Mitutoyo-SERIES 148 – Fine Spindle Feed of 0.25mm/rev-Micrometer Heads

Miniature micrometer heads for ease of incorporating into machines. DIMENSIONS SPECIFICATIONS Metric Order No. Range Graduation Accuracy Stem dia. Stem Spindle end Spindle pitch 148-132 0 – 13mm   0.01mm   ±2µm   9.5mm Plain   Spherical (SR4)   0.25mm 148-133 w/ clamp nut 148-322 0 – 6.5mm Plain 148-323 w/ clamp nut

AUTHOR RATE
Mitutoyo-SERIES 148 – Fine Spindle Feed of 0.1mm/rev-Micrometer Heads

Highly accurate 0.1mm pitch thread is only one-fifth of that used for a standard-pitch head (0.5mm). External dimensions are compatible with standard 0.5mm pitch heads. DIMENSIONS SPECIFICATIONS Metric Order No. Range Graduation Accuracy Stem dia. Stem Spindle end Spindle pitch Special features 148-142     0 – 6.5mm     0.002mm   ±2µm   9.5mm Plain […]

AUTHOR RATE
Mitutoyo-SERIES 152 – Quick Spindle Feed of 1mm/rev-Micrometer Heads

Quick spindle feed of 1mm/rev. DIMENSIONS SPECIFICATIONS Metric Order No. Range Graduation Accuracy Stem dia. Stem Spindle end Spindle pitch 152-101 0 – 15mm   0.01mm ±2µm   12mm   Plain   Flat (carbide tip)   1mm 152-102 0 – 25mm 152-103 0 – 50mm ±4µm

AUTHOR RATE
Mitutoyo-SERIES 153 – Non-rotating Spindle Type – Micrometer Heads

The spindle translates without rotation. Torsion-free feed reduces workpiece deformation and wear. DIMENSIONS SPECIFICATIONS Metric Order No. Range Graduation Accuracy Stem dia. Stem Spindle end Spindle pitch Graduation features 153-101 0 – 15mm 0.01mm   ±3µm 9.5mm   Plain   Flat (carbide tip)   0.5mm Standard 153-201*   0 – 25mm   12mm 153-202* 0.001mm […]

AUTHOR RATE
Mitutoyo-SERIES 148 – Locking-screw Type – Micrometer Heads

Locking screw provides secure locking at any position of the spindle. Position of the locking screw is the same as the sleeve index line. DIMENSIONS SPECIFICATIONS Metric Order No. Range Graduation Accuracy Stem dia. Stem Spindle end Graduation features 148-220   0 – 6.5mm           0.01mm   ±5µm   6mm Plain […]

AUTHOR RATE
Mitutoyo-SERIES 151 – Medium-sized Standard Type with 8mm diameter spindle-Micrometer Heads

Larger spindle for heavy-duty applications (normally ø6.35mm). DIMENSIONS SPECIFICATIONS Metric Order No. Range Accuracy Stem dia. Stem Spindle end Special features 151-224           0 – 25mm           ±2µm             12mm Plain             Flat (carbide tip)   — […]

AUTHOR RATE
Mitutoyo-SERIES 150 – Medium-sized Standard Type-Micrometer Heads

Measuring range of 25mm. DIMENSIONS SPECIFICATIONS Metric Inch Order No. Range Accuracy Stem dia. Stem Spindle end Special features 150-208               0 – 1″               ±.0001″               .375″ Plain   Flat (carbide tip)     Standard 150-207 […]

AUTHOR RATE
Mitutoyo-SERIES 149 – Small Standard Type with Carbide-Tipped Spindle-Micrometer Heads

Carbide-tipped spindle provides high abrasion resistance. DIMENSIONS SPECIFICATIONS Metric Order No. Range Accuracy Stem dia. Stem Spindle end Graduation features 149-132           0 – 15mm           ±2µm           9.5mm Plain   Flat (carbide tip)     Standard 149-131 W/ clamp nut 149-183 Plain* […]

AUTHOR RATE
Mitutoyo-SERIES 148 – Small Thimble Diameter Standard Type-Micrometer Heads

Measuring range of 13mm. The thimble can be set to zero at any position by loosening the setscrew. Stainless steel throughout: 148-513, 518, 511 DIMENSIONS   SPECIFICATIONS Metric Order No. Range Accuracy Stem dia. Stem Spindle end Special features 148-503           0 – 13mm           ±2µm   […]

AUTHOR RATE
Mitutoyo-SERIES 148 – Small Standard Type-Micrometer Heads

Measuring range of 13mm. SPECIFICATIONS Metric Order No. Range Accuracy Stem dia. Stem Spindle end Graduation features 148-104           0 – 13mm           ±2µm           9.5mm Plain   Flat       Standard 148-103 W/ clamp nut 148-121 Plain* 148-120 W/ clamp nut* […]

AUTHOR RATE
Mitutoyo-SERIES 148 — Short Thimble with Choice of Diameter-Micrometer Heads

Short body design maintains measuring range for limited space applications. Available in three thimble diameters to provide ease-of-reading options. DIMENSIONS Technical Data Graduation: 0.01mm or .001” Spindle pitch: 0.5mm or .025”

AUTHOR RATE
Mitutoyo-SERIES 148 — Small/Ultra-small Type-Micrometer Heads

Miniature micrometer heads for ease of incorporating into machines.   SPECIFICATIONS Metric Order No. Range Accuracy Stem dia. Stem Spindle end Graduation 148-215 0 – 5mm ±5µm 3.5mm Plain W/ clamp nut Spherical (SR1.5) Standard 148-216 148-201 0 – 6.5mm 6mm Plain W/ clamp nut Flat 148-203 148-205 Plain W/ clamp nut Spherical (SR3) 148-207 […]

AUTHOR RATE
Mitutoyo-Series 164, 350-Digimatic Micrometer Heads

Equipped with digital display and output. Series 350 IP65 models: the Digimatic output port enables inclusion in a statistical process control or networked measurement system. (Refer to page A-3 for details). SPECIFICATIONS Metric Order No. Range Resolution Accuracy** Stem Stem dia Spindle end Graduation features 164-163 0 – 50mm 0.001mm ±3µm ±2µm Plain 18mm Flat (carbide […]

