Metric/Inch type (rachet stop)
| Code | Range | Resolution | Accuracy | L (mm) | a (mm) | b (mm) | c (mm) |
|---|---|---|---|---|---|---|---|
| 3101-25A* | 0-25mm/0-1″ | 0.001mm/0.00005″ | ±2µm | 34.5 | 6 | 25 | 3 |
| 3101-50A* | 25-50mm/1-2″ | 0.001mm/0.00005″ | ±2µm | 59.5 | 8 | 32 | 3 |
| 3101-75A* | 50-75mm/2-3″ | 0.001mm/0.00005″ | ±3µm | 84.5 | 8 | 44.5 | 3 |
| 3101-100A* | 75-100mm/3-4″ | 0.001mm/0.00005″ | ±3µm | 109.5 | 8 | 57 | 3 |
| 3101-125A | 100-125mm/4-5″ | 0.001mm/0.00005″ | ±3µm | 135 | 10 | 70 | 3 |
| 3101-150A | 125-150mm/5-6″ | 0.001mm/0.00005″ | ±3µm | 160.5 | 10 | 82 | 3 |
| 3101-175A | 150-175mm/6-7″ | 0.001mm/0.00005″ | ±4µm | 186 | 12 | 94.5 | 5.5 |
| 3101-200A | 175-200mm/7-8″ | 0.001mm/0.00005″ | ±4µm | 211.5 | 12 | 107 | 5.5 |
| 3101-225A | 200-225mm/8-9″ | 0.001mm/0.00005″ | ±4µm | 236 | 23 | 129.5 | 5.5 |
| 3101-250A | 225-250mm/9-10″ | 0.001mm/0.00005″ | ±4µm | 261.5 | 23 | 142.5 | 5.5 |
| 3101-275A | 250-275mm/10-11″ | 0.001mm/0.0001″ | ±5µm | 287 | 23 | 155 | 5.5 |
| 3101-300A | 275-300mm/11-12″ | 0.001mm/0.0001″ | ±5µm | 312.5 | 23 | 167.5 | 5.5 |
Metric/Inch type (friction thimble)
| Code | Range | Resolution | Accuracy | L (mm) | a (mm) | b (mm) | c (mm) |
|---|---|---|---|---|---|---|---|
| 3101-25FA* | 0-25mm/0-1″ | 0.001mm/0.00005″ | ±2µm | 34.5 | 6 | 25 | 3 |
Metric type (rachet stop)
| Code | Range | Resolution | Accuracy | L (mm) | a (mm) | b (mm) | c (mm) |
|---|---|---|---|---|---|---|---|
| 3101-25A* | 0-25mm | 0.001mm | ±2µm | 34.5 | 6 | 25 | 3 |
| 3101-50A* | 25-50mm | 0.001mm | ±2µm | 59.5 | 8 | 32 | 3 |
| 3101-75A* | 50-75mm | 0.001mm | ±3µm | 84.5 | 8 | 44.5 | 3 |
| 3101-100A* | 75-100mm | 0.001mm | ±3µm | 109.5 | 8 | 57 | 3 |
Set (rachet stop type)
| Code | Range | Micrometers included | Packaging |
|---|---|---|---|
| 3101-753A* | 0-75mm/0-3″ | 3101-25A, 3101-50A, 3101-75A | blow mould case |
| 3101-1004A* | 0-100mm/0-4″ | 3101-25A, 3101-50A, 3101-75A, 3101-100A | blow mould case |
| 3101-1506A* | 0-150mm/0-6″ | 3101-25A, 3101-50A, 3101-75A, 3101-100A, 3101-125A, 3101-150A | aluminum box |
| 3101-3006A* | 0-300mm/0-12″ | 3101-175A, 3101-200A, 3101-225A, 3101-250A, 3101-275A, 3101-300A | aluminum box |
