MARCAL 30 EWRI-D DIGITAL DEPTH GAGE

MARCAL 30 EWRI-D DIGITAL DEPTH GAGE

High contrast analog display Locking screw above Lapped guideway Measuring surfaces made of steel Slide and beam made of hardened stainless steel Immediate measurements due to the Reference System Raised guideways for the protection of the scale Excellent resistance against dust, coolants and lubricants Dirt wipers are integrated in the slide Integrated wireless IP 67

High contrast analog display
Locking screw above
Lapped guideway
Measuring surfaces made of steel
Slide and beam made of hardened stainless steel
Immediate measurements due to the Reference System
Raised guideways for the protection of the scale
Excellent resistance against dust, coolants and lubricants
Dirt wipers are integrated in the slide
Integrated wireless
IP 67
Battery
Instruction manual
Case
Battery life approx. 3 years (approx. 0.5 in wireless mode)

Height of digits

11 mm

Order no.	Measuring range mm	Measuring range inches	Resolution mm/inch	Error limit (mm)	Error limit inches	Standard
4126533	0 – 200	0 – 8″	0.01 / .0005″	0.03 mm	.001″	Factory standard
4126534	0 – 300	0 – 12″	0.01 / .0005″	0.04 mm	.001″	Factory standard

Functions

ON/OFF
AUTO-ON / OFF
mm/inch
LOCK function (key lock)
RESET (set display to zero)
PRESET (for entering a numerical value)
DATA (data transmission via connection cable)

MARCAL 30 EWR-D DIGITAL DEPTH GAGE

High contrast analog display
Locking screw above
Lapped guideway
Measuring surfaces made of steel
Slide and beam made of hardened stainless steel
Immediate measurements due to the Reference System
Raised guideway for the protection of the scale
Excellent resistance against dust, coolants and lubricants
Dirt wipers are integrated in the slide
USB
Opto RS232C
Digimatic
IP 67
battery
instruction manual
case
Battery life approx. 3 years

Height of digits

8.5 mm

Order no.	Measuring range mm	Measuring range inches	Resolution mm/inch	Error limit (mm)	Error limit inches	Standard
4126523	0 – 200	0 – 8″	0.01 / .0005″	0.03 mm	.001″	Factory standard
4126524	0 – 300	0 – 12″	0.01 / .0005″	0.04 mm	.001″	Factory standard

Functions

ON/OFF
AUTO-ON / OFF
mm/inch
LOCK function (key lock)
RESET (set display to zero)
PRESET (for entering a numerical value)
DATA (data transmission via connection cable)