AUTHOR RATE
Mitutoyo-SERIES 156-Micrometer Stands

Designed to allow benchtop use of hand micrometers or other gages which have frames suitable for gripping by the clamp. SPECIFICATIONS Order No. Micrometer ranges Remarks 156-101-10 Up to 100mm (4″)* Adjustable angle type 156-105-10 0-25mm (0-1″), 25-50mm (1″-2″) Fixed angle type 156-102 125-300mm (5″-12″) Vertical type 156-103 300-1000mm (12″-40″) Vertical type * Items that cannot […]

AUTHOR RATE
Mitutoyo-SERIES 157-Optical Parallels

Designed to inspect parallelism and flatness of measuring faces of micrometers. For details, refer to “Quick Guide to Precision Measuring Instruments”. Each set consists of 4 sizes to aid in testing parallelism at various angular positions of the micrometer spindle.   SPECIFICATIONS Metric Order No. Range of micrometer to be checked Sizes of parallels included in set Diameter […]

AUTHOR RATE
Mitutoyo-SERIES 167-Setting Standards for Screw Thread Micrometers

Used for accurately setting screw thread micrometers at the start or end of the measuring range. Metric Order No. Length Accuracy Metric (unified) 8 = 60° 167-261 25mm ±4µm 167-262 50mm ±5µm 167-263 75mm ±6µm 167-264 100mm ±7µm 167-265 125mm ±8µm 167-266 150mm ±9µm 167-267 175mm ±10µm 167-268 200mm ±11µm 167-269 225mm ±12µm 167-270 250mm […]

AUTHOR RATE
Mitutoyo-SERIES 167-Setting Standards for Outside Micrometers

Used for adjusting the reference point of the outside micrometer. SPECIFICATIONS and DIMENSIONS Metric Order No. Length  (L) Tolerance   Diameter  (D) 167-101 25mm ±1.5µm 18   6.35mm 167-102 50mm ±2.0µm 40 167-103 75mm ±2.5µm Inch Order No. Length  (L) Tolerance   Diameter  (D) 167-141 1″ ±.00005″ 18   .25″ 167-142 2″ ±.0001″ 40 167-143 […]

AUTHOR RATE
Mitutoyo-SERIES 155-Telescoping Gage Set

A spring-loaded plunger expands within a bore (or groove) and is locked in place, allowing measurement of diameter (or width) with an outside micrometer after extraction. SPECIFICATIONS Metric Order No. Range 6-gage Set 155-905 8 – 150mm Gages included 155-127 8 – 12.7mm 155-128 12.7 – 19mm 155-129 19 – 32mm 155-130 32 – 54mm […]

AUTHOR RATE
Mitutoyo-SERIES 700-Quick-Mini

Lightweight and palm-sized. Highly suitable for quick dimensional inspection of small, thin and delicate objects. Functions: origin setting and zero-setting. Application examples Measurement of small objects: pearls, jewels, shims for engine tappets  and screws. Measurement of thin objects: printing paper, polyethylene bags,  sheet materials, foods including noodles, lenses for glasses, media substrates, foils, thin plates and medical products including filter […]

AUTHOR RATE
Mitutoyo-SERIES 146-Groove Micrometers

Flanged spindle and anvil for measuring width and location of grooves inside bores and tubes. Two-directional ratchet stop. For ID and OD (except for 0 – 25mm) measurement, a master gage is required for adjusting the reference point. SPECIFICATIONS Metric Order No. Range Outside Range Inside Graduation Accuracy Flange Rotating spindle 146-121 0 – 25mm […]

AUTHOR RATE
Mitutoyo-SERIES 523-Snap Meters

Suited to the measurement of massproduced parts. Various types of indicator can be selected according to the measurement application. Measuring faces: Carbide SPECIFICATIONS Metric Order No. Range Anvil movement Measuring force* Mass 523-141 0 – 25mm   2mm   5 – 10N 710g 523-142 25 – 50mm 810g 523-143 50 – 75mm 920g 523-144 75 – […]

AUTHOR RATE
Mitutoyo-SERIES 523-Dial Snap Meters

Suited to the measurement of massproduced parts. Designed for measurement using a stand: realizes stable measurement. Greatly improved accuracy: indication error and graduation of 1μm. Water-proof to protection level IP54. Hard-coated crystal: enhanced oil and scratch resistance. Indicator scale is large and easy-to-read. Easily settable adjustable limit markers for GO/±NG testing. Equipped with an elevating workpiece […]

AUTHOR RATE
Mitutoyo-SERIES 510-Indicating Micrometers

Suited to the measurement of low-volume manufactured parts. Easy to use when operating one-handed due to retractable anvil. In the 25mm measuring range, the model lineup offers a choice of left or right positioning of the anvil-retraction button. Greatly improved accuracy: indication error and graduation of 1μm. Water-proof to protection level IP54. Hard-coated crystal: enhanced oil and […]

AUTHOR RATE
Mitutoyo-SERIES 113-Limit Micrometers

Dual-spindle design enables use as a GO/±NG gage by setting upper and lower limits. Measuring faces: Carbide SPECIFICATIONS Metric Order No. Range Graduation Accuracy Flatness Parallelism 113-102 0 – 25mm 0.01mm ±3µm 0.6µm 3µm 113-103 25 – 50mm Technical Data Standard accessories: Reference bar, 1 pc (except for measuring range 0-25mm (0-1″) models) Spanner (200877), 1 […]

AUTHOR RATE
Mitutoyo-Series 317, 117 — Interchangeable Anvil Type-”Uni-Mike”

Measures tubing thickness, shoulderedge distance, rivet head height, etc., with interchangeable anvils (flat anvil, rod anvil, V-anvil). IP65 water/dust protection (series 317). Equipped with Ratchet Stop for constant  measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Digimatic  (LCD) 317-251-30 0 – 25mm 0.001mm ±4µm 317-252-30 25 – 50mm * Excluding quantizing error Inch/Metric Order No. […]

AUTHOR RATE
Mitutoyo-Series 342,112,142-Crimp Height Micrometers

Measures the height of crimp contacts. Equipped with Ratchet Stop for constant measuring force. IP65 water/dust protection (digital model). Model 342-451 is the Quickmike type, which provides a speedy spindle feed of 10mm per thimble rotation, which enables widely differently sized features to be measured quickly. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Digimatic  (LCD) 342-271-30 0 […]

