MARAMETER 838 AB PORTABLE THICKNESS GAGES

MARAMETER 838 AB PORTABLE THICKNESS GAGES

Rugged, sturdy frame made from hard aluminum Built-in digital or dial indicator With a lifting lever for movable upper measuring spindle Technical data Order no. Product type Measuring range inches Measuring range mm Throat depth mm Resolution (mm) Resolution (in) Resolution mm/inch Graduation value mm Measuring surface diameter Measuring face Measurement surface radius 4495140 838

Rugged, sturdy frame made from hard aluminum
Built-in digital or dial indicator
With a lifting lever for movable upper measuring spindle

Portable thickness gages

Technical data

Order no.	Product type	Measuring range inches	Measuring range mm	Throat depth mm	Resolution (mm)	Resolution (in)	Resolution mm/inch	Graduation value mm	Measuring surface diameter	Measuring face	Measurement surface radius
4495140	838 AB	0 – .750″	0 – 20	50 mm	0.005 mm	0 inch	0.005 / .0001″		11.3 mm	1 cm²	30 mm
4495141	838 AB	0 – .750″	0 – 20	100 mm	0.005 mm	0 inch	0.005 / .0001″		11.3 mm	1 cm²	30 mm
4495145	838 AB	0 – .750″	0 – 20	50 mm	0.001 mm	0 inch	0.001 / .00005″		11.3 mm	1 cm²	30 mm
4495146	838 AB	0 – .750″	0 – 20	100 mm	0.001 mm	0 inch	0.001 / .00005″		11.3 mm	1 cm²	30 mm
4495504	838 AB		0 – 20	50 mm				0.01 mm	11.3 mm	1 cm²	30 mm
4495517	838 AB		0 – 20	100 mm				0.001 mm	11.3 mm	1 cm²	30 mm
4495519	838 AB		0 – 20	50 mm				0.001 mm	11.3 mm	1 cm²	30 mm
