM D2457, ASTM D523
Memory of 1000 measurement results for browsing and output
Automatic power off