AUTHOR RATE
Mitutoyo-Series 147-Wire Micrometers

Designed for measuring wire thickness. Measurable wire dia.: 10mm or less Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Graduation Accuracy 147-401 0 – 10mm 0.01mm ±3µm Inch Order No. Range Graduation Accuracy 147-402 0 – .4″ .0001″ ±.00015″ DIMENSIONS Technical Data Flatness: 0.6μm/.000024” Parallelism: 1.3μm/.00005” Standard […]

AUTHOR RATE
Mitutoyo-SERIES 147-Hub Micrometers

Measures hub thickness and shoulders inside a bore. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Graduation Accuracy 147-301 0 – 25mm   0.01mm   ±2µm 147-302 25 – 50mm 147-303 50 – 75mm 147-304 75 – 100mm ±3µm Inch Order No. Range Graduation Accuracy 147-351 0 – […]

AUTHOR RATE
Mitutoyo-SERIES 147-Can Seam Micrometers

 Measures the width, height, and depth of can seams. SPECIFICATIONS Metric Order No. Range Graduation Accuracy Remarks 147-103   0 – 13mm   0.01mm   ±3µm for steel cans 147-105 for aluminum cans 147-202 for spray cans Inch Order No. Range Graduation Accuracy Remarks 147-104   0 – .5″   .001″   ±.00015″ for steel […]

AUTHOR RATE
Mitutoyo-SERIES 422, 122 – Non-Rotating Spindle Type-Blade Micrometers

The anvil and spindle are blade-shaped for measuring the groove diameter of shafts, keyways, and other hard-to-reach features. Carbide-tipped measuring faces are also available Non-rotating spindle type. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Remark Digimatic  (LCD) 422-230-30 0 – 25mm       0.001mm   ±3µm   […]

AUTHOR RATE
Mitutoyo-SERIES 314, 114-3 Flutes and 5 Flutes-V-Anvil Micrometers

Measures the outside diameter of cutting tools (such as taps, reamers, end mills) which have three or five flutes. Measures pitch diameter: refer to “Quick Guide to Precision Measuring Instruments” on page B-73. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric For 3-flute cutting tools Order No. Range Resolution Accuracy* […]

AUTHOR RATE
Mitutoyo-SERIES 342, 142, 112-Point Micrometers

Pointed spindle and anvil for measuring the web thickness of drills, small grooves, keyways, and other hard-to-reach features. The measuring points (carbide tipped) have approximately 0.3mm radius. series 342: IP65 Digimatic micrometers Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Point Digimatic (LCD) (With carbide tip) 342-251-30 0 […]

AUTHOR RATE
Mitutoyo-SERIES 331, 111, 131-Spline Micrometers

The anvil and spindle are of small diameter for measuring splined shafts, slots, and keyways. IP65 water/dust protection (series 331). Measuring faces: Carbide. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Remarks Digimatic  (LCD) 331-251-30 0 – 25mm       0.001mm   ±2µm   Type A 331-252-30 25 […]

AUTHOR RATE
Mitutoyo-SERIES 395, 115, 295 — Spherical and Cylindrical Anvil Type-Tube Micrometers

Spindle face: Carbide series 395: IP65 spherical and cylindrical anvil type digital micrometers Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Remarks Digimatic  (LCD) 395-261-30   0 – 25mm   0.001mm   ±3µm Type A 395-262-30 Type B 395-263-30 Type C 395-264-30 Type D * Excluding quantizing error […]

AUTHOR RATE
Mitutoyo-SERIES 395, 115, 295 — Spherical Anvil and Spindle Type-Tube Micrometers

Measuring faces: Carbide (115-201: only the spindle is carbide tipped.) Series 395: IP65 spherical anvil and spindle type digital micrometer. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* 0D Digimatic  (LCD) 395-271-30 0 – 25mm   0.001mm   ±2µm 015 395-272-30 25 – 50mm 395-273-30 50 – 75mm 019 […]

AUTHOR RATE
Mitutoyo-SERIES 395, 115, 295-Tube Micrometers

Measuring faces: Carbide (115-101: only the spindle is carbide tipped.) series 395: IP65 digital spherical-flat anvil  type micrometer. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* 0D Digimatic  (LCD) 395-251-30 0 – 25mm   0.001mm   ±2µm 015 395-252-30 25 – 50mm 395-253-30 50 – 75mm 019 395-254-30 75 […]

AUTHOR RATE
Mitutoyo-SERIES 119-Sheet Metal Micrometer

Large diameter dial model enables easy and quick measurement of sheet metal thickness. Adjustable anvil. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Order No. Range Graduation Accuracy Throat depth 119-202 0 – 25mm 0.01mm ±4µm 50mm DIMENSIONS Technical Data Standard accessories: Spanner (200168), 1 pc

AUTHOR RATE
Mitutoyo-SERIES 389, 118-Sheet Metal Micrometers

Measures thickness of sheet metal. IP65 water/dust protection (series 389). Measuring faces: Carbide Profile of measuring faces: Flat-Flat, Spherical-Flat and Spherical-Spherical. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Throat depth Measuring surfaces Digimatic  (LCD) 389-251-30   0 – 25mm       0.001mm   ±4µm   150mm […]

AUTHOR RATE
Mitutoyo-SERIES 369, 227, 169 — Non-Rotating Spindle Type-Disk Micrometers

Measures “root tangent length” of spur gears and helical gears. Determination of the root tangent length: refer to “Quick Guide to Precision Measuring Instruments”. Non-rotating spindle type. Measurable range of gear pitch: 0.5 to 6 module (series 227: 0.4 to 3 module). Equipped with Ratchet Stop for constant measuring force. Supplied with a setting standard […]

AUTHOR RATE
Mitutoyo-SERIES 324, 124 — Interchangeable Ball Anvil / Spindle Tip Type-Gear Tooth Micrometers

Measures over-pin diameter of gears using precision steel (or carbide) ball anvils / spindle tips. Series 324: IP65 Digimatic gear tooth micrometers. Determination of the over-pin diameter: refer to “Quick Guide to Precision Measuring Instruments”. Interchangeable ball anvils / spindle tips for various gear modules (0.5-5.25) are optional. Equipped with Ratchet Stop for constant measuring […]

