INSIZE SPECTROPHOTOMETER (CODE 9710-30)

INSIZE SPECTROPHOTOMETER (CODE 9710-30)

Concave grating spectrophotometric 3,5 inch TFT color LCD, capacitive touch screen, 256 image element double arrays CMOS image sensor D/8 geometrical optics, conforms with CIE No. 15, ISO7724/1, ASTM E1164, DIN5033 Teil 7 Use long life and low power consumption combined LED light source Camera locating function, switchable 8mm/4mm aperture, support both SCl and SCE at the same time Large capacity storage space, over 20,000 measurement data USB port and Bluetooth 4.0 Two standard observer angles, a variety of illuminant, a variety of color indexes, conforms with a variety of standard colorimetric data Measure sample spectra, accurate Lab data, can be used in color matching and accurate color transmission

Download Catalog

Optical geometry		reflect: di: 8°, de: 8° (diffused illumination, 8-degree viewing angle)
Integrating sphere size		Ø48mm
Light source		combined LED light, UV light
Spectrophotometric mode		concave grating
Sensor		256 image element double array CMOS image sensor
Wavelength range		400~700nm
Wavelength interval		10nm
Semiband width		10nm
Measured reflectance range		0~200%
Measuring aperture		dual aperture: MAV: 08mm; SAV: 04mm
Specular component		SCI&SCE
Color space		CIE LAB, XYZ, Yxy, LCh, CIE LUV, hunter LAB
Color difference formula		△Eab, △Euv, △E94, △Ecmc (2:1),
Color difference formula		△Ecmc (1:1), △E00V, △E (Hunter)
Other colorimetric index		WI (ASTM E313, CIE/ISO, AATCC, hunter), YI (ASTM D1925,
		ASTM 313), metamerism index MI, staining fastness, color fastness,
		colorstrength, opacity
Observer angle		2°/10°
Illuminant		A, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8,
Illuminant		F9, F10, F11, F12, CWF, U30, TI83, T184, U35
Displayed data		pectrogram/values, samples chromaticity values,
Displayed data		color difference values/graph, PASS/FAIL result, color offset
Measuring time		2.6s
Repeatability	spectral reflectance	MAV/SCI, within 0.08% of standard deviation (400~700nm: 0.18%)
Repeatability	colorimetric values	MAV/SCI: △E*≤0.03
Inter-instrument error		MAV/SCI: △E*≤0.15
Measurement mode		single measurement, average measurement
Data port		USB, bluetooth 4.0
Data storage		standard 1000 pcs, sample 28000 pcs
Ituminant life span		5 years, more than 3 million times measurements
Battery		Li-ion battery, 5000 measurements within 8 hours
Dimension		184×77×105mm
Weight		600g

Concave grating spectrophotometric
3,5 inch TFT color LCD, capacitive touch screen,
256 image element double arrays CMOS image sensor
D/8 geometrical optics, conforms with CIE No. 15, ISO7724/1, ASTM E1164, DIN5033 Teil 7
Use long life and low power consumption combined LED light source
Camera locating function, switchable 8mm/4mm aperture, support both SCl and SCE at the same time
Large capacity storage space, over 20,000 measurement data
USB port and Bluetooth 4.0
Two standard observer angles, a variety of illuminant, a variety of color indexes, conforms with a variety of standard colorimetric data
Measure sample spectra, accurate Lab data, can be used in color matching and accurate color transmission
