- With fine adjustment
- Made of stainless steel
- Satin chrome plating finish on reading surface
- Optional accessory: extension base (code 6141)
Graduation 0.02mm
| Code | Range | Accuracy |
| 1249-1501 | 0-150mm | 0.03mm |
| 1249-2001 | 0-200mm | 0.03mm |
| 1249-3001 | 0-300mm | 0.04mm |
| Range | L | c | d |
| 0-150mm | 256 | 16 | 100 |
| 0-200mm | 306 | 16 | 100 |
| 0-300mm | 406 | 16 | 100 |