AUTHOR RATE
Mitutoyo-SERIES 323, 223, 123-Disk Micrometers

Measures “root tangent length” of spur gears and helical gears. Determination of the root tangent length: refer to “Quick Guide to Precision Measuring Instruments”. Equipped with Ratchet Stop for constant measuring force. Supplied with a setting standard (except for 0-25mm/0-1” measuring range).   SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Anvil dia. Measurable module Digimatic […]

AUTHOR RATE
Mitutoyo-SERIES 169 – Non-Rotating Spindle Type-Paper Thickness Micrometers

• For paper thickness measurement. • Non-rotating spindle. • Equipped with Ratchet Stop for constant measuring force. (8.02±0.8N) SPECIFICATIONS Order No. Range Graduation Accuracy Flatness Parallelism 169-101 0 – 25mm 0.01mm ±4µm 1µm 3µm   Order No. Range Graduation Accuracy Flatness Parallelism 169-103 0 – 1″ .001″ ±.0002″ .00004″ .00015″ DIMENSIONS Anvil dimensions Technical Data Standard […]

AUTHOR RATE
Mitutoyo-SERIES 313-3-Wire Units

• Enables measurement of the pitch diameter of screw threads with a standard micrometer. • Determination of the pitch diameter: refer to “Quick Guide to Precision Measuring Instruments”. SPECIFICATIONS 3-Wire Units set Order No. Set Wire dia. (mm) Support spindle dia. (mm) 313-101 18 0.170 – 3.200 06.35 Order No. (One pair) (Support spindle dia.) 06.35mm […]

AUTHOR RATE
Mitutoyo-SERIES 116 – Interchangeable Anvil Type-Universal Micrometer

Non-rotating spindle type which accepts seven forms of optional interchangeable anvil / spindle tip (flat, spline, spherical, point, knife-edge, disk, and blade) for a wide range of applications. Equipped with Ratchet Stop for constant measuring force. Optional anvils / spindle tips for screw thread measurement (matching V and cone) are also available. SPECIFICATIONS Metric Order No. Range […]

AUTHOR RATE
Mitutoyo-SERIES 326, 126 – Interchangeable Anvil / Spindle Tip Type-Screw Thread Micrometers

Anvils and spindle tips are interchangeable in matching pairs to enable measurement of Metric/Unified or Whitworth threads. Direct reading of screw pitch diameter (no need for calculation) Equipped with Ratchet Stop for constant measuring force. Interchangeable anvils / spindle tips are optional. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Digimatic  (LCD) 326-251-30 0 – 25mm   […]

AUTHOR RATE
Mitutoyo-SERIES 125-Screw Thread Micrometers

Fixed anvil type to suit 60º threads Directly indicates screw pitch diameter (no need for calculation) Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Thread to be measured (Metric/nnified) Range Graduation 125-101 0.4 – 0.5mm/64  – 48TPI     0 – 25mm           0.01mm 125-102 0.6 – […]

AUTHOR RATE
Mitutoyo-SERIES 343, 143-Caliper Type Micrometers

Effective for measuring workpiece features where access is difficult. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Resolution Accuracy* Digimatic  (LCD) 343-250-30 0 – 25mm   0.001mm ±5µm 343-251-30 25 – 50mm ±6µm 343-252-30 50 – 75mm ±7µm 343-253-30 75 – 100mm ±8µm * Excluding quantizing error […]

AUTHOR RATE
Mitutoyo-SERIES 105 — with Anvil Extension Collars-Outside micrometers

Wide measuring range with anvil extension collars 50mm/2” spindle stroke Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No. Range Graduation Extension Collars Setting Standard (pcs) (every 100mm) 105-408 1000 – 1100mm           0.01mm           1 pc (50mm)       […]

AUTHOR RATE
Mitutoyo-SERIES 105 — with Anvil Extension Collars-Outside micrometers

Adjustable measuring range with extension collars. 50mm/2” spindle stroke Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Order No. Range Graduation Extension Collars Setting Standard 105-103 500 – 600mm     0.01mm     1 pc (50mm)     2 pcs. 105-104 600 – 700mm 105-105 700 – 800mm 105-106 800 – 900mm […]

AUTHOR RATE
Mitutoyo-SERIES 340, 104 — with Interchangeable Anvils-Outside Micrometers

Wide measuring range with interchangeable anvils. Measuring face of the spindle is carbide tipped (standard model). IP 65 water/dust protection (series 340). * Models with a measuring range up to 300mm. Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric Order No.   Range   Resolution   Interchangeable anvils Setting Standard   Micrometer head stroke Qty […]

AUTHOR RATE
Mitutoyo-SERIES 107-Indicator Type Micrometers

Designed to mount a dial indicator for direct GO/±NG judgment on mass-produced parts. Anvil retracting trigger for quick measurement. Various kinds of indicators*1 are selectable depending on the measurement type (accuracy required, measuring range, etc.). Measuring faces: Carbide Anvil stroke: 3mm SPECIFICATIONS Metric Order No. Range Accuracy 107-201 0 – 25mm   ±2µm 107-202 25 – 50mm 107-203 […]

AUTHOR RATE
Mitutoyo-SERIES 406-Digimatic straight line micrometer outside micrometer

Non-rotating spindle. Equipped with Ratchet Stop for constant measuring force. Metric Order No. Range Resolution Accuracy* Flatness Parallelism 406-250-30 0 – 25mm     0.001mm   ±3µm     0.3µm   3µm 406-251-30 25 – 50mm 406-252-30 50 – 75mm 406-253-30 75 – 100mm ±4µm 4µm   * Excluding quantizing error Inch/Metric Order No. Range […]

AUTHOR RATE
Mitutoyo-SERIES 193-Digit Outside Micrometers

Mechanical digit counter with 0.01mm or .001” resolution for quick and error-free reading. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. SPECIFICATIONS Metric With ratchet stop Order No. Range Graduation Accuracy 193-101 0 – 25mm 0.01mm     ±2µm 193-111 0.001mm 193-102   25 – 50mm 0.01mm 193-112 0.001mm 193-103   50 – […]

