• High contrast analog display
• Locking screw above
• Lapped guideway
• Measuring blade for inside measurements
• Slide and beam made of hardened stainless steel
• Immediate measurements due to the Reference System
• Raised guideway for the protection of the scale
• Excellent resistance against dust, coolants and lubricants
• Dirt wipers are integrated in the slide
• Digital caliper can support USB
• Opto RS232C
• Digimatic
• IP 67
• battery
• instruction manual
• case
• Battery life approx. 3 years

Height of digits

• 8.5 mm





Order no.	Measuring range mm	Measuring range inches	Resolution mm/inch	Error limit (mm)	Error limit inches	Standard	Depth Rod
4103085	10 – 200	0.4 – 8″	0.01 / .0005″	0.05 mm	.002″	Factory standard	none



Functions of Digital Caliper

• ON/OFF
• AUTO-ON / OFF
• mm/inch
• LOCK function (key lock)
• RESET (set display to zero)
• PRESET (for entering a numerical value)
• DATA (data transmission via connection cable)