AUTHOR RATE
Mitutoyo-SERIES 101-Outside Micrometers

Satin-chrome-finished frame, tapered (on the anvil side) for hard-to-reach places. Supplied with a setting standard (except for 0-1” models). Measuring faces: Carbide SPECIFICATIONS Inch With ratchet stop Order No. Range Graduation Accuracy 101-113 0 – 1″     .0001″   ±.0001″ 101-114 1″ – 2″ 101-119 2″ – 3″ 101-120 3″ – 4″ ±.00015″ Inch With friction […]

AUTHOR RATE
Mitutoyo-SERIES 103-Outside Micrometers

Baked-enamel-finished frame. Measuring faces: Carbide Equipped with Ratchet Stop for constant measuring force. Metric  With ratchet stop Order No. Range Graduation Accuracy 103-137 0 – 25mm 0.01mm     ±2µm 103-129 0.001mm 103-138 25 – 50mm 0.01mm 103-130 0.001mm 103-139-10 50 – 75mm                         […]

AUTHOR RATE
Mitutoyo-SERIES 102 — Outside Micrometers-Ratchet Thimble Micrometer

More accurate in one-handed operation: inexperienced operators measure significantly more accurately with the new micrometer. Ratchet function works both from the thimble and the speeder. Rotating the thimble/speeder when the workpiece is between the anvil and spindle causes the ratchet mechanism to operate and apply a constant measuring force to the workpiece. Clearly audible ratchet operation […]

AUTHOR RATE
Mitutoyo-SERIES 102-Outside Micrometers

Heat-insulated frame. Cut-away frame (behind anvil) for measuring in hard-to-reach places. A ratchet stop or a friction thimble for a constant measuring force. Measuring faces: Carbide       SPECIFICATIONS Metric Order No. Range Graduation Accuracy Flatness Parallelism Constant-force device 102-301   0 – 25mm 0.01mm ±2µm 0.6µm 2µm Ratchet stop 102-311 0.001mm ±1µm 0.3µm […]

AUTHOR RATE
Mitutoyo-SERIES 227-with Adjustable Measuring Force-ABSOLUTE Digimatic Micrometers

Digimatic micrometer dedicated to applications requiring a constant/low measuring force such as measuring wire, paper, and plastic/rubber parts. Ratchet mechanism in the thimble applies constant force to workpiece. Compact and easy to handle. Measuring force is adjustable (in steps) to suit various kinds of workpiece. High-accuracy measurement can be performed even by unskilled operators due to […]

AUTHOR RATE
Mitutoyo-SERIES 293-IP54 ABSOLUTE Digimatic Micrometers-Quickmike

The Quickmike provides a speedy spindle feed of 10mm per thimble rotation, which enables widely differently sized features to be measured quickly. Set the origin only once. The absolute linear scale maintains the origin throughout the life of battery, meaning no more zero setting (presetting) or overspeed error. Measuring faces: Carbide Supplied with a Ratchet […]

293-582
AUTHOR RATE
Mitutoyo-SERIES 293-Digimatic outside micrometers

Models equipped with a Digimatic output port can form part of a statistical process control or networked measurement system. (Refer to page A-3 for details.) Constant-force device: ratchet stop Interface Input Tools are available that enable the conversion of measurement data to keyboard signals that are then directly input to cells in off-the-shelf spreadsheet software such as […]

AUTHOR RATE
Mitutoyo-SERIES 293 — with Dust/Water Protection Conforming to IP65 Level -Coolant Proof Micrometers

World’s highest performing micrometer overall. Extended battery life of approximately 2.4 years. Ergonomic anti-slip frame cover and front panel for more comfortable hand-held measurements. Ratchet thimble provides better operability for one-handed operation. Oil-resistant material used for all plastic parts. Models equipped with a Digimatic output port can form part of a statistical process control or […]

293-140
AUTHOR RATE
Mitutoyo-SERIES 293 — IP65 Micrometer with 2mm/rev Spindle Feed-QuantuMike

Advanced pioneering technology has created the next generation of micrometer, the most revolutionary advance in micrometer technology since James Watt invented the instrument. Faster measurement is achieved by using a coarser thread which feeds the spindle by 2mm per revolution of the thimble. This increase in thread lead has been made possible thanks to new high precision threadcutting […]

293-100
AUTHOR RATE
Mitutoyo – SERIES 293 – High-Accuracy Digimatic Micrometer

Enabling 0.1μm resolution measurement, this micrometer is ideal for customers who need to make highly accurate measurements with a hand-held tool. The High-Accuracy Digimatic Micrometer utilizes Mitutoyo’s innovative 0.1μm resolution ABS (absolute) rotary sensor*1 and high-accuracy screw machining technology to reduce the instrumental error to ±0.5μm, delivering higher accuracy without sacrificing operability. *1. Patent pending […]

AUTHOR RATE
MICROMAR 44 AK / 844 AG / 44 EWG – COMPONENTS

MICROMAR 44 AK MEASURING HEAD Self-centering measuring head consists of 3 laterally positioned anvils, each are offset at intervals of 120° Anvils from 12 mm are carbide tipped From 12 mm the anvils can be used to measure the bottom of a bore From 40 mm all measuring heads are made from aluminium to reduce […]

AUTHOR RATE
MICROMAR 844 A / 844 AS – SELF-CENTERING MEASURING PISTOLS

MICROMAR 844 A SELF-CENTERING INSIDE MEASURING PISTOL Threaded connection for changing the measuring head Self-centering measuring head consists of 3 laterally positioned anvils, each are offset at intervals of 120° Anvils from 12 mm are carbide tipped From 12 mm the anvils can be used to measure the bottom of a bore From 40 mm […]

AUTHOR RATE
MICROMAR 44 EWR – SELF-CENTERING DIGITAL INSIDE MICROMETERS

MICROMAR 44 EWR DIGITAL SELF-CENTERING INSIDE MICROMETER Threaded connection for changing the measuring head Self-centering measuring head consists of 3 laterally positioned anvils, each are offset at intervals of 120° Anvils from 12 mm are carbide tipped From 12 mm the anvils can be used to measure the bottom of a bore From 40 mm […]

AUTHOR RATE
MICROMAR 44 A / 44 AS – SELF-CENTERING INSIDE MICROMETERS

MICROMAR 44 AS SELF-CENTERING INSIDE MICROMETER SET Operating and display units with satin chrome finish Stainless spindle is hardened throughout and ground Rapid drive with integrated ratchet Self-centering measuring head consists of 3 laterally positioned anvils, each are offset at intervals of 120° Anvils from 12 mm are carbide tipped From 12 mm the anvils […]

AUTHOR RATE
MICROMAR 46 EWR DIGITAL MICROMETER HEAD

High contrast analog display Rapid drive with integrated ratchet Immediate measurements due to the Reference System Digimatic Opto RS232C USB Battery life approx. 2 years IP 52 end cap (in case the rapid drive is not required) instruction manual battery case 8.5mm             Technical Data Order no. Measuring range mm […]

AUTHOR RATE
MICROMAR 46 / 46 H – MICROMETER HEAD

MICROMAR 46 MICROMETER HEAD Operating and display units with satin chrome finish Stainless spindle is hardened throughout and ground Technical Data Order no. Measuring range mm Graduation value mm Error limit µm Spindle diameter Spindle thread pitch_mm 4183021 0 – 6.5 0,01 3 µm 3.5 mm 0.5 mm 4183023 0 – 50 0,01 5 µm […]

AUTHOR RATE
MICROMAR 44 CB INSIDE MICROMETER WITH REDUCED MEASURING FACES

Operating and display units with satin chrome finish Rigid, lightweight tubular construction Stainless spindle is hardened throughout and ground Locking device Carbide tipped spherical measuring faces Interchangeable extension 44 Cv contains cylindrical gage rods that are spring mounted in protective sleeves for the extension of the measuring range Protection sleeves have a satin chrome finish […]

AUTHOR RATE
MICROMAR 44 CZ INSIDE MICROMETER

Operating and display units with satin chrome finish Measuring head and end piece with mounting bore for interchangeable anvils Rigid, lightweight tubular construction Stainless spindle is hardened throughout and ground Locking device Interchangeable extension 44 Cv contains cylindrical gage rods that are spring mounted in protective sleeves for the extension of the measuring range Protection […]

AUTHOR RATE
MICROMAR 44 CMS 4 INSIDE MICROMETER SET

Operating and display units with satin chrome finish Rigid, lightweight tubular construction Stainless spindle is hardened throughout and ground Locking device Carbide tipped spherical measuring faces Interchangeable extension 44 Cv contains cylindrical gage rods that are spring mounted in protective sleeves for the extension of the measuring range Protection sleeves have a satin chrome finish […]

AUTHOR RATE
MICROMAR 44 F INSIDE MICROMETER

Operating and display units with satin chrome finish Rigid, lightweight tubular construction Stainless spindle is hardened throughout and ground Measuring faces spherically lapped, one measuring face adjustable Measuring range of 100-125 mm with heat insulators and a locking device case Technical Data Order no. Measuring range mm Graduation value mm Error limit µm Spindle thread […]

AUTHOR RATE
MICROMAR 40 W MICROMETER

Operating and display units with satin chrome finish Spindle and anvil made of hardened steel, carbide tipped Hard lacquered steel frame, from 400 mm the frame is made from a steel tube to reduce weight Heat insulators Ratchet is integrated in the thimble Locking device 4 interchangeable anvils, adjustable instruction manual setting values case Technical […]

AUTHOR RATE
MICROMAR 40 AG MICROMETER

Operating and display units with satin chrome finish Spindle and anvil made of hardened steel, carbide tipped Hard lacquered steel frame, from 400 mm the frame is made from a steel tube to reduce weight Heat insulators Ratchet is integrated in the thimble Locking device instruction manual setting value case Technical Data Order no. Measuring […]

AUTHOR RATE
MICROMAR 40 AS MICROMETER

Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device instruction manual setting values 5″ / 7″ case Technical Data Order no. Measuring range inches Graduation value inch Spindle diameter Micrometer pitch (inches) 4134960 0 […]

AUTHOR RATE
MICROMAR 40 A MICROMETER

Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device instruction manual setting standard (from measuring range 1-2″) case Technical data Order no. Measuring range inches Graduation value inch Error limit inches Spindle diameter Micrometer […]

AUTHOR RATE
MICROMAR 40 SA MICROMETER

Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device instruction manual setting values 125 mm / 175 mm case Technical Data Order no. Measuring range mm Graduation value mm Spindle diameter Spindle thread pitch_mm […]

AUTHOR RATE
MICROMAR 40 A MICROMETER

Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device setting standard (measuring range of 25-50 mm) instruction manual case Technical Data Order no. Measuring range mm Graduation value mm Error limit µm Spindle diameter […]

AUTHOR RATE
MICROMAR 40 TS – PRECISION BENCH MICROMETER

MICROMAR 40 TS PRECISION BENCH MICROMETER Operating and display units with satin chrome finish Rugged steel frame, can be inclined up to 45° from the sturdy base Retraction of the movable anvil ensures maximum wear resistance Height adjustable stop Constant measuring force Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped […]

AUTHOR RATE
MICROMAR 40 T MICROMETER WITH INTEGRATED DIAL COMPARATOR

Operating and display units with satin chrome finish Retraction of the movable anvil ensures maximum wear resistance Constant measuring force Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped Locking device instruction manual case Technical Data Order no. Measuring range mm Error limit µm Parallel error in µm Flatness in µm […]

AUTHOR RATE
MICROMAR – MICROMETER WITH INTEGRATED DIAL COMPARATOR

MICROMAR 40 F MICROMETER WITH INTEGRATED DIAL COMPARATOR Satin chrome finished operating and display units Dial Comparator is integrated in frame Adjustable tolerance markers Chrome plated steel frame, heat insulated Retraction of the moveable anvil ensures maximum wear resistance Spindle and anvil are carbide tipped Spindle is hardened through-out and ground, stainless Locking device Constant […]

AUTHOR RATE
MICROMAR 40 SM MICROMETER

Operating and display units with satin chrome finish Maximum stability Stainless spindle is hardened throughout and ground Disc-type anvils are hardened and lapped Chrome plated steel frame, heat insulated Rapid drive with integrated ratchet Locking device instruction manual case Technical Data Order no. Measuring range mm Graduation value mm Error limit µm Parallel error in […]

AUTHOR RATE
MICROMAR 40 AW MICROMETER

Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device Sliding spindle instruction manual case Technical Data Order no. Measuring range inches Graduation value inch Error limit inches Micrometer pitch (inches) Measuring force (N) 4134950 […]

AUTHOR RATE
MICROMAR 40 AW MICROMETER

Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device Sliding spindle instruction manual case Technical Data Order no. Measuring range mm Graduation value mm Error limit µm Parallel error in µm Flatness in µm […]

AUTHOR RATE
MICROMAR 40 Z THREAD MICROMETER

Scales have a satin chrome finish Rugged steel frame, heat insulated Spindle is hardened throughout, ground and provided with a locking device Adjustable anvil Spindle and anvil both have a mounting bore to accommodate interchangeable anvils Flat end surface of the anvil shank rests on a hardened steel ball at the bottom of the mounting […]

AUTHOR RATE
MICROMAR 40 EWV DIGITAL MICROMETER

High contrast analog display Sliding spindle Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped Rapid drive Ratchet is integrated in the thimble Chrome plated steel frame, heat insulated With mounting shank for anvils dia. = 3,5mm Digimatic Opto RS232C USB Battery life approx. 2 years IP 52 instruction manual battery […]

AUTHOR RATE
MICROMAR 40 AR MICROMETER

Measuring surfaces: spherical anvil, planar spindle Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device instruction manual setting standard (measuring range of 25-50 mm) case Technical Data Order no. Measuring range mm Graduation value […]

AUTHOR RATE
MICROMAR 40 EWR-R DIGITAL MICROMETER

Measuring surfaces: spherical anvil, planar spindle High contrast analog display Stainless spindle is hardened throughout and ground Rapid drive Lacquered steel frame, heat insulated USB Digimatic Opto RS232C Battery life approx. 2 years IP 65 instruction manual battery setting standard (measuring range of 25-50 mm) case 8.5 mm             Technical […]

AUTHOR RATE
MICROMAR 40 AS – MICROMETERFOR MEASURING RECESSES, GROOVES, ETC.

MICROMAR 40 AS MICROMETER With blade-type measuring surfaces Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device Sliding spindle instruction manual setting standard (measuring range of 25-50 mm) case Technical Data Order no. Measuring […]

AUTHOR RATE
MICROMAR 40 EWR-S DIGITAL MICROMETER

With blade-type measuring surfaces Sliding spindle High contrast analog display Stainless spindle is hardened throughout and ground Rapid drive Lacquered steel frame, heat insulated USB Digimatic Opto RS232C Battery life approx. 2 years IP 54 instruction manual battery setting standard (measuring range of 25-50 mm) case         Technical Data Order no. Measuring […]

AUTHOR RATE
MICROMAR 40 AB – MICROMETERFOR MEASURING GROOVES, SPLINE SHAFTS, RECESSES, ETC.

MICROMAR 40 AB MICROMETER Reduced measuring surfaces Ø 3 mm Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device instruction manual setting standard (measuring range of 25-50 mm) case Technical Data Order no. Measuring […]

AUTHOR RATE
MICROMAR 40 AR MICROMETER

Measuring surfaces: spherical anvil, planar spindle Operating and display units with satin chrome finish Hard lacquered steel frame Spindle and anvil made of hardened steel, carbide tipped Heat insulators Rapid drive with integrated ratchet Locking device instruction manual setting standard (from measuring range 1-2″) case Technical Data Order no. Measuring range inches Graduation value inch […]

AUTHOR RATE
MICROMAR 40 EWR-B DIGITAL MICROMETER

Reduced measuring surfaces Ø 3 mm High contrast analog display Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped Rapid drive Ratchet is integrated in the thimble Lacquered steel frame, heat insulated USB Digimatic Opto RS232C Battery life approx. 2 years IP 65 instruction manual battery setting standard (measuring range of […]

AUTHOR RATE
MICROMAR 40 EWR-K DIGITAL MICROMETER

Measuring surfaces: Anvil with narrow web, pointed spindle High contrast analog display Stainless spindle is hardened throughout and ground Rapid drive Lacquered steel frame, heat insulated USB Digimatic Opto RS232C Battery life approx. 2 years IP 65 battery instruction manual case Height of Digits 8.5mm           Technical Data Order no. Measuring […]

AUTHOR RATE
MICROMAR 40 EWRI DIGITAL MICROMETER SET

High contrast analog display Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped Rapid drive Ratchet is integrated in the thimble Lacquered steel frame, heat insulated ntegrated wireless Battery life approx. 2 years (approx. 0.5 in wireless mode) IP 65 instruction mnual battery setting values case Height of Digits 10 mm […]

AUTHOR RATE
MICROMAR 40 EWR DIGITAL MICROMETER

High contrast analog display Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped Rapid drive Ratchet is integrated in the thimble Lacquered steel frame, heat insulated Battery life approx. 2 years IP 65 instruction manual battery setting standard (measuring range of 25-50 mm) case Height of Digits 10 mm .   […]

AUTHOR RATE
MICROMAR 40 EWRI DIGITAL MICROMETER

High contrast analog display Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped Rapid drive Ratchet is integrated in the thimble Lacquered steel frame, heat insulated Integrated wireless Battery life approx. 2 years (approx. 0.5 in wireless mode) IP 65 instruction manual battery setting standard (measuring range of 25-50 mm) case […]

AUTHOR RATE
MICROMAR 40 ER DIGITAL MICROMETER

High contrast analog display Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped Rapid drive Ratchet is integrated in the thimble IP 40 instruction manual battery case Height of Digits 10 mm       Technical Data Order no. Measuring range mm Measuring range inches Resolution mm/inch Error limit µm Spindle […]

AUTHOR RATE
MICROMAR 40 EWS DIGITAL MICROMETER

Sliding spindle High contrast analog display Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped Rapid drive Ratchet is integrated in the thimble Lacquered steel frame, heat insulated Digimatic Opto RS232C USB IP 52 battery instruction manual case Height of Digit 8.5mm             Technical Data Order […]

AUTHOR RATE
MICROMAR 40 EWR – DIGITAL OUTSIDE MICROMETER, IP 65

MICROMAR 40 EWR DIGITAL MICROMETER High contrast analog display Stainless spindle is hardened throughout and ground Spindle and anvil are carbide tipped Rapid drive Ratchet is integrated in the thimble Lacquered steel frame, heat insulated Digimatic Opto RS232C USB Battery life approx. 2 years IP 65 instruction manual battery setting standard (measuring range of 25-50 […]

AUTHOR RATEUSERS RATE (0)
PRECISION BORE GAGE CODE – 2825

Optional accessory: setting ring (code 6312)     Check the PDF

AUTHOR RATEUSERS RATE (0)
INTERNAL MICROMETER WITH INTERCHANGEABLE ANVILS CODE – 3226

Graduation: 0.01mm Optional accessory: ball tips (code 7391) V-shaped and cone-shaped anvils(code 7321), zero block for V-shaped and cone-shaped anvils(code 3226-SP)     Check the PDF

AUTHOR RATEUSERS RATE (0)
TUBULAR INSIDE MICROMETER CODE – 3229

Graduation 0.01mm Carbide measuring faces     Check the PDF

AUTHOR RATEUSERS RATE (0)
TUBULAR INSIDE MICROMETER CODE – 3224

Graduation 0.01mm Accuracy:(3+n+L/50)μm n=number of rods L=maximum measuring length(mm) Travel of micrometer head 50mm Carbide measuring faces     Check the PDF

AUTHOR RATEUSERS RATE (0)
TUBULAR INSIDE MICROMETER CODE – 3225

Graduation 0.01mm Accuracy:(3+n+L/50)μm n=number of rods L=maximum measuring length(mm) Travel of micrometer head 25mm Supplied with setting standards Carbide measuring faces     Check The PDF

AUTHOR RATEUSERS RATE (0)
THREE POINTS INTERNAL MICROMETER

6-12mm:graduation 0.001mm 12-300mm: graduation 0.005mm Ratchet stop Optional accessory:setting rings (code 6312)     check the pdf

AUTHOR RATEUSERS RATE (0)
DIGITAL THREE POINTS INTERNAL MICROMETER

Resolution 0.001mm/0.00005″ IP54 dust/waterproof Buttons:on/off, set,mm/inch,ABS/INC Data output LR44 battery,automatic power off Ratchet stop Optional accessary:data output cable(code 7306-30, 7302-SPC2A, 7305-SPC3), setting ring(code 6312) Check The PDF

AUTHOR RATEUSERS RATE (0)
BAKER MICROMETER HEAD

Micrometer Head – Plain Holding Diameter FEATURES: Spindle made from stainless steel for rust prevention Measuring face: carbide tipped, precision ground & micro lapped An in-built ratchet in the thimble Sharp laser marking for better visibility & durability     Measuring Range mm Reading mm Type Measuring Range inch Reading inch Type 0-25 0.01 MMA25-HP […]

AUTHOR RATEUSERS RATE (0)
BAKER SETTING GAUGE FOR EXTERNAL MICROMETER

FEATURES: Hardened, ground & lapped measuring faces Flat type measuring faces Measuring faces flatness 0.3 µm     Metric Length (L) mm Tolerence µm I mm Diameter ( Ød) mm Diameter ( ØD) mm 25 ± 1.5 20 7 11 50 ± 2.0 40 7 11 75 ± 2.5 40 7 11 100 ± 3.0 […]

AUTHOR RATEUSERS RATE (0)
BAKER DISC MICROMETER – ROTATING TYPE

Disc Micrometer Rotating Type FEATURES: Spindle made from stainless steel for rust prevention Measuring faces: hardened steel An in-built ratchet in the thimble Zero setting once done cannot be easily tampered with Sharp laser marking for better visibility & durability Heat insulating grip plates cover the entire handling portion of the micrometer frame Robust design […]

AUTHOR RATEUSERS RATE (0)
BAKER POINT MICROMETERS

FEATURES: Spindle made from stainless steel for rust prevention Measuring Faces – 15° & 30° hardened steel points having radius 0.3 mm approximately An in-built ratchet in the thimble Zero setting once done cannot be easily tampered with Sharp laser marking for better visibility & durability Heat insulating grip plates cover the entire handling portion […]

AUTHOR RATEUSERS RATE (0)
BAKER SPLINE MICROMETERS

FEATURES: Spindle made from stainless steel for rust prevention Measuring faces: carbide tipped available in two types Ø2 x 5 mm & Ø3 x 8 mm Zero setting once done cannot be easily tampered with An in-built ratchet in the thimble Sharp laser marking for better visibility & durability Heat insulating grip plates cover the […]

AUTHOR RATEUSERS RATE (0)
BAKER TUBE TYPE MICROMETER

FEATURES: Spindle made from stainless steel for rust prevention Measuring faces: hardened steel available in two types: T1 – one end spherical T2 – both ends spherical An in-built ratchet in the thimble Zero setting once done cannot be easily tampered with Sharp laser marking for better visibility & durability Heat insulating grip plates cover […]

AUTHOR RATEUSERS RATE (0)
BAKER BLADE MICROMETERS

FEATURES: Spindle made from stainless steel for rust prevention Measuring faces: hardened steel An in-built ratchet in the thimble Zero setting once done cannot be easily tampered with Sharp laser marking for better visibility & durability Heat insulating grip plates cover the entire handling portion of the micrometer frame Robust design withstands toughest workshop conditions […]

AUTHOR RATEUSERS RATE (0)
BAKER DIGITAL MICROMETERS

FEATURES: Protection level IP65 against dust & water (coolant proof) Stainless steel spindle to avoid rust Carbide measuring faces mm / inch conversion Auto power off SR44/LR44 battery Ball attachment free of cost Absolute & incremental measuring mode Easy operations with 2 buttons Each micrometer is supplied with calibration certificate stating actual values Supplied in […]

Baker Gauges Micrometer
AUTHOR RATEUSERS RATE (0)
Baker Gauges Micrometer

Mechanical External Micrometer: Range 0-200 mm / 0-8″ FEATURES: Specifications : IS, DIN, ANSI & JIS Spindle made from stainless steel for rust prevention Measuring faces: carbide tipped, precision ground & micro lapped An in-built ratchet in the thimble Zero setting once done cannot be easily tampered with Sharp laser marking for better visibility & […]

AUTHOR RATE
Long Handle Code 7351

Brand : Insize

AUTHOR RATE
Bore Gage Code 2827

Brand : Insize

AUTHOR RATE
Bore Gage Code 2322

Brand : Insize

Gokul Traders Copyright © 2010-18 Developed by Shades Of Web. All rights reserved.
